MWE 700 WHITE 230V V2

MPE-7001-ACABW

POWER UP

The MWE White offers 80 Plus Standard certification,

guaranteeing an average efficiency of 85% at typical load.

The DC-to-DC + LLC circuit design allows the unit to convert

power from the single +12V rail reliably, efficiently, and

safely for a better overall user experience. The thermally

sensitive HDB fan cools based on temperature, adjusting

constantly as the system’s needs change. Not only does this

waste less power but it also creates a quieter overall user

experience by not running the fan at maximum noise level

when not needed. For a great entry level computing

experience, choose the MWE White.

FEATURES

SPECIFICATIONS

Single +12V Rail : All power comes from a single +12V source,

ensuring consistent output through all connected cables.

120mm HDB Fan : The 120mm HDB fan employs responsive

fanspeed control, limiting noise to specific cooling requirements

during use.

DC- -DC Technology :to The DC- -DC + LLC circuit design offers to

reliable, stable output to all connected components.

Silent Mode : The fan will not spin under lower loads or in standby

mode, ensuring a quiet user experience during casual operation.

Flat Black Cables : The flat cables take up less space and are easier

to manipulate within the chassis.

3 Year Warranty : This unit comes with a standard limited

manufacturing warranty of 3 years from the date of purchase.

PACKAGE INFORMATION

Cable Type

EAN

UPC

4719512083079

884102055560

4719512083086

884102055577

4719512083055

884102055546

4719512083116

884102055607

4719512083093

884102055584

4719512083062

884102055553

4719512083109

884102055591

4719512083048

884102055539

4719512083031

884102055522

Nett Weight

1.498 kg / 3.303 lb

Gross Weight

1.896 kg / 4.18 lb

Package Dimensions

245 x 190 x 110mm (9.65 x 7.48 x 4.33")

Carton Dimensions

570 x 260 x 215mm (22.44 x 10.24 x 8.46")

Unit / Carton

5 pcs

Carton / Pallet

32 pcs

Product Name

MWE 700 White 230V V2

Item Code

MPE-7001-ACABW

ATX Version

Intel ATX 12V V2.52

PFC

Active PFC

Input Voltage

200-240V

Input Current

Input Frequency

50-60Hz

Dimensions (L x W x H)

140 x 150 x 86mm

Fan Size

120

Fan Bearing

HDB

Fan Speed

2400 RPM

Noise @ 20%

11.12dB-A

Noise @ 50%

20.4dB-A

Noise @ 100%

40.8dB-A

Efficiency

85% Typically

80 PLUS Rating

80 PLUS Standard 230V EU

ErP 2014 Lot 3

Yes

Operating Temperature

40°C

Power Good Signal

100 -500ms

Hold Up Time

>14ms at 100% full load@230Vac

MTBF

>100,000 hours

Protections

OVP / OPP / SCP / UVP / OTP

Regulatory

CCC, CE, TUV-RH, RCM, EAC, cTUVus,

FCC, BSMI, KC, CB

Connectors

ATX 24 Pin

EPS 4+4 Pin

EPS 8 Pin

SATA

Peripheral 4 Pin

PCI-e 6+2 Pin

AC INPUT

200-240V~ 6A 50-60Hz

DC OUTPUT

+3.3V

+5V

+12V

- 12V

+5Vstb

20A

58A

0.3A

TOTAL POWER

120W

696W

3.6W

15W

700W

FEATURES

All power comes from a single +12V

source, ensuring consistent output

through all connected cables.

The 120mm HDB fan employs

responsive fanspeed control, limiting

noise to specific cooling requirements

during use.

The DC-to-DC + LLC circuit design offers

reliable, stable output to all connected

components.

This certification guarantees a typical

efficiency of 85% under normal

operating conditions.

The flat cables take up less space and

are easier to manipulate within the

chassis.

This unit comes with a standard limited

manufacturing warranty of 3 years from

the date of purchase.
