Side 1/44

INSTALLER MANUAL

Pellet Stove

ATENA

PLUS 12/14 - DUKE 12/14 AIRTIGHT- SABA 12/14

MITHOS

PLUS 12/14 - MITHOS PLUS 12/14 PS

New

ATENA - DUKE - SABA - MITHOS

SUMMARY

1 MANUAL SIMBOLOGY ....................................3

2 PACKAGING AND HANDLING ..........................3

2.1 PACKAGING .............................................................3

2.2 REMOVING THE STOVE FROM THE PALLET ..............3

2.3 STOVE HANDLING....................................................4

3 CHIMNEY FLUE .............................................4

3.1 PREPARING THE SMOKE EXPULSION SYSTEM .........4

3.2 CHIMNEY COMPONENTS .........................................4

3.3 SMOKE DUCT (SMOKE FITTING) ..............................5

3.4 FLUE (CHIMNEY OR PIPED DUCT) ...........................5

3.5 CHIMNEY POT ..........................................................6

3.6 MAINTENANCE ........................................................7

4 COMBUSTION AIR .........................................7

4.1 AIR INLET ................................................................7

4.2 COMBUSTIBLE AIR INLET FOR SEALED-CHAMBER

INSTALLATION ...................................................................8

5 EXAMPLES OF INSTALLATION (DIAMETERS AND

LENGTHS TO BE SIZED) ........................................9

6 INSTALLATION ............................................10

6.1 INTRODUCTION .....................................................10

6.2 MINIMUM DISTANCES ........................................... 11

6.3 OVERALL DIMENSIONS .........................................12

6.4 STOVE DOOR REMOVAL/INSTALLATION ................15

6.5 REMOVAL OF CAST IRON COVER AND CAPS (ATENA

PLUS 12/14 - DUKE 12/14 AIRTIGHT) ..............................15

6.6 REMOVAL/ASSEMBLY OF SIDE PANELS (DUKE 12/14

AIRTIGHT - SABA 12/14) .................................................. 16

6.7 REMOVAL/ASSEMBLY OF BACK PANELS (ATENA

PLUS

12/14) ..............................................................................17

6.8 REMOVAL/ASSEMBLY OF TILE PROFILES (ATENA

PLUS 12/14) .....................................................................17

6.9 REMOVAL/ASSEMBLY OF METAL PROFILES (ATENA

PLUS 12/14) .....................................................................18

6.10 TILES ASSEMBLY (ATENA

PLUS 12/14).................18

6.11 METAL FRAME ASSEMBLY (MITHOS

PLUS 12/14) 19

6.12 MOUNTING SERPENTINE STONE FRAME (MITHOS) 20

6.13 REMOVAL OF SIDE PANELS (MITHOS3 PLUS 12/14) 23

6.15 REAR OR UPPER FUME EXHAUST (ATENA PLUS 12/14

- DUKE 12/14 AIRTIGHT - SABA 12/14) ...........................23

6.16 CONCENTRIC PIPE-KIT ASSEMBLY (ATENA PLUS

12/14 - DUKE 12/14 AIRTIGHT - SABA 12/14) .................24

6.17 HOT AIR DUCTING SYSTEM (ATENA

PLUS 12/14 -

DUKE 12/14 AIRTIGHT - SABA 12/14) .............................. 25

6.18 HOT AIR DUCTING (MITHOS3 PLUS 12/14) ...........27

6.19 USING THE STOVE WITHOUT DUCTING (ATENA

PLUS

12/14 - DUKE 12/14 AIRTIGHT - SABA 12/14) .................30

6.20 ELECTRIC CONNECTION .........................................31

6.21 STOVE CALIBRATION AND DEPRESSION

MEASUREMENT ...............................................................31

6.22 CONNECTION TO THE EXTERNAL THERMOSTAT .....32

7 SPECIAL MAINTENANCE ..............................33

7.1 INTRODUCTION .....................................................33

7.2 FUME CHAMBER CLEANING ..................................33

7.3 FUME CONDUIT CLEANING .................................... 34

7.4 FUME PASSAGE CLEANING .................................... 34

7.5 FUME FAN CLEANING ............................................35

7.6 ROOM FAN CLEANING ...........................................36

8 IN CASE OF ANOMALY ..................................36

8.1 PROBLEM SOLVING ...............................................36

9 TECHNICAL DATAS ......................................39

9.1 REPAIR INFORMATION ..........................................39

10 FEATURES ..................................................40

Produkt Specifikationer

Mærke:	Cadel
Kategori:	Komfur
Model:	Atena Plus 14
Antal effektniveauer:	3
Velegnet til rumvolumen på op til:	399 m³
Vekselstrømsindgangsspænding:	230 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	580 mm
Dybde:	580 mm
Højde:	1140 mm
Vægt:	160000 g
Produktfarve:	Black, Red
Strøm:	- W
Pakkevægt:	170000 g
Pakkedybde:	790 mm
Pakkebredde:	790 mm
Pakkehøjde:	1300 mm
Husmateriale:	Cast iron, Steel
Placering af apparat:	Fritstående
Velegnet til værelsesareal på op til:	148 m²
Strømkilde:	Vekselstrøm
Strømforbrug (maks.):	153 W
Fjernbetjent:	Ja
Brændstof, type:	Træpiller
Termostat:	Ja
Placering af udsugning:	Bagside
Pakkevolumen:	690000 cm³
Ovn inkluderet:	Ingen
Programmeringsfunktion:	Ja
Tragt kapacitet:	23 kg
Effektivitet (nominel):	89 %
Effektivitet (reduceret):	93.5 %
Autonomi interval:	7 - 27 t
Træpille forbrug (min.):	0.86 kg/t
Træpille forbrug (maks.):	3.5 kg/t
Gennemsnitligt støvindhold:	15 mg/Nm³
Kulilte (CO) niveau (nominel):	0.0197 %
Røggas temperatur:	210 °C
Røggas (maks.):	10 Pa
Kulilte (CO) niveau (reduceret):	0.0149 %
Strømforbrug (antænding):	360 W
Varmetilførsel (nominel):	14 kW
Varmetilførsel (reduceret):	3.8 kW
Træpille diameter understøttet (maks.):	6 mm
Ekstern termostat:	Ja
