Side 1/4
KXX-100_ii_230228 Pg 1
1
K10-100(SQ)/101(SQ)/102(SQ)/103(SQ),
K30-100(SQ)/101(SQ)/102(SQ)/103(SQ)
K51-100(SQ)/101(SQ)/102(SQ)/103(SQ),
K50-100/101/102/103 & K80-100/101/102
Kitchen/Prep Pull-Down Faucet Installation Instructions
IMPORTANT: Read all instructions prior to installation and provide copy of instructions to consumer.
Operating Specifications:
Recommended Supply Pressure: 20 to 70 psi
*†
* Operating pressures between hot and cold supplies should vary no more than 30 psi.
† If water pressure exceeds 70 psi, install a Pressure-Reducing Valve (PRV).
INSTALLING TO SINK/DECK
• Place BASE (2) with O-RING (3) onto BODY (1)
• Slide INLET HOSES (4) and SPRAY-HOSE (5)
through sink/deck hole
• From underside slide SPACER (6a), in necessary,
MOUNT (6) and NUT (7) onto SHANK (1a);
loosely tighten NUT (7)
• From topside position BODY (1) with handle on
right side as shown and from underside securely
tighten NUT (7)
Position MOUNT (6)
to prevent rubbing of
SPRAYER HOSE (5)
CALIFORNIA FAUCETS RECOMMENDS THAT ALL PLUMBING PRODUCTS BE INSTALLED
BY A LICENSED PROFESSIONAL
Ø1-3/8”
IMPORTANT: The recommended sink/deck through-hole shall
be Ø1-3/8”. Maximum sink/deck thickness should no greater than
2-1/4”
IMPORTANT: Based on sink/deck thickness the use of SPACER
(6a) needs to be determined. If thickness is LESS than ½” use
SPACER (6a), if GREATER than ½” use only MOUNT (6).
IMPORTANT: Position MOUNT (6) so that SPRAY-HOSE (5)
does NOT rub against MOUNT (6) when SPRAYHEAD (8) is
pulled.
