FEATURES
PECIFICATIONS
PACKING INFORMATION
POSTMODERN ELEGANCE TD300 Mesh
TD300 Mesh brings together modern presentation and
performance with its three dimensional artistic mesh front
panel. The polygonal diamond-cut facade emphasizes the
illumination of two included SickleFlow PWM ARGB fans,
cast various glowing effects, shifting based on the viewing
angle. FineMesh technology simultaneously Cooler Master’s
provides high airflow, dust filtration, and strengthened
structure for maximum performance and effortless cooling.
With the exclusive removable top panel, adaptable drive
cage, and ample cooling support, TD300mesh provides a
canvas of unlimited possibilities.
Polygonal Mesh –Crafted with FineMeshCooler Master’s
technology, the polygonal mesh features a three-dimensional
contour, capable of simultaneously providing high airflow and
excellent dust filtration.
Sickleflow PWM ARGB Fans Included–Pre-installed with two
highly acclaimed 120mm ARGB Sickleflow fans, managed by the
included Hub to easily customize a comprehensive ARGB
lighting system and minimize ARGB port usage on the
motherboard.
ARGB/PWM Hub - The included HUB features 5 ARGB and 4
PWM ports and facilitates cable management in the system,
allowing you to conveniently control fans with a single
connector for power and PWM signal and another for ARGB
signal.
Removable Top Panel –The top panel is entirely removable for
improved access to the components during assembly. Ease of
use also facilitates the mounting of cooling solutions such as
fans and radiators.
Tempered Glass Side Panel –Hardware, custom-loop cooling,
and the pure pride of the builder is shown in panoramic view
through an edge- -edge tempered glass side panel.to
Adaptable Drive Cage –The drive cage can be shifted towards
the front to accommodate for PSU space, backwards to provide
additional radiator space, or even completely removed.
Versatile Cooling Options –Support for up to six fans and front,
top, and rear radiator support ensure that performance is not
compromised.
Room For Upgrades –Support for up to a 344mm graphics
card, a 166mm CPU cooler, and up to a 325mm PSU in length
provides room for upgrades to stay ahead of the game.
TD300 MESH/ TD300 MESH WHITE
TD300-KGNN- /TD300-WGNN-S00 S00
Product Name
TD300 M
esh
TD300
Mesh
white
Product Number
TD300
-KGNN-S00
TD300
-WGNN-S00
Exterior Color
Black
White
Materials
Body
Steel, Mesh, Plastic
Left Side Panel
Tempered Glass
Dimensions
(L x W x H)
Body Size
366.5 x 210 x 410mm
incl.
Protrusions
433
x 210 x 420.5mm
Volume (Liters
incl. Protrusions)
38.24L
Motherboard Support
Mini
-ITX, Micro-ATX
Expansion Slots
4
Drive Bays
5.25“ ODD
N/A
3.5” / 2.5” Combo
2
2.5” SSD
2
I/O Panel
USB
Ports
2 x USB 3.2 Gen 1 (USB 3.0)
Audio In / Out
1 x 3.5mm Audio Jack
1 x 3.5mm
Mic Jack
Other
1 x
ARGB/PWM bHu
Pre
-installed
Fan(s)
Top
N/A
Front
2 x 120mm Sickle
flow PWM ARGB fans
Rear
N/A
Bottom
N/A
Fan Support
Top
2 x 120mm / 2 x 140mm
Front
3 x 120mm* / 2 x 140mm
(*can only mount behind the front plate)
Rear
1 x 120mm
Radiator
Support
Top
120 / 140 / 240 / 280mm
Front
120 / 140 / 240 / 280mm
Rear
120mm
Clearances
CPU Cooler
166mm
Power Supply
325mm
(w/o front radiator & drive cage)
140mm
(drive cage in backmost position)
Graphics
Card
344mm
Cable Routing
Behind MB Tray
18~22mm
Dust Filters
Front, Top,
Bottom
Power Supply Support
Bottom Mount, ATX
Cont. W/ Pallet Carton/ Pallet W/O Pallet
20’ 320 32 416
40’ 704 32 848
40 HQ 792 36 967
TD300-KGNN-S00 TD300 Mesh white
EAN
CN)
4719512124161
6928968315223
(for
CN)
UPC
884102096488
Net weight
5.85
kg
Gross weight
7.10
kg
Carton dimension
(LxWxH
)
493
x x280 493 mm
FEATURES
Polygonal Mesh
Crafted from Cooler Master’s Fine
Mesh technology, Polygonal Mesh
features a three-dimensional
contour and is also capable of
simultaneously providing high
airflow and dust filtration.
Dual ARGB Fans
Two pre-installed 120mm
ARGB fans can be managed by
the motherboard, connected
by the included H , to create ub
a comprehensive ARGB
lighting system.
Removable Top Panel
The top panel is entirely removable
for improved access to the
components during assembly. Ease
of use also facilitates the mounting
of cooling solutions such as fans
and radiators.
Tempered Glass Side Panel
Hardware, custom-loop
cooling, and the pure pride of
the builder is shown in
panoramic view through an
edge- -edge tempered glass to
side panel.
Adaptable Drive Cage
The drive cage can be shifted
toward the front to
accommodate for PSU space,
backwards to provide
additional radiator space, or
even completely removed.
ARGB/PWM Hub Included
The HUB features 5 ARGB and 4
PWM ports and facilitates cable
management in the system,
allowing you to conveniently
control fans with a single connector
for power and PWM signal and
another for ARGB signal.
