Side 1/48
Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.
Catalog No. 04-53300176-01 Printed in U.S.A. Form 30HX-16SI Pg 1 12-17 Replaces: 30HX-14SI
Installation Instructions
CONTENTS
Page
SAFETY CONSIDERATIONS . . . . . . . . . . . . . . . . . . . . . . .1
INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-46
Step 1 — Inspect Shipment . . . . . . . . . . . . . . . . . . . . . . . . 2
Step 2 — Rig and Place Unit. . . . . . . . . . . . . . . . . . . . . . . . 2
Step 3 — Piping Connections . . . . . . . . . . . . . . . . . . . . . .17
COOLER FLUID, VENT, AND DRAIN
BRINE UNITS
PREPARATION FOR YEAR-ROUND OPERATION
FILL FLUID LOOP
INSULATE COOLER HEADS
30HXA PIPING, VALVE, AND FAN CYCLING
PRESSURE SWITCH INSTALLATION
30HXC PIPING AND VALVE INSTALLATION
INSTALL PRESSURE RELIEF REFRIGERANT VENT
PIPING
Step 4 — Make Electrical Connections . . . . . . . . . . . . .24
FIELD POWER CONNECTIONS
FIELD CONTROL POWER CONNECTIONS
CONDENSER FAN CONTROL FOR CONDENSER
UNITS USED WITH 30HXA UNITS
Step 5 — Install Accessories . . . . . . . . . . . . . . . . . . . . . . 29
30HXA LOW-AMBIENT OPERATION
MINIMUM LOAD ACCESSORY
MISCELLANEOUS ACCESSORIES
Step 6 — Leak Test Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
30HXC UNITS
30HXA UNITS
Step 7 — Refrigerant Charge . . . . . . . . . . . . . . . . . . . . . . .42
30HXC UNITS
30HXA UNITS
Step 8 — BACnet Communication Option Wiring . . .44
SAFETY CONSIDERATIONS
Installing, starting up, and servicing this equipment can
be hazardous due to system pressures, electrical components,
and equipment location. Only trained, qualified installers and
service mechanics should install, start up, and service this
equipment.
When working on the equipment, observe precautions in
the literature and on tags, stickers, and labels attached to the
equipment.
Follow all safety codes.
Wear safety glasses and work gloves.
Use care in handling, rigging, and setting bulky
equipment.
IMPORTANT: This equipment generates, uses, and can ra-
diate radio frequency energy. If not installed and used in ac-
cordance with these instructions, this equipment may cause
radio interference. The equipment has been tested and found
to comply with the limits of a Class A computing device as
defined by the FCC (Federal Communications Commission,
U.S.A.) Regulations, Subpart J of Part 15, which are de-
signed to provide reasonable protection against such inter-
ference when operated in a commercial environment.
WARNING
DO NOT USE TORCH to remove any component. System
contains oil and refrigerant under pressure.
To remove a component, wear protective gloves and gog-
gles and proceed as follows:
a. Shut off electrical power to unit.
b. Recover refrigerant to relieve all pressure from sys-
tem using both high-pressure and low pressure ports.
c. Traces of vapor should be displaced with nitrogen
and the work area should be well ventilated. Refrig-
erant in contact with an open flame produces toxic
gases.
d. Cut component connection tubing with tubing cutter
and remove component from unit. Use a pan to catch
any oil that may come out of the lines and as a gage
for how much oil to add to the system.
e. Carefully unsweat remaining tubing stubs when nec-
essary. Oil can ignite when exposed to torch flame.
Failure to follow these procedures may result in personal
injury or death.
CAUTION
DO NOT re-use compressor oil or any oil that has been ex-
posed to the atmosphere. Dispose of oil per local codes and
regulations. DO NOT leave refrigerant system open to air
any longer than the actual time required to service the
equipment. Seal circuits being serviced and charge with dry
nitrogen to prevent oil contamination when timely repairs
cannot be completed. Failure to follow these procedures
may result in damage to equipment.
AquaForce
®
30HXA,HXC076-271
Condenserless and Water-Cooled
Liquid Chillers with ComfortLink Controls
50/60 Hz
Series 7
2
INTRODUCTION
These instructions cover installation of 30HX liquid chillers
with electronic controls and units with factory-installed options
(FIOPs).
INSTALLATION
Step 1 — Inspect Shipment —
Inspect unit for dam-
age upon arrival. If damage is found, immediately file a claim
with the shipping company. Verify proper unit delivery by
comparing the model number on the nameplate with the data in
Fig. 1. Do not store units in an area exposed to weather because
of sensitive control mechanisms and electronic devices.
Fig. 1 — 30HX Identification
Locate unit indoors. When considering unit location, con-
sult National Electrical Code (NEC, U.S.A.) and local code
requirements. Allow sufficient space for wiring, piping, and
service. Install unit in an area which will not be exposed to am-
bient temperatures below 50°F (10°C). See Fig. 2-10 for clear-
ance details.
Allow the following clearances for service access:
Front 3 ft (914 mm)
Rear 3 ft (914 mm)
Top 2 ft (610 mm)
Ends tube length at one (either) end;
3 ft (914 mm) at opposite end.
Be sure surface beneath unit is level and is capable of
supporting the operating weight of the unit. See Fig. 11 and 12
and Tables 1 and 2 for unit mounting and operating weights. If
necessary, add supporting structure (steel beams or reinforced
concrete slabs) to floor to transfer weight to nearest beams.
Step 2 — Rig and Place Unit
Do not remove unit from skid until unit is in its final
location. Rig from the rigging holes provided in the top heat
exchanger. See Fig. 2-9, 11, and 12 for rigging and center of
gravity information. Lower the unit carefully onto the floor or
roller. Push or pull only on the skid, not the unit. If the unit is
moved on rollers, use a minimum of 3 evenly spaced rollers.
Areas where unit mounting points will be located must be
level to within
1
/
16
in. per ft (5 mm per m) along the long axis
of the unit. Once unit is in place and level, bolt unit to the floor.
Use isolation pads under the unit to aid in vibration isolation as
required.
Instructions continued on page 17.
30HXC 076 R - - 6 7 1 AA
Model Description
30HXA
Condenserless
Liquid Chiller
30HXC
Water-Cooled
Liquid Chiller
Nominal Size
076 126 186
086 136 206
096 146 246
106 161 261
116 171 271
Refrigerant/Cooler Options
L — Nitrogen with Minus 1-Pass
Cooler
M — R-134a with Minus 1-Pass
Cooler
N — Nitrogen with Standard Cooler
P — R-134a with Plus 1-Pass Cooler
Q — Nitrogen with Plus 1-Pass
Cooler
R — R-134a with Standard Cooler
Electrical Options
- — Across The Line Start
A — Non-Fused Disconnect
Y — Y-Delta Starter
Z — Y-Delta and Non-Fused
Disconnect
Packaging Code
1 = Standard Domestic
2 = Standard Export
Series
Voltage Code
1 — 575-3-60
2 — 380-3-60
4 — 230-3-60
5 — 280/230-3-60
6 — 460-3-60
9 — 380/415-3-50
Control Options
-
E —
U —
W
*Option Code Descriptions:1 = Minimum Load Control, 2 = Suction Service
Valve, and 3 = Medium Temperature Brine
Factory-Installed
Option Codes*
AA — 1
BA — 2
CA — 3
KA — 1,2
LA — 1,3
TA — 2,3
ZB — 1,2,3
Standard
Navigator Display with
Energy Management
BACnet
Communication Option
Energy Management
Option and BACnet
Communication Option
CAUTION
Rig unit from the top heat exchanger only. Rigging from
the bottom heat exchanger will cause the unit to be lifted
unsafely. Personal injury or damage to the unit may occur.
IMPORTANT: Install unit in area which will not be exposed
to ambient temperatures below 50°F (10°C).
