INSTALLATION INSTRUCTIONS

LCM1UP

(Shown installed to

CPA Series extension column

as example only)

Single Portrait Flat Panel Ceiling Mounts

Spanish Product Description

German Product Description

Portuguese Product Description

Italian Product Description

Dutch Product Description

French Product Description

LCM1UP

LCM1UP Installation Instructions

DISCLAIMER

Milestone AV Technologies and its affiliated corporations and

subsidiaries (collectively "Milestone"), intend to make this

manual accurate and complete. However, Milestone makes no

claim that the information contained herein covers all details,

conditions or variations, nor does it provide for every possible

contingency in connection with the installation or use of this

product. The information contained in this document is subject

to change without notice or obligation of any kind. Milestone

makes no representation of warranty, expressed or implied,

regarding the information contained herein. Milestone assumes

no responsibility for accuracy, completeness or sufficiency of

the information contained in this document.

Chief® is a registered trademark of Milestone AV Technologies.

IMPORTANT SAFETY INSTRUCTIONS

WARNING: A WARNING alerts you to the possibility of

serious injury or death if you do not follow the instructions.

CAUTION: A CAUTION alerts you to the possibility of

damage or destruction of equipment if you do not follow the

corresponding instructions.

WARNING: Failure to read, thoroughly understand, and

follow all instructions can result in serious personal injury,

damage to equipment, or voiding of factory warranty! It is the

installer’s responsibility to make sure all components are

properly assembled and installed using the instructions

provided.

WARNING: Failure to provide adequate structural strength

for this component can result in serious personal injury or

damage to equipment! It is the installer’s responsibility to

make sure the structure to which this component is attached

can support five times the combined weight of all equipment.

Reinforce the structure as required before installing the

component.

WARNING: Exceeding the weight capacity can result in

serious personal injury or damage to equipment! It is the

installer’s responsibility to make sure the combined weight of

all components located between the mount up to (and

including) the display does not exceed 125 lbs (56.7 kg).

WARNING: Use this mounting system only for its intended

use as described in these instructions. Do not use

attachments not recommended by the manufacturer.

WARNING: Never operate this mounting system if it is

damaged. Return the mounting system to a service center for

examination and repair.

WARNING: Do not use this product outdoors.

NOTE: The LCM1UP

mounts are designed to be mounted to a

1-1/2" NPT or NPSM following ANSI/ASME B1.20.1

(Schedule 40, 0.154" minimum thickness steel or

aluminum-ASTM B221) threaded extension column

(not included);

a UL Listed Chief CPA Series

extension column (not included).

NOTE: The LCM1UP mounts are intended to be used with the

UL Listed CPA Ceiling Plates (not included): CPA330,

CPA365, CPA395.

The following UL Listed Chief ceiling plates WITHOUT

swaged collars (not included) may also be used:

CMA330, CMA345, CMA395.

--SAVE THESE INSTRUCTIONS--

Produkt Specifikationer

Mærke:	Chief
Kategori:	Vægophæng
Model:	LCM1UP
Produktfarve:	Sort
Pakkevægt:	12000 g
Certificering:	UL
Monteringstype:	Loft
Harmoniseret systemkode (HS):	85299097
Hældningsvinkelområde:	-20 - 5 °
Maksimal vægtkapacitet:	56.7 kg
Antal understøttede skærme:	1
Montering interface kompatibilitet (min.):	200 x 200 mm
Montering interface kompatibilitet (maks.):	200 x 200 mm
