ERVCRNVA

Owner’s Manual

Energy Recovery Ventilator

(ERV)

A13212

Fig. 1 − ERVCRNVA

SAFETY CONSIDERATIONS

Recognize safety information. This is the safety−alert symbol

When you see this symbol on the unit and in instructions or

manuals, be alert to the potential for personal injury. Understand

these signal words; DANGER, WARNING, and CAUTION. These

words are used with the safety−alert symbol. DANGER identifies

the most serious hazards which will result in severe personal injury

or death. WARNING signifies hazards which could result in

personal injury or death. CAUTION is used to identify unsafe

practices which would result in minor personal injury or product

and property damage. NOTE is used to highlight suggestions

which will result in enhanced installation, reliability, or operation.

ELECTRICAL OPERATION HAZARD

Failure to follow this warning could result in personal injury

or death.

Before servicing system, always turn off main power to

system. Turn off accessory heater power if applicable. There

may be more than one disconnect switch.

WARNING

PERSONAL INJURY HAZARD

Failure to follow this caution may result in personal injury.

Although special care has been taken to minimize sharp edges

in the construction of your unit, be extremely careful when

handling parts or reaching into the unit.

CAUTION

NOTE TO EQUIPMENT OWNER:

For your convenience, please record the model and serial numbers of your new equipment in the spaces

provided. This information, along with the installation data and dealer contact information will be helpful

should your system require maintenance or service.

ENERGY RECOVERY VENTILATOR

Model # ERVCRNVA1090

Serial # ______________________________________

ACCESSORIES (List type and model #)

_____________________________________________

INSTALLATION INFORMATION:

Date Installed ________________________________

DEALERSHIP CONTACT INFORMATION:

Company Name_______________________________

Address______________________________________

_____________________________________________

Phone Number _______________________________

Technician Name _____________________________

_____________________________________________

NOTE TO INSTALLER:

This manual must be left with the equipment owner.

UNIT OPERATION

Today’s houses are constructed using energy−saving building

practices and technologies. These practices and innovations help

reduce your utility bills, but prevent the introduction of fresh air.

Without ventilation, stale air and contaminants remain in the air for

extended periods of time. Stale, unhealthy air is generated from a

variety of sources including everyday living functions, cooking,

cleaning, painting, exhaust from attached garages, and off−gassing

of chemicals used in construction and furnishings. Your ERV

brings in fresh air and circulates it through your home around the

clock and expels stale air to help reduce the stuffy effects of

trapped indoor air.

The actual rate of ventilation is determined by the size of your

home, the number of bedrooms, and applicable local or national

ventilation codes. Your installing contractor has selected and set an

internal fan speed in the ERV to meet these fresh air requirements.

This unit is normally installed without a separate wall−mounted

control. It is generally wired directly to your furnace or fan coil

unit. The blower motor in the furnace or fan coil works in

conjunction with the two blowers in the ERV to circulate the air

through the ERV and duct system. There are no controls, settings,

or functions that need to be adjusted or changed by the

homeowner.

Continuous ventilation is provided when your thermostat is set

to the constant fan mode.

MAINTENANCE

1. The motors are factory lubricated. Lubricating the bearings

is not recommended.

2. A dirty air filter will cause excessive strain on the blower

motor. The filters in your ERV are washable and should be

cleaned every three months. Use a vacuum cleaner to

remove the heaviest portion of accumulated dust, then wash

in warm water.

NOTE: Do NOT clean these filters in a dishwasher or dry them

with heating appliances as they will be permanently damaged. Use

lukewarm water to clean filters, then air dry. Replace filters only

when they are completely dry.

3. The core should be vacuumed every three months to

remove dust that would inhibit the energy transfer. Do not

use water. The core should only be serviced when the

outdoor temperature is between 605 5 5F (16 C) and 75 F

(245C) and dry.

NOTE: If the edges of the core are soft, do not try to service the

core. The air passages can be damaged and/or closed off by

handling it or trying to remove it.

4. Regularly check the screen on the exterior intake hood and

clean as necessary.

INLET HOOD

EXHAUST HOOD

A13270

Fig. 2 − Inlet/Exhaust Ventilation

Heat Exchanger

Core

Filters

Front Door

(Remove for access

to core and lters.)

A13213

Fig. 3 − ERVCRNVA Components

BEFORE YOU REQUEST A SERVICE

CALL

SCheck the main power disconnect switch. Verify that the circuit

breakers are ON or that fuses have not blown. If you must reset

breakers or replace fuses, do so only once. Contact your servicing

dealer for assistance if the breakers trip or the fuses blow a second

time.

SCheck for sufficient airflow. Check air filters for accumulations of

large particles. Check for blocked exhaust−air grilles or ductwork.

Keep grilles and duct work open and unobstructed.

If your ERV still fails to operate properly, contact your servicing

dealer. Give the dealer your model and serial number. With this

information, the dealer will be able to correct any problems.

NOTE: During cold weather operation, it is possible for a small

amount of frost to accumulate on the heat exchange core inside the

ERV. If a large amount of frost or icing is present on the core,

ventilation performance will be reduced, and melting ice or frost

from the core may result in water damage. If you see a large

amount of ice or frost on the core, or water dripping from or

underneath the ERV, contact your installing contractor.

Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.

Catalog No: OM-ERVCRNVA-02

Replaces: OM-ERVCRNVA-01
