© 2022.10 CANON INC. BT1-D030-A-ENG
Lens Accessory
Studio Conversion Kit
MS-15
2. System conguration
[Attaching focusing group]
1.Insert the guidepinor xingscrew ofthe exiblefocus module<FM-12> into
theguideholeorxingscrewhole.Makecertainthegearonthefocusringof
thelensbodyengagestheoneontheexiblefocusmodule.
2.Loosen thetwo fastening knobs of the flexible focus controller FFC-15,
mountthemonthepanhandle,andtightentheknobs.
3.Make sure the focus ring on the lens body rotates by rotating the grip of the
exiblefocuscontroller.
NOTE
Whenoperatingthelensusingtheexiblefocusmodule,removethezoom
lever.Besuretokeepitinasafeplacesoasnottolooseit.
[Attaching zooming group]
1.Loosenthetwofasteningknobsontheclamper,mounttheclamperonthepan
handle,andtighentheknobs.
2.Engage the rose jointofthe zoom demand <ZSD-15MII> and that of the
clamper,andthentighenthemwiththeclampermountingknob.
3.Connect the connector of the the zoom demand to the remoteconnector on
the lens body. Be sure to fit the positioning pin properly when plugging the
connectorin.
1. Product List
Zoomdemand(ZSD-15MII)1
Flexiblefocuscontroller(FFC-15)1
Flexiblefocusmodule(FM-12)1
Flexiblecable(FC-40) 1
Clamper1
OperationManual
OperationManual“Regulations”
[Focusing operation]
Tofocus,rotatethegripoftheexiblefocuscontroller.
Rightrotation:Tominimumobjectdistance
Leftrotation:Tomaximumobjectdistance
[Zooming operation]
Set the zoom operation change-over knob at the bottom of the lens drive
unittothe<SERVO>position.Thissettingoperationcanbeperformedmore
smoothlyiftheknobismovedwhilerotatingthezoomringslightly.
1. Basic Operation
< Zooming operation / Rocker seesaw operation >
Tocontrolthezoomingspeed,usetherockerseesawontheservozoomgrip.
The zooming speed changes according to how deep you press the seesaw.
Thedeeperyoupresstheseesaw,thefasterthezoomingspeedbecomes.
2. Applied operations
RETswitchandVTRswitch
OneRET switch and one VTR switch are installed on the zoom demand.
These switches are equivalent to those on the lens drive unit. While RET
switchishelddown,onairpicture/beingrecordedpicture canbeseeninthe
viewnderthroughcameracontrolsystemwhenmulticamerasareconnected
toitssystem.
PressVTRswitchtoexecutetheoperationofVTR.
Beforeusingtheproduct,makesuretoreadthe""GENERALSAFETY
INFORMATION"andbesuretousetheproductcorrectly.
Thankyouforpurchasingastudioconversionkit<MS-15>.
ENG OPERATION MANUAL
3. Mounting and connecting 4. Operation
W
T
8
1
1
16
C
4
5.6
1.8
2.8
20
8.5
80
170
40
1
.7
2.5
4
7
m
4
.5
8
6
20
50
f t
12
IRIS
RET
VTR
Shtl
Fixing Screw Hole
Lens
Drive Unit
Fixing Knob
Flexible Focus Module
Flexible Cable
《FC-40》
Mounting Knob
Rocker Seesaw
Grip
Fastening Knobs
Zoom Demand
Fastening Knobs
Flexible Focus Controller
《FFC-15》Clamper
Zoom
Lever
《
FM-12》
《 II》ZSD-15M
2/2
© 2022.10 CANON INC. BT1-D030-A-ENG
GENERALSAFETYINFORMATION
Thesafety warnings and cautions provided on the productor in this operation manual mustbe observed.Failure to
observethesewarningsand cautionsprovidedfor thepurposeofhazardpreventionmayresultininjuriesoraccidents.
Readthismanualcarefullytofamiliarizeyourselfwith itscontentsandtoensureproper operation of thisproduct.Also,
keepthismanualinasafeplacewhereitcaneasilybereferencedwheneverrequired.
This manualuses thefollowing symbolsand termsin the warning and cautionnotices forpreventing accidents and
protectingthesafetyofthecustomerandothers.
WARNING
This indicatesapotentiallyhazardous situation which, ifnot heeded,may resultin deathor
seriousinjurytoyouorothers.Besuretoheedallwarningnoticestoensuresafeoperationat
alltimes.
CAUTION
Thisindicatesapotentially hazardoussituationwhich,ifnotheeded,may resultinaminor
injurytoyouorothers,ordamagetoproperty.Besuretoheedallcautionnoticestoensure
safeoperationatalltimes.
NOTE
This indicates cautions and recommendations for operation. This contains essential
informationwhich,ifnotheeded,mayresultinthisproductfailingtofunctionproperly.These
noticesalsocontainusefulinformationforoperation.
HANDLINGTHEPRODUCT
WARNING
1. Donotgetthisproductwetorallowliquidinside.Ifwatergetsinside,stopusingtheproductimmediately.Otherwise
itmaycauseareorelectricshocks.
2.Besuretoholdtheconnectorwhendisconnectingthecable.Pullingonthecablemayseverordamageitandpose
ariskofareorelectricshocksfromashortcircuit.
3. Donotdamage,destroyormodifythecable.Donotplaceheavyobjectsonit,steponit,forciblybendorbundle
thepowercable.Powermayleakfromadamagedcable,resultinginareorelectricshocks.
CAUTION
1. Becarefulnottodroptheproductwhencarryingit.Droppingtheproductmaycauseinjury.
2.Ensurethatallmountingsaresecurelytightened.Ifamountingbecomesloose,partsmayfallo󰀨andcauseinjury.
3.Inspect mountings regularly (aboutevery six months to oneyear)to ensuretheyare securelytightened.If a
mountingbecomesloose,partsmayfallo󰀨andcauseinjury.
NOTE
1. Do not expose the product to strong impact. Striking or dropping the product may cause the malfunction of the
product.
2. Thisproductisnotwaterproof.Takemeasurestoavoiddirectcontactwithrain,snow,ormoisture.Otherwiseitmay
causethemalfuctionoftheproduct.
3. In dusty environments, cover the product when attaching or removing the product. If dust enters inside, it may
causethemalfunctionoftheproduct.
4. Beforeuseinparticularenvironments,suchasplaceswherechemicalproductsareused,contactyourCanonsales
representativeordealer.
DEALINGWITHABNORMALITIES
WARNING
Ifanyofthefollowingsituationsoccurs,immediatelydisconnectthecablefromthelensandthecameraandcontact
yourCanonsalesrepresentativeordealer.
・
Smoke,fumes,orunusualnoisescomingfromtheproduct
・
Foreignobjects(suchasliquidormetalobjects)insidetheproduct
MAINTENANCEANDINSPECTION
WARNING
Besureto disconnect thecable andremovetheproductfromthelensandthecamerabeforecleaning outsideofthe
product.Donotusebenzene,thinner,orotherammablesubstancestocleanthisproduct.Thismaycausereorelectric
shock.
NOTE
 Routineinspectionaboutonceayear isrecommended,dependingontheconditionsandenvironmentofuse.Request
overhaul,ifneeded.
STORAGE
NOTE
 Immediatelywipeo󰀨anymoistureonthelensfrommistyorfoggyenvironments,usingadrycloth.Sealthelensin
aplasticbagwithadesiccant(preferablynew)topreventmoistureinside.Otherwiseitmaycausethemoldorthe
malfunctionoftheproduct.
TOTHECUSTOMER
1. Canonshallbearnoresponsibilityfordamageresultingfromimproperoperationofthisproductbythecustomer.
2. Canonshallmakenoguaranteesabouttheproductquality,functions,oroperationmanualanditsmarketabilityand
suitabilityforthecustomer’spurpose.
Moreover,Canonshallbearnoresponsibilityforanydamage,directorincidental,thatresultsfromusageforthe
customer’spurpose.
3.Theproductspecications,conguration,andappearancearesubjecttochangewithoutpriornotice.
4.For further information on repairs, maintenance, or adjustments not mentioned in this operation manual, contact
yourCanonsalesrepresentativeordealer.
5.Note that Canon may be unable to undertake servicingor repair of aproduct ifit ismodied without consulting
CanonoryourCanonsalesrepresentative.
Allrightsreserved.Nopartofthisoperationmanual
maybereproducedorcopiedinanyfromorbyany
meanswithoutthewrittenpermissionofCanonInc.
CANONINC.
30-2,Shimomaruko3-chome,Ohta-ku,Tokyo146-8501,Japan
