Side 1/2
Features Specifications & Packing Information
The MasterAir MA410P is the upgraded version of
the MasterAir Pro 4, the Pro standard in CPU air
cooling design and production from Cooler
Master. The Continuous Direct Contact
Technology 2.0 (CDC 2.0) increases the surface
area of the cooler base by 45%. With the added
bonus of the MasterFan 120 Air Balance RGB,
making it not only silent and efficient in heat
transfer, but also the most vibrant and fun
choice when it comes to air cooling. If you are
looking for an air cooler based on performance,
silence, and quality RGB lighting, the MasterAir
MA410P is the perfect cooler for you.
Custom Colors – With a sturdy MasterFan 120
Air Balance RGB, MasterAir MA410P is ready for
more than 16.7 million color options and fun
effects to play with
Continuous Direct Contact Technology 2.0
(CDC 2.0) - By compressing heatpipes together,
there is 45% more surface area on the cooler
base, providing improved heat dissipation over
the previous version ,CDC 1.0
Precise Combination of Air Flow and
Heatsink – The stacked fin array ensures the
least amount of airflow resistance allowing cooler
air into the heatsink. The patented X-vents and
Air-Guide steer extra ventilation to the hottest
spots
Snap and Play - Intuitive fan bracket design
makes upgrading and removing the fan a breeze.
MasterAir MA410P
Product
Name
MasterAir
MA410P
Product
Number
MAP
-T4PN-220PC- R1
CPU socket*
Intel® LGA 2066/2011
-v3 / 2011 / 1151 / 1150 /
1155 / 1156 / 1366
AMD
AM4/AM3
+ / AM3 / AM2+ /AM2 / FM2+ /
FM2 / FM1
Dimensions
(LxWxH)
84
x129 x158.5mm (3.3 x 5.1 x 6.2 inch)
Heat
Sink Dimensions
(LxWxH)
60
x116 x158.5mm (2.4 x 4.6 x 6.2 inch)
Heat Sink Material
4 Heat Pipes / CDC 2.0 / Aluminum Fins
Heat Sink weight
420 g
（0.93 lb.）
Heat Pipe Dimensions
Φ6
mm
Fan Dimensions
120x120x25 mm (4.7x4.7x1 inch)
Fan Speed
650
-2,000 RPM (PWM) ± 10%
Fan Air Flow
66.7 CFM (Max)
Fan Air Pressure
2.34 mmH2O (Max)
Fan MTTF
160,000
hours
Fan Noise
Level
6
-30 dBA
Fan Connector
4
-Pin (PWM)
Fan Rated
Voltage
12 VDC
Fan Rated
Current
0.28A
Fan Safety
Current
0.37A
Fan Power
Consumption
3.36
W
Warranty
2
years
EAN code
4719512064009
UPC code
884102036675
Net
weight (Kg)
0.786
Gross
weight (Kg)
0.972
Carton dimension
(L x W x H)
52x33x25.5 cm
Cont. W/ Pallet Carton/ Pallet W/O Pallet
20’ 4800 48 N/A
40’ 9600 48 N/A
40 HQ 10800 54 N/A
Key Features
4 heatpipes with Continuous Direct
Contact 2.0 Technology (CDC 2.0)
technology increases the surface area of
the copper base by 45% while a total of 6
heatpipes efficiently conducts heat away
from the CPU
Certifiled Compatible with top RGB
capable motherbords
Comes with the for Wire RGB LED Controller
users who do not posses an RGB capable
motherboard.
•Mode Switch Buon Easily switch between six lighng –
modes with the touch of a buon.
•Color Switch Buon Switch between seven dierent –
colors across all connected devices instantly.
•Brightness Buon Adjust your LED lights between ve –
dierent brightness levels
•No Soware Required
Brightness
Color
Mode Change 6 pre-set modes –
