Minx Air100/200 Wireless music system
Wi-fi set-up
3
Go to your computer and click on the
WiFi/network logo and select Minx Air_XXX.
2
6
Mac
PC
iPad
Open a new page in your internet browser (Internet Explorer, Safari,
Chrome etc). In the address bar of your browser, type 192.168.1.1
followed by ‘enter’ and the Minx Air setup page will be displayed.
If you are happy that you have entered your details correctly, click
‘OK’ to finish.
The Minx Air set-up page may now display an ‘error’ or ‘no data
received’ type message. Don’t worry, this is normal. You can now
close your internet browser.
4Select your home Wi-Fi network from the ‘Service Set ID (SSID)’
drop-down list of choices. Made a mistake?
To reset the Minx Air, press and hold the power button
and WPS button on the rear panel for 10 - 15 seconds
until the Minx Air switches off. Then start again at Step 1.
You can also watch the Minx Air connection videos on
the Cambridge Audio website for further explanation.
5Type your home Wi-Fi/Network password into the red box,
and click the ‘Apply’ button.
(Don’t know your Wi-Fi password key? It’s commonly found on
a label on your internet modem/router)
7After a few seconds, the Minx Air will be connected to your
network (successful connection is indicated by a solid green light
on the rear of the product). This can take up to 30 seconds.
(If your computer/tablet has not already done so automatically, change the
Wi-Fi/network setting on your computer/tablet back to your home network).
Connect the Minx Air to the mains power and press the power
button on top of the unit. Wait for up to 20 seconds for the
flashing light on the rear panel to flash green and orange
1
iTunes
iPad
iPhone
To enjoy Airplay and internet radio, you must first
connect your Minx Air to your home network.
If you have a laptop computer, tablet, or any
other wi-fi enabled internet browser go to Step 1
below to connect to your home network.
If you have no wi-fi enabled internet browser
(such as a desktop computer) then please see the
online user manual for wired set-up instructions.
Airplay
Congratulations! You are now ready to stream music via Airplay.
When you open iTunes or your Music you will see the
Airplay logo allowing you to select your Minx Air as the
playback device.
Note – when Minx Air is selected, it will take a few seconds
to connect.
Wait for the music to start playing before adjusting the volume.
