FEATURES SPECIFICATIONS & PACKING INFORMATION
CHOOSE YOUR STYLE
The MasterBox Q300L is your straightforward option in the
lineup of the brand new MasterBox Q-series from Cooler
Master. A series that might be small in size but excels in
functionality and modularity without compromising on the
thermal performance.
Although the size wouldn’t tell, the MasterBox Q300L
supports a standard ATX PSU which we don’t see often in
the market with this size. Based on the different system
setup, the I/O panel can be adjusted to six different
locations, three options at each side of the case. You can
decide which setup fits your system best.
Due to the cube design of the frame and special pattern
design on the magnetic dust filter will make the chassis
stand out from the rest. The combination of a practical
design and the unique customizable outlook makes the
MasterBox Q300L the perfect choice for office and home
usage.
High Flexibility for System Building: The I/O panel can
be adjusted to six different locations. On both side of the
body you can install the I/O panel at the front, top or
bottom.
Minimized Dimension with ATX PSU Support: Despite
the Micro-ATX form factor and the body depth and
height of only 370mm x 370mm, the MasterBox Q300L
can accommodate a normal ATX PSU.
Patterned Dust Filter: Special pattern on the dust filter
creates a unique outlook for the chassis.
Clean Routing Space: Behind the motherboard tray, it
offers 28mm wide and spacy room for hidden cable
management.
Excellent Thermal Performance: The open design of
the perforated front, top and bottom guarantees
excellent thermal performance.
Edge-to-Edge Acrylic Transparent Side Panel: Show off
your build through the full size transparent side panel.
Vertical and Horizontal position: The case can be put in
vertical and horizontal position.
MASTERBOX Q300L
Product Number MCB-Q300L-KANN-S00
Product Name MasterBox Q300L
Available Color Black
Materials Steel, Plastic
Dimensions (LxWxH) 387 x 230 x 378mm
Motherboard Support Micro-ATX, Mini-ITX
Expansion Slots 4
Drive Bays
5.25" 0
3.5" HDD 1
2.5” SSD 2
I/O Port USB 3.0 x 2, Audio In / Out
Pre-installed
Fan(s)
Front N/A
Rear 120mm x 1
Fan Support
Front 120 / 140mm x 2
Top 120mm x 2
Rear 120mm x 1
Bottom 120mm x 1
Radiator Support Front 120mm x 1 / 240mm x 1
Rear 120mm x 1
Clearances
CPU Cooler 157mm
PSU 160mm
GPU 360mm
Cable Routing Behind
MB Tray 28mm
Dust Filters Bottom
Power Supply Support Bottom mount, ATX PS2
Cont. W/ Pallet Carton/ Pallet W/O Pallet
20’ 440 44 520
40’ 880 44 1080
40 HQ 1000 50 1215
EAN code 4719512065488
UPC code 884102038006
Net weight 3.7 kg
Gross weight 4.7 kg
Carton dimension (L x W x H) 435 x 276 x 461mm
MCB-Q300L-KANN-S00
FEATURES
High Flexibility for
System Building
The I/O panel can be
adjusted to six different
locations. On both side of
the body you can install the
I/O panel at the front, top
or bottom.
Patterned Dust Filter
Special pattern on the dust
filter creates a unique
outlook for the chassis.
Clean Routing Space
Behind the motherboard
tray, it offers 28mm wide
and spacy room for hidden
cable management.
Excellent Thermal
Performance
The open design of the
perforated front, top and
bottom guarantees
excellent thermal
performance.
Edge-to-Edge Acrylic
Transparent Side Panel
Show off your build
through the full size
transparent side panel.
Vertical and Horizontal
position
The case can be put in
vertical or horizontal
position.
