Chief Manufacturing, a products division of

Milestone AV Technologies

8401 Eagle Creek Parkway, Savage, MN 55378

• P: 800.582.6480 / 952.894.6280 • F:877.894.6918 / 952.894.6918

8832-000065 Rev. N

Duchossois Group Company

www.chiefmfg.com

06/09

I N S T A L L A T I O N I N S T R U C T I O N S

BEFORE YOU BEGIN

Small Flat Panel Mounts

Model: K-Series

This Instruction Manual covers most of the K-Series wall,

desk, and pole mounts for single, dual, and triple

displays. In addition, this Instruction Manual also covers

selected K-Series accessories.

NOTE: Some K-Series mounts, such as Extreme Tilt,

Grommet, and Table, as well as most K-Series

accessories, have separate Instruction Manuals.

See Specifications for a complete list of models

covered by this Instruction Manual.

NOTE: If an accessory such as an optional laptop tray is

being installed, complete all required installation

procedures within this document prior to installing

the accessory.

K-Series Mounts (Examples)

WARNING: It is the installer’s responsibility to make sure all components are properly assembled and installed

using the instructions provided. Failure to read, thoroughly understand, and follow all instructions can result in

serious personal injury, damage to equipment, or voiding of factory warranty.

• If you have any questions about this these instructions or your specific installation, contact Chief Manufacturing.

DISCLAIMER:

Milestone AV Technologies and its affiliated corporations and subsidiaries (collectively, "Milestone"), intend to make this manual accurate and

complete. However, Milestone makes no claim that the information contained herein covers all details, conditions or variations, nor does it provide for

every possible contingency in connection with the installation or use of this product. The information contained in this document is subject to change

without notice or obligation of any kind. Milestone makes no representation of warranty, expressed or implied, regarding the information contained

herein. Milestone assumes no responsibility for accuracy, completeness or sufficiency of the information contained in this document.

Model: K-Series Installation Instructions

IMPORTANT WARNINGS AND CAUTIONS!

WARNING: A WARNING alerts you to the possibility of serious injury or death if you do not follow the instructions.

CAUTION: A CAUTION alerts you to the possibility of damage or destruction of equipment if you do not follow the

corresponding instructions.

WARNING: Failure to provide adequate structural strength for this component can result in serious personal injury

or damage to equipment! It is the installer’s responsibility to make sure the structure to which this component is

attached can support five times the combined weight of all equipment. Reinforce the structure as required before

installing the component.

WARNING: Exceeding the weight capacity can result in serious personal injury or damage to equipment! It is the

installer’s responsibility to make sure the combined weight of all components does not exceed the maximum support

weight as stated in the Specifications section.

WARNING: Allowing any part of your body or component cables to be caught between movable parts can result in

serious personal injury or damage to equipment!

CAUTION: Overtightening fasteners may result in improper operation, excessive wear or damage to equipment,

and/or voiding of factory warranty!

CONTENTS

TOOLS REQUIRED FOR INSTALLATION ...............................................................................................................2

SPECIFICATIONS.....................................................................................................................................................3

MOUNT INSTALLATION ...........................................................................................................................................4

DISPLAY INSTALLATION .........................................................................................................................................7

ARRAY ASSEMBLY (DUAL / TRIPLE DISPLAY; ALL EXCEPT KCY-210/-220).......................................................9

MULTI-DUAL ARM ASSEMBLY (KCY-210/-220 ONLY)..........................................................................................10

CABLE MANAGEMENT.......................................................................................................................................... 11

ADJUSTMENT ........................................................................................................................................................12

TOOLS REQUIRED FOR INSTALLATION

• Phillips Screwdriver, #1 and #2

• 9/16" Wrench (KSA-1015/-1016 Only)

• Drill (All Wall Mounts)

• 1/8" Drill Bit (All Wall Mounts except KSA-1015/-1016)

• 1/4" Drill Bit (KSA-1015/-1016 Only)
