Operation Guide ANA(G3H-2)

E-9

Charging Time

The times below are general guidelines for reference only.

Charging Time to Support Daily Use

Exposure Level (Brightness) Approximate Charging Time

Outdoor sunlight (50,000 lux) 6 minutes

Sunlight through a window (10,000 lux) 23 minutes

Daylight through a window on an overcast day

(5,000 lux)

36 minutes

Indoor fluorescent lighting (500 lux) 6 hours

E-8

Low Battery Alert

The second hand will jump at two-second intervals to alert you when the charge is

low.

2-second jump

E-7

Low Charge and Dead Battery Conditions

An alert operation is performed when the battery charge goes low.

E-6

Caution!

x The case of the watch may become quite hot when charging. Guard against burn

injury after charging.

x Avoid charging in the following locations, and anywhere else where the watch may

become very hot.

− On the dashboard of an automobile parked in the sun

− Close to an incandescent light source or other sources of heat

− Locations exposed to direct sunlight for long periods

Battery Indicator

While the crown is pushed in, holding down the button for about one second will B

cause the stopwatch second hand to move to a position that indicates the current

battery level (about how long the watch can continue operating).

H : At least four months

M : Two to four months

L : No more than two months

After about two seconds, the hand will return to 12o’clock.

E-5

Solar Charging

A solar panel generates electrical power that charges a built-in (secondary) battery.

The entire face is a solar panel, so power is generated when the face is exposed to

light. Keep the watch exposed to light as much as possible.

Charging the Battery

When you are not wearing the watch, leave it where it is

exposed to light. For stable operation, expose the watch to at

least a half day of light per month.

When wearing the watch, try to keep your clothing from

blocking its face (solar panel). Charging efficiency is reduced

significantly even if the face is blocked only partially.

E-4

Contents

Before Using the Watch for the First Time .......................................... E-2

Solar Charging .................................................................................... E-5

Indicators and Crown Operation ....................................................... E-11

Setting the Current Time and Day .................................................... E-13

To adjust the time setting ...........................................................................E-13

To change the day indicator setting ............................................................E-14

Using the Stopwatch ........................................................................ E-15

Specifications................................................................................... E-18

E-3

Crown Operations

Some water-resistant models (100meters, 200meters)

have a screw-in crown. When you need to perform a crown

operation, rotate it towards you to unscrew it. Then pull

the crown out. Avoid applying undue force when pulling.

The watch loses its water resistance while the crown is

unscrewed. After performing a crown operation, fully screw

the crown back in.

Crown

Loosen

If your watch has a rotary bezel...

You can rotate the bezel to align its

▼

mark with

the minute hand. Then you will be able to tell how

much time has elapsed since aligning the

▼

mark.

Start

Elapsed time

Current

E-2

Before Using the Watch for the First Time

Crown

Spacer

x Depending on your watch model, there may be a spacer

installed at the factory around the crown. If your watch has

a spacer, you should remove the spacer before using the

watch.

x After removing the spacer, use the procedures in “Crown

Operations” (page E-3) and “To adjust the time setting” (page E-13)

to set up the watch for use.

E-1

ENGLISH

x Your watch may differ somewhat from the one shown in the illustration.

MA1802-EA

Operation Guide ANA(G3H-2)

E-18

Specifications

Accuracy at normal temperature: ±20 seconds a month

Stopwatch: Measuring Capacity: 29'59" (30minutes)

Measuring Unit: 1 second

Measurements: Elapsed time; split time; two finishes

Other: Low battery alert

Power Supply: Solar panel and one rechargeable battery

Approximate battery operating time: 5months (no exposure to light after a full

charge)

Specifications are subject to change without notice.

E-17

Correcting the 0 Positions of the Hands

Perform the following procedure if the stopwatch hands do not return to their 0 (zero)

positions when you reset the stopwatch.

1. Pull the

Crown out to Click 2.

2. Use (clockwise) and (counterclockwise) to move the A B

Stopwatch Second Hand

and

Stopwatch Minute Hand

to 12o’clock.

x Holding down either button will move the second hand at high speed, until you

release the button.

x The

Stopwatch Minute Hand

is synchronized with the

Stopwatch Second Hand

3. After all of the hands are the way you want, push the

Crown back in.

Important!

x Timekeeping stops while the crown is pulled out. Correct the current time setting

after performing the above operation.

E-16

Two finishes

B A B B

Start Split

First runner

finishes.

Display time of

first runner.

Stop

Second runner

finishes.

Split release

Display time of

second runner.

Reset

Important!

x Do not operate the stopwatch with the crown pulled out.

Note

x An elapsed time operation will stop automatically at the end of 30minutes.

E-15

Using the Stopwatch

The stopwatch measures elapsed time in 1-second increments up to 29minutes,

59seconds.

Elapsed time

A A A B

Start Stop Resume Stop Reset

Split time

B B A B

Start Split Split release Stop Reset

E-14

To change the day indicator setting

1. Pull the Crown out to Click 1.

2. Rotate the towards you to set the day. Crown

3. Push the back in. Crown

Note

x The day indicator setting uses a 31-day month. Make adjustments for months of

shorter lengths.

x Avoid changing the day indicator setting between the hours of 9 p.m. and 1 a.m.

Otherwise, the day indicator may not change correctly at midnight.

E-13

Setting the Current Time and Day

To adjust the time setting

1. When the second hand is at 12 o’clock, pull the out to Click 2. Crown

2. Rotate the to change the time setting. Crown

3. Push the back in on a time signal to resume timekeeping. Crown

Note

x Take care that you set the correct AM or PM time.

x When changing the time, move the minute hand four or five minutes past your final

setting, and then back it up to the setting you want.

E-12

Module 5557 5564

24 Hour Hand

Stopwatch functions

Second Hand

Hour Hand

Minute Hand

Stopwatch Second Hand

Day Indicator

Crown

Click 2

Click 1

Stopwatch Minute Hand

E-11

Indicators and Crown Operation

Module 5529 5530 5585

Click 2

Click 1

Crown

Day Indicator

24 Hour Hand

Second Hand

Hour Hand Minute Hand

Stopwatch Minute Hand

Stopwatch Second Hand

Stopwatch functions

E-10

Charging Time to Recover from Dead Battery

Exposure Level

(Brightness)

Approximate Charging

Time to 1-second

Hand Movement

Approximate Time to

Full Charge

Outdoor sunlight (50,000 lux) 2 hours 21 hours

Sunlight through a window

(10,000 lux)

6 hours 78 hours

Daylight through a window on

an overcast day (5,000 lux)

10 hours 125 hours

Indoor fluorescent lighting

(500 lux)

96 hours – – –

Note

x Actual charging time depends on environmental conditions.
