Operation Guide 5176

MO1011-EA

E-1

ENGLISH

Congratulations upon your selection of this CASIO watch.

Applications

The built-in sensors of this watch measure barometric pressure, temperature and

altitude. Measured values are then shown on the display. Such features make this

watch useful when hiking, mountain climbing, or when engaging in other such outdoor

activities.

E-2

Warning !

•

The measurement functions built into this watch are not intended for taking

measurements that require professional or industrial precision. Values produced

by this watch should be considered as reasonable representations only.

• Note that CASIO COMPUTER CO., LTD. assumes no responsibility for any

damage or loss suffered by you or any third party arising through the use of

this product or its malfunction.

E-3

About This Manual

• Depending on the model of your watch, display text

appears either as dark ﬁ gures on a light background, or

light ﬁ gures on a dark background. All sample displays

in this manual are shown using dark ﬁ gures on a light

background.

• Button operations are indicated using the letters shown

in the illustration.

• Note that the product illustrations in this manual are

intended for reference only, and so the actual product

may appear somewhat different than depicted by an

illustration.

E-4

Things to check before using the watch

1. Check the Home City and the daylight saving time (DST) setting.

Use the procedure under “To conﬁ gure Home City settings” (page E-14) to conﬁ gure

your Home City and daylight saving time settings.

Important!

Proper World Time Mode data depend on correct Home City, time, and date settings

in the Timekeeping Mode. Make sure you conﬁ gure these settings correctly.

2. Set the current time.

See “Conﬁ guring Current Time and Date Settings” (page E-17).

The watch is now ready for use.

E-5

Contents

E-3 About This Manual

E-4 Things to check before using the watch

E-9 Mode Reference Guide

E-13 Timekeeping

E-14 Conﬁ guring Home City Settings

E-14 To conﬁ gure Home City settings

E-16 To change the Daylight Saving Time (summer time) setting

E-17 Conﬁ guring Current Time and Date Settings

E-18 To change the current time and date settings

E-22 Hand Home Position Correction

E-22 To adjust home positions

E-6

E-23 Barometer/Thermometer

E-23 To enter and exit the Barometer/Thermometer Mode

E-28 To calibrate the pressure sensor and the temperature sensor

E-30 Altimeter

E-31 To take an altimeter reading

E-34 To specify a reference altitude value

E-39 Specifying Temperature, Barometric Pressure, and Altitude Units

E-39 To specify temperature, barometric pressure, and altitude units

E-41

Precautions Concerning Simultaneous Measurement of Altitude and

Temperature

E-42 Checking the Current Time in a Different Time Zone

E-42 To enter the World Time Mode

E-42 To view the time in another time zone

E-43 To specify standard time or daylight saving time (DST) for a city

E-7

E-44 Using the Stopwatch

E-44 To enter the Stopwatch Mode

E-44 To perform an elapsed time operation

E-44 To pause at a split time

E-45 To measure two ﬁ nishes

E-46 Using the Countdown Timer

E-46 To enter the Countdown Timer Mode

E-46 To specify the countdown start time

E-48 To perform a countdown timer operation

E-48 To stop the alarm

E-49 Using the Alarm

E-49 To enter the Alarm Mode

E-50 To set an alarm time

E-51 To test the alarm

E-52 To turn an alarm and the Hourly Time Signal on and off

E-52 To stop the alarm

E-8

E-53 Illumination

E-53 To turn on illumination

E-53 To change the illumination duration

E-55 Button Operation Tone

E-55 To turn the button operation tone on and off

E-57 Troubleshooting

E-61 Speciﬁ cations

E-9

Mode Reference Guide

Your watch has 7 “modes”. The mode you should select depends on what you want to do.

To do this: Enter this mode: See:

• View the current time and date in the Home City

•

Conﬁ gure Home City and daylight saving time (DST) settings

• Conﬁ gure time and date settings

Timekeeping Mode E-13

View the barometric pressure and temperature at your

current location Barometer/

Thermometer Mode E-23

• View the altitude at your current location

• Determine the altitude differential between two locations

(reference point and current location)

Altimeter Mode E-30

View the current time in one of 48 cities (31 time zones)

around the globe World Time Mode E-42

Use the stopwatch to measure elapsed time Stopwatch Mode E-44

Use the countdown timer

Countdown Timer Mode

E-46

Set an alarm time Alarm Mode E-49

Operation Guide 5176

E-10

Selecting a Mode

• The illustration below shows which buttons you need to press to navigate between

modes.

• In any mode (except when a setting screen, with ﬂ ashing digits is on the display),

press B to illuminate the display.

World Time

Mode

Barometer/

Thermometer Mode

Stopwatch Mode

Countdown

Timer Mode

World Time

Mode

Barometer/

Thermometer Mode

Stopwatch Mode

Countdown

Timer Mode

E-11

Alarm Mode Hand Setting Mode

Altimeter Mode

Timekeeping Mode

Alarm Mode Hand Setting Mode

Altimeter Mode

Timekeeping Mode

E-12

General Functions (All Modes)

The functions and operations described in this section can be used in all of the modes.

Auto Return Features

• The watch returns to the Timekeeping Mode automatically if you do not perform any

button operation for two or three minutes in the Alarm Mode.

• The watch will return to the Timekeeping Mode automatically if you do not perform

any operation for about one hour after entering the Barometer/Thermometer Mode.

•

If you leave a setting screen with ﬂ ashing digits on the display for two or three minutes

without performing any operation, the watch exits the setting screen automatically.

Initial Screens

When you enter the World Time Mode or Alarm Mode, the data you were viewing

when you last exited the mode appears ﬁ rst.

Scrolling

The B and D buttons are used on the setting screen to scroll through data on the

display. In most cases, holding down these buttons during a scroll operation scrolls

through the data at high speed.

E-13

Timekeeping

Use the Timekeeping Mode to set and view the current

time and date.

• In the Timekeeping Mode, the graphic in the center of

the display indicates the passage of seconds.

PM indicator

Day of week

Month Day

Seconds

Graphic

Hour hand

Hour : Minutes

Minute hand

PM indicator

Day of week

Month Day

Seconds

Graphic

Hour hand

Hour : Minutes

Minute hand

E-14

Conﬁ guring Home City Settings

There are two Home City settings: actually selecting the Home City and selecting

either standard time or daylight saving time (DST).

To conﬁ gure Home City settings

1. In the Timekeeping Mode, hold down A until the

currently selected city code (Home City) starts to ﬂ ash.

This is the city code setting screen.

• Before the city code starts to ﬂ ash, the message

SET Hold will appear on the display. Keep A

depressed until SET Hold disappears and the city

code starts to ﬂ ash.

• The watch will exit the setting mode automatically if

you do not perform any operation for about two or

three minutes.

• For details about city codes, see the “City Code Table”

at the back of this manual.

PM indicator

City code

Seconds

Hour : Minutes

PM indicator

City code

Seconds

Hour : Minutes

E-15

2. Press D (East) and B (West) to select the city code

you want to use as your Home City.

• Keep pressing D or B until the city code you want to

select as your Home City appears on the display.

3. Press C to display the DST setting screen.

Press

to toggle between Daylight Saving Time (On)

and Standard Time (

OFF).

• Note that you cannot switch between standard time

and daylight saving time (DST ) while UTC is

selected as your Home City.

After all the settings are the way you want, press A to return to the Timekeeping Mode.

• The indicator appears to indicate that Daylight Saving Time is turned on.DST

Note

• After you specify a city code, the watch will use UTC* offsets in the World Time

Mode to calculate the current time for other time zones based on the current

time in your Home City.

* Coordinated Universal Time, the world-wide scientiﬁ c standard of timekeeping.

The reference point for UTC is Greenwich, England.

Setting

DST indicator

Setting

DST indicator

E-16

To change the Daylight Saving Time (summer time) setting

1. In the Timekeeping Mode, hold down A until the

currently selected city code (Home City) starts to ﬂ ash.

This is the city code setting screen.

• Before the city code starts to ﬂ ash, the message

SET Hold will appear on the display. Keep A

depressed until SET Hold disappears and the city

code starts to ﬂ ash.

2. Press C to display the DST setting screen.

3. Press D to toggle between Daylight Saving Time (

On)

and Standard Time (

OFF).

4. After all the settings are the way you want, press

A to

return to the Timekeeping Mode.

• The DST indicator appears to indicate that Daylight

Saving Time is turned on.

Setting

DST indicator

Setting

DST indicator

E-17

Conﬁ guring Current Time and Date Settings

You can use the procedure below to adjust the current time and date settings if they

are off.

Changing the digital Home City data should cause the analog time setting to change

accordingly. If the analog time does not indicate the digital time, check the home

positions of the hands and make adjustments if necessary (page E-22).

E-18

To change the current time and date settings

1. In the Timekeeping Mode, hold down A until the

currently selected city code (Home City) starts to ﬂ ash.

This is the city code setting screen.

• Before the city code starts to ﬂ ash, the message

SET Hold will appear on the display. Keep A

depressed until SET Hold disappears and the city

code starts to ﬂ ash.

2. Use D and B to select the city code you want.

• Select your Home City code before changing any

other setting.

• For full information on city codes, see the “City Code

Table” at the back of this manual.

City code

PM indicator

Seconds

Hour : Minutes

City code

PM indicator

Seconds

Hour : Minutes

E-19

Press C to move the ﬂ ashing in the sequence shown below to select the other settings.

Barometer

unit

Temperature

unit

Illumination

Duration

Button Operation

Tone On/Off Day

City

Code DST

Altitude

unit

12/24-Hour

Format Seconds Hour Minute Year Month

• The following steps explain how to conﬁ gure timekeeping settings only.

4. When the timekeeping setting you want to change is ﬂ ashing, use B and/or D to

change it as described below.

Screen To do this: Do this:

Change the city code Use D

(East) and

B (West).

Toggle between Daylight Saving Time (

On)

and Standard Time (OFF

). Press D.
