U-PAD

Compact Mixer with USB Interface

Item ref: 170.879UK

User Manual

Version 1.1

Caution: Please read this manual carefully before operating

Damage caused by misuse is not covered by the warranty

170.879UK User Manual

Introduction

Thank you for choosing a Citronic U-PAD mixer as part of your recording setup or stage sound system.

This product has been developed to provide a wide range of facilities for professional and reliable sound

reinforcement. Please read and keep this manual to achieve the best results from your purchase and avoid

damage through misuse.

SAFETY SYMBOL AND MESSAGE CONVENTIONS

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

AVIS

RISQUE DE CHOC

ELECTRIQUE NE PAS

OUVRIR

This symbol indicates that dangerous voltage constituting a risk of

electric shock is present within this unit

This symbol indicates that there are important operating and

maintenance instructions in the literature accompanying this unit.

Warning

To prevent the risk of fire or electric shock, do not expose any components to rain or moisture. If liquids

enter the housing, stop using immediately, allow the unit to dry out and have it checked by qualified

personnel before further use. Avoid impact, extreme pressure or heavy vibration to the case.

No user serviceable parts inside – Do not open the case – refer all servicing to qualified service personnel.

Safety

• Use 5Vdc power from a host computer or USB power supply with 1A or more output.

• Avoid ingress of water or particles into any part of the housing. If liquids are spilled on

the console, stop using immediately, allow the unit to dry out and have checked by

qualified personnel before further use.

Placement

• Keep the console out of direct sunlight and away from heat sources.

• Do not place heavy objects on top of the control surface.

• Allow adequate space for airflow and keep the console away from damp or dust.

Cleaning

• Use a soft cloth with a neutral detergent to clean the housing as required.

• A soft brush can be used to clear debris from between controls without damaging them.

• Do not use solvents for cleaning the unit.

Produkt Specifikationer

Mærke:	Citronic
Kategori:	Blandekonsol
Model:	U-Pad 170.879UK
Bredde:	171 mm
Dybde:	166 mm
Højde:	66 mm
Vægt:	900 g
Brugervejledning:	Ja
Produktfarve:	Sort
Pakkevægt:	1210 g
Pakkedybde:	208 mm
Pakkebredde:	300 mm
Pakkehøjde:	87 mm
USB-port:	Ja
Antal USB 2.0-porte:	1
Frekvensområde:	20 - 20000 Hz
Antal kanaler:	- kanaler
Stativ-montering:	Ja
Output impedans:	120 ohm (Ω)
Fantomstrøm:	48 V
Digital lydbehandling:	- Bit
DJ mixer:	Ja
