MasterWatt 650

Semi-fanless Modular 80 PLUS Bronze Certified Power Supply

The MasterWatt is a 80 Plus Bronze Power supply with an

innovative semi-fanless mode. Under 15% load, the

MasterWatt fan remains idle, offering zero dBA. When

demand for power increases, a gradual fan curve provides

measured cooling with little to no noise at any output level.

Dual forward / DC- -DC topology are employed to keep the to

voltage stable in all conditions. For increased performance,

MasterWatt is equipped with 16 AWG power cables, which

reduce resistance thereby increasing efficiency.

Features

Semi-Fanless up till 15% load - Experience noise-free

operation in normal PC loads under 15% output.

Dual Forward and DC- -DC circuit designto - The Dual

Forward and DC- -DC circuit design offers reliability and to

stability especially significant in +3.3V and +5V output.

5 years warranty - The MasterWatt comes with a 5 year

warranty

More Conductive PCI-e Cables - The MasterWatt uses

16AWG cables for PCI-e cables. Less resistance means

better efficiency.

80 PLUS Bronze Certified - The 80 PLUS Bronze

certification means MasterWatt is independently tested with

efficiency of 85%.

Durable LDB bearing - Silencio technology combines

sealed LDB bearings with quiet fan blades delivering a long

lifetime of quiet cooling.

Package Information

Net Weight

2.027 kg / 4.47 lb

Gross Weight

2.398 kg /5.29 lb

Package Dimensions

276 x 194 x 112 mm

(10.87 x 7.64 x 4.41")

Carton Dimensions

582 x 289 x 218 mm

(22.91 x 11.38 x 8.58")

Unit / Carton

5 pcs

Carton / Pallet

24 cartons

Cable type

EAN

UPC

4719512062371

884102035050

4719512062388

884102035067

4719512053102

884102029219

4719512062395

884102035074

4719512062401

884102035081

4719512062173

884102034855

4719512062364

884102035043

4719512053133

884102029240

4719512062357

884102035036

Specifications

Model

MPX-6501-AMAAB

Type

ATX 12V V2.4

PFC

Active PFC

Operation Voltage

100-240Vac

Input Voltage

100-240Vac

Input Current

10 5A-

Input Frequency

50-60Hz

Dimensions (L x B x H)

140 x 150 x 86mm

Fan size

120mm

Fan Bearing

LDB

Powergood Signal

100-500ms

Hold Up Time

16ms at 80% load

Efficiency

85% @ Typical Load

ErP 2013 Lot 6

Yes

MTBF

>100,000 hours

Operating Temperature

0~40°C

Protections

OCP / OVP / UVP / OPP / OTP /

SCP

Regulatory

CCC, CE, TUV-RH, RCM, EAC,

cTUVus, FCC, BSMI, KC,CB

Connectors

MB 24 pin

CPU 12V

4+4Pin

SATA

Peripheral 4

FDD Cable 4

PCI-e 6+2

AC INPUT

100-240Vac~ 10-5A 50-60Hz

DC OUTPUT

+3.3V

+5V

+12V

- 12V

+5sb

22A

54.1A

0.3A

TOTAL POWER

120W

650W

3.6W

15W

650W

MasterWatt 650

Experience noise-free operation in

normal PC loads under 15%

output.

DC- -DC circuit design offers to

reliability and stability especially

significant in +3.3V and +5V

output.

The 80 PLUS Bronze certification

means MasterWatt is

independently tested with

efficiency of 85%.

The MasterWatt comes with a 5

year warranty

Silencio technology combines

sealed LDB bearings with quiet fan

blades delivering a long lifetime of

quiet cooling.

16AWG cables for PCI-e cables.

Less resistance means better

efficiency.
