Safety and Notice
The BG-UHD-VWP-1X4 4K 1x4 Video Wall Processor has been tested for conformance to safety
regulations and requirements, and has been certified for international use. However, like all
electronic equipment, the BG-UHD-VWP-1X4 should be used with care. Please read and follow the
safety instructions to protect yourself from possible injury and to minimize the risk of damage to the
unit.
● Follow all instructions and warnings marked on this unit.
● Do not attempt to service this unit yourself, except where explained in this manual.
● Provide proper ventilation and air circulation and do not use near water.
● Keep objects that might damage the device and assure that the placement of this unit is on a
stable surface.
● Use only the power adapter and power cords and connection cables designed for this unit.
● Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the device
before cleaning.
TABLE OF CONTENTS
INTRODUCTION..................................................................................................................... 1
FEATURES ............................................................................................................................. 1
PACKAGE CONTENTS .......................................................................................................... 1
SPECIFICATIONS .................................................................................................................. 2
HARDWARE INSTALLATION ................................................................................................ 3
CONNECTION DIAGRAM ...................................................................................................... 3
PANEL DESCRIPTIONS ........................................................................................................ 4
SUPPORTED RESOLUTION ................................................................................................. 5
OPERATION APPROACH ..................................................................................................... 6
EDID LEARNING .................................................................................................................. 19
WARRANTY .......................................................................................................................... 20
EDID LEARNING .................................................................................................................. 19
WARRANTY .......................................................................................................................... 20
