PPX Series User Manual
Introduction
Thank you for choosing a Citronic PPX series power amplifier as part of your sound reinforcement system. This high
output amplifier is designed to offer high quality, dependable service for mobile and installed systems. Please read this
manual fully and follow the instructions to achieve the best results with your new purchase and to avoid damage through
misuse.
Warning
To prevent the risk of fire or electric shock, do not expose any of the components to rain or moisture.
If liquids are spilled on the casing, stop using immediately, allow unit to dry out and have checked by qualified personnel
before further use. Avoid impact, extreme pressure or heavy vibration to the case
No user serviceable parts inside Do not open the case refer all servicing to qualified service personnel. – –
Safety
• Check for correct mains voltage and condition of IEC lead before connecting to power outlet
• Ensure speaker leads are good condition with no short connections or damaged plugs
• Check impedance of speaker loads do not exceed the minimum stated load for the amplifier
• Do not allow any foreign objects to enter the case or through the ventilation grilles
Placement
• Keep out of direct sunlight and away from heat sources
• Keep away from damp or dusty environments
• When rack-mounting, ensure adequate support for the base of the amplifier and firm fixings for the front
• Ensure adequate air-flow and do not cover cooling vents at the front and rear of the amplifier
• Ensure adequate access to controls and connections
Cleaning
• Use a soft cloth with a neutral detergent to clean the casing as required
• Use a vacuum cleaner to clear ventilation grilles of any dust or debris build- ups
• Do not use strong solvents for cleaning the unit
Front Panel
1. Power switch and LED
2. CH1 level control
3. Protect LED indicators
4. Signal LED indicators
5. Clip LED indicators
6. CH2 level control
7. Cooling vent
