I N S T A L L A T I O N I N S T R U C T I O N S

Plasma Dual Ceiling Mount

PDC Series

PDC Series Installation Instructions

DISCLAIMER

Milestone AV Technologies, Inc., and its affiliated corporations

and subsidiaries (collectively, "Milestone"), intend to make this

manual accurate and complete. However, Milestone makes no

claim that the information contained herein covers all details,

conditions or variations, nor does it provide for every possible

contingency in connection with the installation or use of this

product. The information contained in this document is subject

to change without notice or obligation of any kind. Milestone

makes no representation of warranty, expressed or implied,

regarding the information contained herein. Milestone assumes

no responsibility for accuracy, completeness or sufficiency of

the information contained in this document.

IMPORTANT WARNINGS AND

CAUTIONS!

WARNING:

A WARNING alerts you to the possibility of

serious injury or death if you do not follow the instructions.

CAUTION:

A CAUTION alerts you to the possibility of

damage or destruction of equipment if you do not follow the

corresponding instructions.

WARNING:

Failure to read, thoroughly understand, and

follow all instructions can result in serious personal injury,

damage to equipment, or voiding of factory warranty! It is the

installer’s responsibility to make sure all components are

properly assembled and installed using the instructions

provided.

WARNING:

Failure to provide adequate structural strength

for this component can result in serious personal injury or

damage to equipment! It is the installer’s responsibility to

make sure the structure to which this component is attached

can support five times the combined weight of all equipment.

Reinforce the structure as required before installing the

component.

WARNING:

Exceeding the weight capacity can result in

serious personal injury or damage to equipment! It is the

installer’s responsibility to make sure the combined weight of

all components located between the supporting structure and

the PDC does not exceed 400 lbs (181.44 kg) [200 lbs

(90.72 kg) each faceplate].

• The weight capacity of the PDC may be LIMITED to the

lowest weight capacity of any other component located

between the PDC and the supporting structure!

2" to 1-1/2" Reducer (NPT Threads)

103

4.06

11.42

290

2.56

16.45

418

14.00

356

14.00

356

413

16.27

2.50

NOT SHOWN. THE CUSTOM INTERFACE

BRACKET NEEDED FOR YOUR DISPLAY

ALL MEASUREMENTS ARE IN

THE FOLLOWING FORMAT:

[MILLIMETERS]

INCHES

WILL ADD BETWEEN 1/2" AND 2" IN DEPTH

SEE PSBU DRAWING ALSO.

ON THE MOUNT.

AND MAY AFFECT LOCATION OF DISPLAY

NOTE: CUSTOM INTERFACE BRACKET

Product Features

Weight Capacity 400 lbs

200 lbs per faceplate

Roll / Tilt / Yaw ±2.5° / +5°, -25° / 360°

25°

5°

DIMENSIONS

Produkt Specifikationer

Mærke:	Chief
Kategori:	Flad panel støtte
Model:	PDC2364
