SAFETY WARNINGS & INSTRUCTIONS
Information contained in this Instruction Manual will help you operate the item safely, protect yourself and others
from hazards, and prevent damage to the device and other property.
SAVE THESE INSTRUCTIONS
WARNING!
- This is not a TOY. Children should be kept out of reach from this robot and its accessories.
- Never allow children to operate this product.
- This appliance is not intended for use by persons with reduced physical, sensory, mental
capabilities, or a lack of experience and knowledge, unless they are given supervision or
instructions concerning the safe use of the appliance and understand the hazards involved by a
person responsible for their safety.
- Children must not play with this product.
- Cleaning and maintenance of the robot must not be carried out by children.
- Make sure the robot is fully immersed in the pool before initiating operation. The minimum water
level required to operate the robot must reach above the swivel head of the robot. Operating the
robot when it is not immersed correctly could damage the unit and void the warranty.
- Maximum operating depth in water is 3 meters ( 10 ft ).
- Operating water temperature: 5˚C ( 41˚F ) – 35˚C ( 95˚F ).
- Detachable supply unit (external adaptor).
- The robot should only be recharged with the external adaptor and charging cable delivered with
this product.
- For the purposes of recharging the battery, only use the detachable supply unit ( external adaptor
model number: DSS12D-0841000-B / DSS12D-0841000-C / DSS12D-0841000-D / LX084100U )
that provided with this robot to charge the battery.
- Connect the external adaptor to a power source through a residential current device ( RCD ) / a
ground fault circuit interrupter ( GFCI ). If in doubt, consult a qualified electrician.
- Do not use this robot if any damage is detected.
- Replace damaged parts with ones that are certified by the distributor or manufacturer.
- Turn off the robot, disconnect the external adaptor from the power source, and unplug the external
adaptor from the charging cable, before detaching the robot from the charging cable.
- Disconnect the robot from the supply mains and make sure the robot is OFF prior to carrying out
regular maintenance – such as cleaning the filter, swivel smoothing-ring, and the areas around the
water sensors and charging port.
- Do not attempt to replace the installed rechargeable Li - ion battery pack.
- DO NOT handle the robot, external adaptor, and charging cable while it is charging with wet limbs
and without shoes.
- You should not operate this robot when people and/or pets are present in the water.
- DO NOT use this robot without an intact filter in place, otherwise your warranty will be voided as a
result.
- Suction entrapment hazard: This robot generates suction. Do not allow hair, body, and any loose
parts of your clothing to make contact with the suction hole of the robot during its operation.
- Never insert body parts, clothing, and other objects into the openings and moving parts of the robot.
- DO NOT use this robot to pick up any toxic substance, flammable, and combustible liquids ( i.e.
gasoline ) in the presence of explosive or flammable fumes.
-
Under no circumstances should you disassemble the swivel head to replace its internal components
by yourself. Doing so would void the warranty, expose yourself to potential hazards, and possibly
- For details regarding battery recycling/disposal, refer to the section “
DO NOT use this robot right after pool-shocking. It is recommended to first leave the pool circulating for at least 24 - 48 hours.
- DO NOT use this robot with another automatic cleaner/cleaner simultaneously in the pool.
adaptor /charging cable or pull the cord to disconnect it from the power source and charging cable.
Pool / spa owners should always exercise extra caution and common sense when utilizing the product.
swivel head turns 180˚, allowing the robot to move in the opposite direction. The robot moves in a generally straight pattern in
Fully charge the robot ( about 6 hrs ) before using it for the first time.
Be sure not to invert the charging cable and ensure both the charging cable and
4. When charging is complete, disconnect the external adaptor from the power source and unplug the
Normally the robot can operate up to 45 minutes on a full charge.
Once the lifespan of the battery reaches its end, refer to section “
Let the robot rest for around 30 to 40 minutes before charging it again.
1. Bring the robot to the side of your pool.
First, align and attach the retrieval cord to the side notches at the top as you wrap the cord around the stem (
3. Slide the power switch to “ ” ( while the robot is still submerged ) – the indicator light will turn on and activate the motor
automatically ( water level covering the sensors at the top of the swivel head ). Let the robot sink to the pool floor and observe
retrieve it and redeploy it while making sure its front/back is facing the pool wall
No light - Power off / no power
Light - Power on
Blinking light - Battery power will be exhausted within 5 - 10 minutes.
4. To retrieve the robot from the pool, attach the hook to a telescopic pole ( not provided ) and use it to retrieve the float, if you
( for Australia / New
5. Slide the power switch OFF. Rinse the robot with fresh water after every use. DO NOT use any detergent.
6. Dry the charging port and pins thoroughly (
Before cleaning the debris compartment, make sure the robot is
clips are secured to the base. A “click” sound will
Before redeploying the robot to the pool, hold onto the wings on the body top cover to sway the robot slightly, to ensure
Float Replacement
Use a screwdriver ( not provided ) to unscrew the 4 screws at on the top cover of the swivel head. Untie the knot on the string
Flap replacement
1. Be sure to clean and dry the areas around the charging port and water sensors after every use to avoid the forming of
2. Battery discharges on its own during storage. Make sure to charge the robot to about 30% to 50% of the battery capacity
• Be sure to drain the water from the robot before storage.
temperature for storage should be 10˚C – 25˚C ( 50˚F – 77˚F ).
- Battery does not charge fully.
Battery operation time is noticeably reduced. Observe and record the run times of the first few operations ( on a full charge ).
could cause sparking and/or short circuit the battery.
Follow section “
2. Use the screwdriver to unscrew the 4 screws located at the bottom of the head to release the
3. Remove out the battery pack to expose the PCBA. To detach the battery connection wire, press
