Café CDT828P2VS1 Manual

Café Vaskemaskine CDT828P2VS1

Læs gratis den danske manual til Café CDT828P2VS1 (2 sider) i kategorien Vaskemaskine. Denne vejledning er vurderet som hjælpsom af 73 personer og har en gennemsnitlig bedømmelse på 4.4 stjerner ud af 37 anmeldelser. Har du et spørgsmål om Café CDT828P2VS1, eller vil du spørge andre brugere om produktet?

Download PDF
Side 1/2
Café™ CustomFit Stainless Interior
Built-In Dishwasher with Hidden Controls
CDT828P2VS1
CDT828P2VS1
Fingerprint Resistant
Stainless Steel with
Brushed Stainless Handle
FEATURES & BENEFITS
CustomFit Top Rack – Load your way in this dishwasher with a
customizable top rack. The sliding top rack provides loading flexibility with a place to
load silverware, spatulas, ramekins, lids and more, so you can wash everything at once.
CustomFit Basket – Load more than just silverware in this redesigned basket. The
stylish CustomFit Basket holds all your silverware, 9" tall delicate stemware, reusable
straws and more, so items that were hand-washed before can safely be washed in
the dishwasher.
Ultra Wash & Dry – This ultra-wash and dry dishwasher ensures table-ready dishes.
Ranging from gentle for delicate stemware to intense for pots and pans, flexible wash
options ensure that dishes get full coverage and the right amount of pressure for an
ideal clean.
4 Bottle Wash Jets – This dishwasher with 4 bottle wash jets ensures a deep clean
for tall items, narrow glasses, jars and more. In the upper rack, each of the jets directs
water and detergent inside to eectively wash hard-to-reach areas.
Customizable Dishwasher Handles – Choose from six unique Café handle finishes
to complement the rest of your kitchen thanks to this dishwasher with customizable
hardware.
Favorites – Easily save your favorite wash and dry option combinations to the
'Favorites' button on your control panel for convenient and quick access at the touch
of a button.
Adjustable Middle Rack – Load the dishwasher your way thanks to an adjustable
middle rack. Easily move it up and down to fit bottles, large platters and other items as
tall as 10.5".
Presoak – Loosen tough soils with a presoak cycle that runs before the wash cycle
begins, so you can skip the need to pre-rinse or soak items by hand.
Sanitize – Enjoy piece of mind with a sanitization cycle that reduces up to 99.999%
of bacteria on dishes.
Middle and Lower Rack Fold-Down Tines – Two rows of adjustable tines in both
the middle and lower rack allow you to load the way you want. Sixteen dierent tine
positions oer the ultimate customization to fit all of your items.
Active Flood Protect – Active Flood Protect prevents potential overflows for greater
peace of mind. It works by using a water leak detector to sense when water is too high,
pumping it out until a safe level is reached.
Flush Installation – Cabinet-depth flush installation ensures your dishwasher blends in
with the design of your kitchen without sacrificing space for dishes inside.
Piranha™ Hard Food Disposer – The Piranha™ Hard Food Disposer lets you use your
dishwasher without pre-rinsing. Its stainless steel impellers rotate to pulverize food
particles and an anti-jamming design make sure wash arms stay unclogged.
42 dBA Dishwasher – Enjoy a peaceful kitchen while delivering a powerful wash
thanks to this super-silent 42 dBA dishwasher.
FEATURES
Style Built-In
Tub and Door Liner Stainless Steel
Tub Type Tall Tub
Control Type Top Controls; Cap Touch Controls; 8 Touchpads
Dishwasher Control Features
Audible End-of-Cycle Signal: Cycle Countdown with Bi-Color
LED Status Light on door; Cycle Progress Indicators: Clean/
Sanitized/Smart Assist/WiFI/Remote Enabled; Last Cycle
Memory; Fingerprint Resistant
Wash System 3-Level; 800 Series
Wash System Features
Automatic HotStart; Automatic Temperature Control; Bottle
Jets (4); Hard Food Disposer with removable filter; Lower
Wash Arm; Middle Wash Arm; Variable Speed Dual Pumps
and Motors
Sensor Clean Sensor
Wash Arms 3 Wash Levels; Bottle Jets; Lower; Middle; Upper
Water Filtration System 100% Filtration with Hard Food Disposer and Removable Filter
Dispenser Rinse Aid with Indicator and Adjustment
Number of Cycles 5
Dishwasher Cycles Auto; Cookware; Express; Gentle; Normal
Number of Options 15
Dishwasher Options
1/2 Load (on app); Bottle Wash (on app); Delay Start 1-12 Hr.;
Favorites (on app); Heated Dry O; Hi-Temp Wash; Lock
Controls; Normal Dry; Pre Soak; Sabbath Mode; Sani (Certified
to NSF Standard 184); Start/Cancel; Ultra-Dry; WiFi/Remote
Enabled
Rack Features
Adjustable Upper Rack; Ball-Tipped Tines; Cafe Flex
Silverware Basket
Racking Material Nylon
Rack Color Black Pearl
Number of Place Settings Up to 16
Upper Rack
P1 Rack handle; 1/2 fixed tines, 1/2 fold down tines; Adjustable;
Ball-Tip Tines; Fixed tines with Bottle Jets; Removable
Lower Rack
Heated Dry - Ultra/Normal/O; Multi-Wattage Wash & Dry
Element; UltraDry
Additional Protection Active Flood Protect; Leak Defense with Active Flood Protect
Dishwasher Drying Features Ultra Dry; Ultra/Normal/O
Cutlery Tray One piece removable 3rd rack; CustomFit Top Rack
Leveling System 4 Leveling Legs
Latch Pull Handle
WiFi Connect Optional (Requires part no. PBX23WOOYO)
Exterior Style Traditional
ECONOMICAL/QUIET
Quiet Package 42 dBA
Quiet Features Quiet Water Valve; Sealed Toe Kick; Tub Collar Trim
Motor Type Variable Speed
Outer Wrap Full-Wrap Blanket; Bitumen
Door Insulation Insulation; Mastic
WEIGHTS & DIMENSIONS
Cabinet Width 24 in
Approximate Shipping Weight 137 lb
Net Weight 124 lb
Overall Height 34 in
Height w/Legs Retracted -
Minimum Height 33-3/8 in
Height w/Legs Extended -
Maximum Height 34-5/8 in
Overall Depth 24 in
Overall Width 23-3/4 in
APPEARANCE
Door Style Long Door with Top Controls
Installation
Side Installation or Top Installation Included; Built-Up Floor
Capable; Flush Cabinet Installation
Door Appearance Full-length flat door
Certified to NSF
Standard 184 for
sanitization
CERTIFIED
SAFETY US CA
SANITATION US
Café™ CustomFit Stainless Interior
Built-In Dishwasher with Hidden Controls
CDT828P2VS1
DIMENSIONS
ADDITIONAL ACCESSORIES
INSTALLATION DIMENSIONS
For answers to your Café™ product questions, visit our website at cafeappliances.com.
This Wall Area
must be Free
of Pipes or
Wires
33-1/2" to 34-3/4"
Underside of
Countertop
to Floor
Figure A
Cabinets
Square
and
Plumb
24"
Min.
4"
6"
Plumbing and Electric Service
Must Enter Inside This Area
24"
Min.
© 2023 GE Appliances 09/23
TECHNICAL DETAILS
Calrod Heater Watts 1200/400
Power Connection
Optional cord kit (GPFCORD - WX09X70910,
WX09X70911)
Volts/Hertz/Amps 120 V; 60 Hz; 7.8 A
WARRANTY
Parts warranty Limited 1-year entire appliance
Labor warranty Limited 1-year entire appliance
Warranty notes See written warranty for full details
Overall depth including
handle: 26.3"
4" (toekick)
24"
Typical
23-3/4"
29-7/8"
27-1/2"
33-3/8" MIN.
adj to
34-5/8" MAX.
CXADTH1PVBT ACC
Brushed Black
Handle Kit
CXADTH1PVBZ ACC
Brushed Bronze
Handle Kit
(Standard on
Matte White)
CXADTH1PVCU ACC
Brushed Copper
Handle Kit
CXADTH1PVSS ACC
Brushed SS
Handle Kit
(Standard on
Matte Black and
Stainless Steel)
CXADTH1PVCG ACC
Brushed Brass
Handle Kit
CXADTH1PVFB ACC
Flat Black
Handle Kit
