2 XC6610
English
Owner’s Manual
INTRODUCTION
The Clarion XC6610 is a full-featured, six-channel amplifier incorporating the
following features:
• Conformably Coated PC Board that resists mold, mildew and moisture damage.
• Pulse-Width Modulated (PWM) MOSFET power supply for maximum
performance with minimal distortion.
• Remote turn-on with “soft start” muting to prevent turn-on “thump”.
• Variable high-pass/low-pass electronic crossover with a 12dB per octave
slope (adjustable range: 50Hz to 500Hz).
• Variable bass boost circuit to reinforce low frequency signals.
• Adjustable input level controls with ground loop isolation to minimize noise
and distortion.
• 2-ohm stereo stable, 4-ohm bridged stable.
• Corrosion resistant speaker and RCA connections.
• Speaker level input. (High-level speaker output to RCA input adapters included).
• Auto Sense Turn-on for easy OEM installation.
• Low profile construction with non-corrosive aluminum heat sink for efficient heat
dissipation.
ABOUT THE MANUAL AND WARRANTY
This manual describes the basic requirements to install the Clarion XC6610
amplifier. The installation of this amplifier can be quite complex to install. If you
do not posses the necessary knowledge and tools to perform this installation
please contact your local Clarion Audio dealer. Keep all instructions and
sales receipt for future reference and warranty information.
TABLE OF CONTENTS
Description ................................................ 2
Input Connections and Audio Controls. . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Connections for Power and Speakers . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Installation ................................................ 5
Mounting Precautions........................................ 6
Wiring Precautions.......................................... 6
Wiring and Applications ...................................... 7
Setting the Gain ............................................ 10
Setting the Crossover........................................ 10
Setting the Subwoofer Bass Boost. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Final System Check ........................................ 10
Troubleshooting ............................................ 11
Product Specifications ....................................... 12
