MWE 500 BRONZE 230V V2

MPE-5001-ACABW-B

POWER UP

The MWE Bronze V2 offers 80 PLUS Bronze certification,

guaranteeing an average efficiency of 88% at typical load.

The DC-to-DC + LLC circuit design allows the unit to convert

power from the single +12V rail reliably, efficiently, and

safely for a better overall user experience. The thermally

sensitive HDB fan cools based on temperature, adjusting

constantly as the system’s needs change. Not only does this

waste less power but it also creates a quieter overall user

experience by not running the fan at maximum noise level

when not needed. For a great mid-tier computing

experience, choose the MWE Bronze V2.

FEATURES

SPECIFICATIONS

Single +12V Rail : All power comes from a single +12V source,

ensuring consistent output through all connected cables.

120mm HDB Fan : The 120mm HDB fan employs responsive

fanspeed control, limiting noise to specific cooling requirements

during use.

DC- -DC Technology :to The DC- -DC + LLC circuit design offers to

reliable, stable output to all connected components.

Flat Black Cables : The flat cables take up less space and are easier

to manipulate within the chassis.

80 PLUS Bronze 230V EU Efficiency : This certification guarantees a

typical efficiency of 88% under normal operating conditions.

5 Year Warranty : This unit comes with a standard limited

manufacturing warranty of 5 years from the date of purchase.

PACKAGE INFORMATION

Cable Type

EAN

UPC

BUS

4719512103890

884102076206

BUK

4719512103906

884102076213

BEU

4719512103913

884102076220

BST

4719512103920

884102076237

BAU

4719512103937

884102076244

BBR

4719512103944

884102076251

BKR

4719512103951

884102076268

BTW

4719512103968

884102076275

BJP

4719512103975

884102076282

BIN

4719512103982

884102076299

BWO

4719512103999

884102076305

Nett Weight

1.272 kg / 2.804 lb

Gross Weight

1.67 kg / 3.682 lb

Package Dimensions

245 x 190 x 110mm (9.65 x 7.48 x 4.33")

Carton Dimensions

570 x 260 x 215mm (22.44 x 10.24 x 8.46")

Unit / Carton

5 pcs

Carton / Pallet

32 pcs

Product Name

MWE 500 Bronze 230V V2

Item Code

MPE-5001-ACABW-B

ATX Version

Intel ATX 12V V2.52

PFC

Active PFC

Input Voltage

200-240V

Input Current

Input Frequency

50-60Hz

Dimensions (L x W x H)

140 x 150 x 86mm

Fan Size

120mm

Fan Bearing

HDB

Fan Speed

1500 RPM

Noise @ 20%

11.77dB-A

Noise @ 50%

18.3dB-A

Noise @ 100%

31.0dB-A

Efficiency

88% Typically

80 PLUS Rating

80 PLUS Bronze EU 230V

ErP 2014 Lot 3

Yes

Power Good Signal

100 - 500ms

Hold Up Time

>14ms at 100% full load@230Vac

MTBF

>100,000 hours

Protections

OVP / OPP / SCP / UVP / OTP

Regulatory

CCC, CE, TUV-RH, RCM, EAC, cTUVus,

FCC, BSMI, KC, CB

Connectors

ATX 24 Pin

EPS 4+4 Pin

SATA

Peripheral 4 Pin

PCI-e 6+2 Pin

AC INPUT

200-240V~ 5A 50-60Hz

DC OUTPUT

+3.3V

+5V

+12V

- 12V

+5Vstb

16A

41A

0.3A

TOTAL POWER

110W

492W

3.6W

15W

500W

FEATURES

All power comes from a single +12V

source, ensuring consistent output

through all connected cables.

The 120mm HDB fan employs

responsive fanspeed control, limiting

noise to specific cooling requirements

during use.

The DC-to-DC + LLC circuit design offers

reliable, stable output to all connected

components.

This certification guarantees a typical

efficiency of 88% under normal

operating conditions.

The flat cables take up less space and

are easier to manipulate within the

chassis.

This unit comes with a standard limited

manufacturing warranty of 5 years from

the date of purchase.
