FEATU
FEATU
FEATU
FEATUFEATU
SPECIFICATIONS &
SPECIFICATIONS &
SPECIFICATIONS &
SPECIFICATIONS & SPECIFICATIONS &
PACKING INFORMATION
PACKING INFORMATION
PACKING INFORMATION
PACKING INFORMATIONPACKING INFORMATION
THE NR200(P) JUST GOT OVERPOWERED
THE NR200(P) JUST GOT OVERPOWERED
THE NR200(P) JUST GOT OVERPOWERED
THE NR200(P) JUST GOT OVERPOWEREDTHE NR200(P) JUST GOT OVERPOWERED
ATX Power Supply Support for MasterBox NR200 & NR200P
Choosing the right power supply for your system is no small task—
especially if you’re limited to SFX PSUs. With the ATX PSU Bracket
Accessory, compatibility is unlocked to support ATX power supplies
in the MasterBox NR200 and NR200P.
The intuitive design of the ATX PSU Bracket allows for ventilation and
the secure fitment of components. To accommodate for a high
range of builds, the ATX PSU bracket is also able to mount in two
positions depending on the length of your graphics card, power
supply, and depending on the number and the location of installed
fans in the system.
For extra power and more choices in components, the ATX PSU
Bracket adds even more modularity to the MasterBox NR200(P).
ATX PSU Support – Enables ATX Power Supply support to the
MasterBox NR200 & NR200P
Available in 2 colorations - The ATX PSU support bracket is
available in both black and white so you can choose the color
that best matches your MasterBox MasterBoxNR200 or NR200P
based system.
Ventilated Design – The design of the bracket is ventilated for
actively cooled units to be installed, independently from the
orientation of the intake fan. It is also natively compatible with
passively cooled power supplies.
Modular Mounting Options – To accommodate for a high
range of builds, the ATX PSU bracket is also able to mount in
two positions depending on the length of your graphics card,
power supply, and depending on the number and the location
of installed fans in the system.
ATX PSU BRACKET FOR NR200 & NR
ATX PSU BRACKET FOR NR200 & NR
ATX PSU BRACKET FOR NR200 & NR
ATX PSU BRACKET FOR NR200 & NRATX PSU BRACKET FOR NR200 & NR
MCA
MCA
MCA
MCAMCA
-
-
-
--NR200C
NR200C
NR200C
NR200CNR200C
-
-
-
--KPSU00/MCA
KPSU00/MCA
KPSU00/MCA
KPSU00/MCAKPSU00/MCA
-
-
-
--NR200C
NR200C
NR200C
NR200CNR200C
-
-
-
--WPSU00
WPSU00
WPSU00
WPSU00WPSU00
Product Name NR200 ATX PSU Bracket
Black
NR200 ATX PSU Bracket
White
Product Number MCA MCA- -NR200C KPSU00 - -NR200C WPSU00
Exterior Color Black White
Materials Steel
Compatible MasterBox NR200, MasterBox NR200P
Warranty 1 Year
EAN code 4719512116593(MCA KPSU00)- -NR200C
4719512116609(MCA WPSU00)- -NR200C
UPC code 884102088902(MCA NR200C KPSU00)- -
884102088919(MCA NR200C WPSU00)- -
Net weight 6.8kg(20pcs per carton)
Gross weight 8.9kg
Retail dimensionbox
(L x W x H) 160mmx108mmx160mm
Carton dimension (L x W x H) 567mmx340mmx358mm
Cont. W/ Pallet Carton/ Pallet W/O Pallet
20’ 6000 30 /
40’ 12000 30 /
40 HQ 14400 36 /
IMPORTANT NOTES BEFORE USE:
-It is recommended to use graphics cards no longer than 240mm to ensure maximum compatibility between components.
-It is recommended to use ATX PSUs no longer than 160mm to ensure maximum compatibility between components.
-When installing the ATX PSU bracket in the top- -most location a secondary standard 120mm fans in the front most position of the top panel cannot be
installed.
-When installing the side radiator/HDD mounting bracket cannot be installed.
