Clamper
《CR-10》
Flexible focus
module
《
FFM-100》
Flexible cable
《
FC-40》
Zoom demand
《ZSD-300D》
Flexible focus
controller
《FFC-200》
Fixing knob
Zoom speed control knob
Frame switch
RET switch
Thumb ring
Fastening knobs
Mounting knob
Reverse switch
Memo switch
Shtl switch
VTR Switch
Fastening knobs
Mounting knob
Clamper
《CR-10》
1x
2x
■
■
■
■
■
■
■
■
■
■
■
■
■
■
ft
m
■
■
■
■
■
Drive unit
Fixing screw
Lens
Zoom
Lever
1/2
© 2022.10 CANON INC. BT1-D023-A-ENG
Zoom demand (ZSD-300D) Flexible focus controller (FFC-200)
Flexible focus module (FFM-100) Flexible cable (FC-40)
Clamper 2pcs (CR-10)
Operation Manual
1　PRODUCT COMPONENTS
Lens Accessory
Studio Conversion Kit
MS-210D
2　SYSTEM CONFIGURATION 3　MOUNTING
[Attaching focusing group]
1.Inserttheguidepinorxingscrewoftheexiblefocusmodule<FFM-100>intothe
guideholeorxingscrewhole.Makecertainthegearonthefocusringofthelens
bodyengagestheoneontheexiblefocusmodule.
2.Loosen the twofastening knobs oftheclamper <CR-10>and mountthe clamper
onthepanhandle,thentightentheknobs.
3.Engage the rose joint of the flexible focus controller <FFC-200>and that of the
clamper,andthentighenthemwiththemountingknoboftheclamper.
4.Finally,makecertainthefocusringonthelensbodyrotatesbyrotatingthegripof
theexiblefocuscontroller.
NOTE
Beforeattachingtheexiblefocusmoduletothelens,removethezoomlever.
Besuretokeepitsoasnottoloseit.
[Attaching zooming group]
1.Loosenthetwofasteningknobsoftheclamperandmounttheclamperonthepan
handle,thentighentheknobs.
2.Engage the rosejoint ofthe zoom demand<ZSD-300D>and thatof the clamper,
andthentighenthemwiththemountingknoboftheclamper.
3.Connect the remote connectoron the lens body with the cable connector from
the zoom demand using the connecting cable. Be sure to t the positioning pin
properlywhenpluggingtheconnectorin.
Thankyouforpurchasingastudioconversionkit<MS-210D>.
The studio conversionkit <MS-210D> suppliesall theaccessories necessaryto
convert cameras mounted with digital drive unit loadinglens into “rear view” TV
cameras that can be mounted on a tripod.
Whenusingthelensofanalogdriveunitloading,aconversioncable<CC-0820>is
needed separately.
In that case, a part of the function is restricted.
Beforeusingtheproduct,makesuretoreadthe"GENERALSAFETYINFORMATION"
and be sure to use the product correctly.
ENG OPERATION MANUAL
Operation ManualOperation Manual
(Regulations)
2/2
© 2022.10 CANON INC. BT1-D023-A-ENG
4
　
OPERATION
[Focusing operation]
Tofocus,rotatethegripoftheexiblefocuscontroller.
Clockwiserotation:Tominimumobjectdistance
Counterclockwiserotation:Tomaximumobjectdistance
[Zooming operation]
Setthezoomoperationchange-overknobatthebottomofthelensdriveunitto
the<SERVO>position.Thissettingoperationcanbeperformedmoresmoothlyif
theknobismovedwhilerotatingthezoomringslightly.
1. Basic Operation
< Zooming operation / Thumb ring operation >
Thezoom functionis controlledby turningthe thumbring ofthe zoomdemand.
Howmuchthethumbringisrotateddeterminesthezoomingspeed.Thezooming
speedvariesaccordingtotherotationangleofthumbring.
< Adjusting the max. zoom speed. >
Thamax. zoomspeed, obtained by completelyturning the thumbring of the
zoomdemand,ischangeablewiththezoomspeedcontrolknob.
Turningthisknobclockwise,fasterspeedcanbeobtained.
Turningthisknobcounterclockwise,lowerspeedcanbeobtained.
< To change the zooming direction >
Thethumbringofthezoomdemandisfactorysettozoomin(telephoto),whenit
ispressedtowardtheright.
However, this zoom direction may be changed by switching the position of the
reverseswitch.
2. Applied operations
Function1:Shuttleshot
This comesin handy forshots involving frequentswitching between twopicture
angles.
Function2:Framingpreset
Thismakesiteasytoreproduceapresetpictureangleandzoomspeedduringa
rehearsal, etc.
Function3:Speedpreset
This presets the zoom speed during a rehearsal, etc. and enables the preset
speed to be reptoduced repratedly.
The <Shtl> switch, <Frame> switch and <Memo> switch as well as the <VTR>
switch and <RET> switch on the zoom demand which are used for these
operations correspond to their counterparts on the lens unit. However, the DIP
switchesonthelensunitwhichareusedtoperformvarioussettingsmustbeset
to their proper positions.For further details on operation and functions, refer to the
lens operation manual.
RETswitchandVTRswitch
OneRETswitchandoneVTRswitchareinstalled onthezoomdemand.These
switchesareequivalenttothoseonthelensdriveunit.WhileRETswitchisheld
down,onairpicture/beingrecordedpicturecanbeseenintheviewnderthrough
camera control system when multi cameras are connected to its system. Press
VTRswitchtoexecutetheoperationofVTRandpressagaintostoptheoperation
ofVTR.
GENERALSAFETYINFORMATION
The safetywarnings and cautions provided onthe product or inthis operation manual mustbe observed. Failure to
observethese warningsandcautions providedfor thepurposeof hazardprevention mayresult ininjuries oraccidents.
Read thismanualcarefully tofamiliarize yourselfwithits contents andto ensureproper operationof thisproduct.Also,
keepthismanualinasafeplacewhereitcaneasilybereferencedwheneverrequired.
This manualuses the following symbols andterms in the warningand caution notices forpreventing accidents and
protecting the safety of the customer and others.
WARNING
This indicatesa potentiallyhazardous situationwhich,if not heeded, mayresult in deathor
seriousinjurytoyouorothers.Besuretoheedallwarningnoticestoensuresafeoperationat
all times.
CAUTION
This indicatesa potentially hazardous situationwhich, if notheeded,may resultin aminor
injury to you or others, or damage to property. Be sure to heed all caution notices to ensure
safe operation at all times.
NOTE
This indicates cautions and recommendations for operation. This contains essential
informationwhich,ifnotheeded,mayresultin thisproductfailing tofunctionproperly.These
notices also contain useful information for operation.
HANDLINGTHEPRODUCT
WARNING
1. Do not get this product wet or allow liquid inside. If water gets inside, stop using the product immediately.
Otherwiseitmaycauseareorelectricshocks.
2.Besuretoholdthe connectorwhendisconnectingthecable.Pulling onthecablemaysever ordamageitand
poseariskofareorelectricshocksfromashortcircuit.
CAUTION
1. Becarefulnottodroptheproductwhencarryingit.Droppingtheproductmaycauseinjury.
2.Ensurethatallmountingsaresecurelytightened.Ifamountingbecomesloose,partsmayfallo󰀨andcauseinjury.
3. Inspect mountings regularly (about every six months to one year) to ensure they are securely tightened. If a
mountingbecomesloose,partsmayfallo󰀨andcauseinjury.
NOTE
1. Do not expose the product to strong impact. Strikingordropping theproductmaycausethemalfunction ofthe
product.
2. Thisproductisnotwaterproof.Takemeasurestoavoiddirect contactwithrain,snow,ormoisture. Otherwiseit
may cause the malfuction of the product.
3. Industy environments,coverthe productwhen attachingor removingthe product.Ifdust entersinside, itmay
cause the malfunction of the product.
4. Beforeuse in particular environments, such as placeswhere chemicalproducts are used, contact yourCanon
salesrepresentativeordealer.
DEALINGWITHABNORMALITIES
WARNING
Ifanyofthefollowingsituationsoccurs,immediatelydisconnectthecablefromthelensandthecameraandcontact
yourCanonsalesrepresentativeordealer.
・
Smoke,fumes,orunusualnoisescomingfromtheproduct
・
Foreignobjects(suchasliquidormetalobjects)insidetheproduct
MAINTENANCEANDINSPECTION
WARNING
Besureto disconnectthecableandremove theproductfromthelens andthecamerabefore cleaningoutsideofthe
product.Donotusebenzene,thinner,orotherammablesubstancestocleanthisproduct.Thismaycausereorelectric
shock.
NOTE
Routineinspectionaboutonceayearisrecommended,dependingontheconditionsandenvironmentofuse.Request
overhaul,ifneeded.
STORAGE
NOTE
Immediatelywipeo󰀨anymoistureonthelensfrommistyorfoggyenvironments,usingadrycloth.Sealthelensin
aplasticbagwithadesiccant(preferablynew)topreventmoistureinside. Otherwiseitmaycausethemoldorthe
malfunction of the product.
TOTHECUSTOMER
1. Canon shall bear no responsibility for damage resulting from improper operation of this product by the customer.
2. Canonshallmakenoguaranteesabouttheproductquality,functions,oroperationmanualanditsmarketability
and suitability for the customer’s purpose.
Moreover,Canonshallbearnoresponsibilityforanydamage,directorincidental,thatresultsfromusageforthe
customer’s purpose.
3.Theproductspecications,conguration,andappearancearesubjecttochangewithoutpriornotice.
4. For further information on repairs, maintenance, or adjustments not mentioned in this operation manual, contact
yourCanonsalesrepresentativeordealer.
5.NotethatCanonmaybeunabletoundertakeservicingor repair of a productifitismodied withoutconsulting
CanonoryourCanonsalesrepresentative.
Allrightsreserved.Nopartofthisoperationmanual
may be reproduced or copied in any from or by any
meanswithoutthewrittenpermissionofCanonInc.
CANONINC.
30-2,Shimomaruko3-chome,Ohta-ku,Tokyo146-8501,Japan
