Side 1/9

User’s Guide

BSS Audio MC-1

Stand-Alone Media Converter

•Gigabit Ethernet

•Copper to Fiber

•1000Base-T to 1000Base-SX/LX

BSS MC-1 Gigabit Ethernet mediaAudio

converter connects 1000Base-T

shielded or unshielded twisted-pair copper

cable to 1000Base-SX or 1000Base-LX, fiber-

optic cable. is a stand-MC-1

alone media converter

Installation . . . . . . . . . . . . . . . . . .3

Operation . . . . . . . . . . . . . . . . . . .7

Cable Specifications . . . . . . . . . . .9

Technical Specifications . . . . . . .11

Troubleshooting . . . . . . . . . . . . .12

Compliance Information . . . . . . .15

MC-1 RJ-45 1000Base-T

100 m (328 ft)*

SC, 1000Base-LX, 1310 nm single mode

10 km *(6.2 miles)

*Typical maximum cable distance. Actual

distance is dependent upon the physical

characteristics of the network installation.

2BSS Audio 800-931-2357 8760 South Sandy Parkway, Sandy, Utah 84070 www.bssaudio.com 800-931-2357 3

Installation

Set the 6-position switch

The 6-position switch is located

on the side of the media

converter.

•Use a small flat blade

screwdriver to set the

recessed switches.

•All switches are shown in

the default position, UP.

Note: Switch positions S2 and S3 work together to configure the media

converter for Pause conditions.

S1 Remote-Fault Detection

up Disabled

down Enable

S2 & S3 work in combination

Pause

10 sw position 2 up and 3 down: Symmetric

01 sw position 2 down and 3 up: Asymmetric

11 sw positions 2 and 3 up: Pause is OFF (default position)

00 sw positions 2 and 3 down: Symmetric and Asymmetric

S4 Transparent Link Pass-Through

up Enable Link Pass-Through

down Disable Link Pass-Through

S5 Fiber Auto-Negotiation

up Disable Fiber Auto-Negotiation for the fiber link

(default setting)

down Enable Fiber Auto-Negotiation for the fiber link

S6 Loop Back

up Disable RX/TX signal loop back (default setting)

down Enable RX/TX signal loop back

2. Pause (symmetric)

3. Pause (asymmetric)

4. Transparent Link Pass-Through

5. Auto-Negotiation

1. Remote Fiber Fault Detect

6. Loop Back
