Cadel Zefiro 9 Manual

Cadel Komfur Zefiro 9

Læs gratis den danske manual til Cadel Zefiro 9 (43 sider) i kategorien Komfur. Denne vejledning er vurderet som hjælpsom af 13 personer og har en gennemsnitlig bedømmelse på 4.7 stjerner ud af 7 anmeldelser. Har du et spørgsmål om Cadel Zefiro 9, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/43

INSTALLER MANUAL

Pellet Stove

ZEFIRO - ZEN - PONENTE - ZENITH

SUMMARY

1 MANUAL SIMBOLOGY ....................................3

2 PACKAGING AND HANDLING ..........................3

2.1 PACKAGING .............................................................3

2.2 REMOVING THE STOVE FROM THE PALLET ..............3

2.3 STOVE HANDLING....................................................4

3 CHIMNEY FLUE .............................................4

3.1 PREPARING THE SMOKE EXPULSION SYSTEM .........4

3.2 CHIMNEY COMPONENTS .........................................4

3.3 SMOKE DUCT (SMOKE FITTING) ..............................5

3.4 FLUE (CHIMNEY OR PIPED DUCT) ...........................5

3.5 CHIMNEY POT ..........................................................6

3.6 MAINTENANCE ........................................................7

4 COMBUSTION AIR .........................................7

4.1 AIR INLET ................................................................7

4.2 COMBUSTIBLE AIR INLET FOR SEALED-CHAMBER

INSTALLATION ...................................................................8

5 EXAMPLES OF INSTALLATION (DIAMETERS AND

LENGTHS TO BE SIZED) ........................................9

6 INSTALLATION ............................................10

6.1 INTRODUCTION .....................................................10

6.2 MINIMUM DISTANCES ........................................... 11

6.3 INSULATING MATERIAL ......................................... 12

6.4 OVERALL DIMENSIONS .........................................13

6.5 INSERT EXTRACTION .............................................17

6.6 INSERT REMOVAL ..................................................17

6.7 INSTALLATION WITH EXTERNAL COVER ................18

6.8 INSTALLATION ON EXISTING FIREPLACE ...............20

6.9 DOOR ADJUSTMENT (ZEN - ZEFIRO) ....................22

6.10 DOOR ADJUSTMENT (PONENTE - ZENITH) ............ 22

6.11 CONNECTION TO THE EXTERNAL THERMOSTAT .....22

6.12 ELECTRIC CONNECTION .........................................23

6.13 AIR REGULATOR ....................................................23

6.14 INSERT LEGS INSTALLATION (OPTIONAL) .............24

6.15 HOT AIR DUCTING (OPTIONAL ONLY FOR ZEFIRO) 25

6.16 PELLET DRAWER INSTALLATION (OPTIONAL) ....... 27

6.17 TRAPDOOR INSTALLATION (OPTIONAL) ................29

6.18 FRAME INSTALLATION (OPTIONAL) ......................31

6.19 CONCENTRIC PIPE INSTALLATION .........................32

6.20 DISPLAY ROTATION ...............................................32

7 WI-FI KIT INSTALLATION .............................33

8 SPECIAL MAINTENANCE ..............................34

8.1 INTRODUCTION .....................................................34

8.2 FEED SCREW MAINTENANCE.................................34

8.3 ROOM FAN CLEANING ...........................................35

8.4 FLUE GAS EXTRACTOR CLEANING..........................36

8.5 FUME PASSAGES CLEANING ..................................36

8.6 FUME CHAMBER CLEANING ..................................37

8.7 SMOKE DUCT CLEANING .......................................38

8.8 GLASS REPLACEMENT ...........................................39

9 IN CASE OF ANOMALY ..................................39

9.1 PROBLEM SOLVING ...............................................39

10 TECHNICAL DATAS ......................................41

10.1 FUSE REPLACEMENT .............................................41

11 FEATURES ..................................................42

Produkt Specifikationer

Mærke:	Cadel
Kategori:	Komfur
Model:	Zefiro 9
Velegnet til rumvolumen på op til:	265 m³
Vekselstrømsindgangsspænding:	230 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	715 mm
Dybde:	790 mm
Højde:	750 mm
Vægt:	94000 g
Produktfarve:	Sort
Kontroltype:	Knapper
Strøm:	- W
Pakkevægt:	106000 g
Husmateriale:	Aluminium, Cast iron
Placering af apparat:	Indbygget
Velegnet til værelsesareal på op til:	98 m²
Strømkilde:	Vekselstrøm
Strømforbrug (maks.):	113.7 W
Fjernbetjent:	Ja
Brændstof, type:	Træpiller
Udsugningsforbindelse, diameter:	80 mm
Placering af udsugning:	Top
Ovn inkluderet:	Ingen
Programmeringsfunktion:	Ja
Tragt kapacitet:	15 kg
Effektivitet (nominel):	88.4 %
Effektivitet (reduceret):	94.2 %
Autonomi interval:	6.9 - 25 t
Træpille forbrug (min.):	0.59 kg/t
Træpille forbrug (maks.):	2.17 kg/t
Gennemsnitligt støvindhold:	19.2 mg/Nm³
Kulilte (CO) niveau (nominel):	0.012 %
Røggas temperatur:	197 °C
Røggas (maks.):	11.9 Pa
Kulilte (CO) niveau (reduceret):	0.024 %
Strømforbrug (antænding):	346 W
Varmetilførsel (nominel):	9.3 kW
Varmetilførsel (reduceret):	2.7 kW
Træpille diameter understøttet (maks.):	6 mm
Ekstern termostat:	Ja
