SANTEC IP FISHEYE CAMERA

BWNC-842DFIF

4K/Ultra HD 360°Fisheye-camera

1,98 mm lens, IR-LED, PoE

PRODUCT DESCRIPTION

Application:

BWNC-842DFIF is a 360° sheye camera which can be used for for many dierent applications, indoors as well

as outdoors. Thanks to the integrated IR LEDs with up to 10m range, surveillance at night or under poor light

conditions are not a problem. The dome camera is vandal-proof according to IK10 classication. BWNC-842DFIF

supports Ultra HD/4K at max. 12 megapixel resolutio (4000x3000 pixels). This camera has manifold functions and

adjustment options such as 3x streaming, 360° panorama view, region-of-interest (ROI), privacy zones and many

more. A special camera feature is the so-called extended Intelligent Video Analysis (IVA+). It comprises the

well-known functions such as virtual tripwire, area monitoring etc. but also special functions liek "heatmap",

"people counting" and SmartTrack with a connected SANTEC speed-dome camera. Using a SD card you can

store and export data.

Technical specications:

Type 12MP UHD Fisheye

Decoding / Video / Lens >>>>>DECODING/VIDEO/LENS<<<<<

Sensor type 1/1.7" Progressive Scan CMOS

Max. Picture resolution (pixel) 12 MP (4000x3000 pixel)

Video codec H.264M/B/H, H.264, H.264+, MJPEG, H.265, H.265+

Max. frame rate (fps) 25 fps at 12 MP, 25/30 fps at 3 MP

Number of video streams 3 (individually adjustable)

Lens mount Intern

S/N ratio (dB) < 50dB

Iris control Automatic

Lens type 360° panorama lens, Fixlens

Focal length 1,85 / F2.0

BURG-GUARD GmbH

Wormgermühle, 58540 Meinerzhagen, Germany

Tel.: +49 2358 905 490, Fax: +49 2358 905 499

BURG-GUARD@burg.biz, www.burg-guard.com

Our products undergo constant development. Please refer to the price list for our most up-to-date product program. Errors and omissions excluded. No responsibility accepted for accuracy of

images.

SANTEC IP FISHEYE CAMERA

BWNC-842DFIF

Technical specications:

Angle of view (horizontal) 180° / 180° / 180°

Sensitivity (Lux) 0.01 (color) / 0.0 (IR on)

IR cut lter ICR-IR-Cut lter

DETECT-OBSERVE-RECOGNIZ

E-IDENTIFY

>DETECT-OBSERVE-RECOGNIZE-IDENTIFY<

DORI max.

(Detect-Observe-Recognize-Ident

ify)

36m - 14m - 7m - 4m

Features >>>>>>>>>>FEATURES<<<<<<<<<<<

Day/night mode adjustment Auto / color / B/W

Automatic gain control (AGC) Yes

Digital noise reduction (DNR) 3DNR

Shutter (sec.) 1/3 - 1/10000

White balance Auto, manually and others

Backlight compensation BLC, HLC, 100dB WDR

Wide dynamic range (WDR) Yes, 100dB

Digital zoom Yes

Mirroring (vertical) Yes

Privacy zones Yes, 4 zones

Region of Interest (ROI) Yes

Video analysis >>>>>>>>Videoanalytics<<<<<<<<<

IVA via ONVIF Motion Yes

Intelligent Video Analysis (IVA) Yes

Tripwire (IVA) Yes

Intrusion (IVA) Yes

People counting (IVA+) No

People in Area Yes

Queue Management Ja

Tampering Alarm Yes

Scene change (tampering) Yes

IVA Missing / Added No

Audio detect (IVA) Yes

Face detect (IVA) No

Camera title Yes

Interface >>>>>>>>>INTERFACE<<<<<<<<<

Video output 1x Video test port (1.0 Vpp, 75 Ohm)

Audio support Two-way

Audio in-/outputs 1 / 1

Audio codec G.711a / G.711Mu / PCM

Alarm contacts I/O 2 / 2 -> Input: 5mA/5VDC / Output: 1A/30VDC

RS-485 interface No

Internal memory Micro SD (optional), max. 128 GB
