Side 1/19

Owner’s manual & Installation manual

Mode d’emploi et manuel d’installation

Manual de instrucciones y de instalación

XN AMPLIFIERS

AMPLIFICATEURS XN

AMPLIFICADORES XN

XN 3210

XN 3410

XN3210/XN3410 3

English

Owner’s Manual

INTRODUCTION

The Clarion XN3210 is a full-featured, two-channel amplifier incorporating the

following features:

• Specially coated circuit boards that resists mold, mildew and moisture damage.

• Pulse-Width Modulated (PWM) MOSFET power supply for maximum

performance with minimal distortion.

• Remote turn-on with "soft start" muting to prevent turn-on "thump".

• Variable high-pass/low-pass electronic crossover with a 12dB per octave

slope (adjustable range: 55Hz to 5.5kHz).

• Variable bass boost circuit to reinforce low frequency signals that may be lost

due to subwoofer enclosure design.

• Adjustable input level controls with ground loop isolation to minimize noise

and distortion.

• 2-ohm stereo stable, 4-ohm mono stable.

• Chrome-plated power, speaker and RCA connections.

• Speaker level input.

• Low profile construction with aluminum heat sink for efficient heat dissipation.

The Clarion XN3410 is a full featured, four-channel amplifier adding the following

feature:

• Advanced circuitry design featuring bridgeable and mixed mode operation for

use in various system configurations including 4, 3, or 2 channel systems.

ABOUT THE MANUAL AND WARRANTY

This manual describes the basic requirements to install the Clarion XN3210 and

XN3410 amplifiers. The installation of this amplifier can be quite complex to install.

If you do not posses the necessary knowledge and tools to perform this installation,

please contact your local Clarion Marine Audio dealer.

Keep all instructions and sales receipt for future reference and warranty information.

Warranty information can be found on page 19 of this manual.

TABLE OF CONTENTS

Description ............................................... 4

Input Connections and Audio Controls . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Connections for Power and Speakers . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Installation ................................................ 8

Mounting Precautions ....................................... 8

Wiring Precautions ......................................... 8

XN3410 Wiring and Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

XN3210 Wiring and Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Setting the Gain ........................................... 17

Setting the Crossover ....................................... 17

Setting the Subwoofer Bass Boost . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Final System Check ........................................ 18

Troubleshooting ............................................ 18

Product Specs ............................................. 19
