Side 1/2
V1300 PLATINUM
MPZ-D001-AFBAPV
POWER UP
The V Platinum series promises high-end performance for
every type of PC user. This vanguard of power supply
innovation and development offers an 80 PLUS Platinum
efficiency certification, full-modular cabling, 100% Japanese
capacitors, a high operating temperature of 50°C, and a
hardware based single/multi rail switch. Add on the 10 year
warranty and you have a PSU that won’t disappoint even
the most seasoned system integrators and PC builders. For
highly efficient, quiet operation, you simply can’t go wrong
with the V Platinum.
FEATURES
SPECIFICATIONS
80 PLUS Platinum Certified : This certification guarantees a typical
efficiency of 92% under normal operating conditions.
Thermal Regulation Mode (TRM) : TRM regulates the temperature
of the PSU by keeping a constant and quiet fan speed up to 60% of
maximum load.
Performance Driven Topology : The full-bridge LLC resonant
converter and DC-DC technology offer reliable and stable voltage
outputs for safer, more reliable performance and higher efficiency.
Single/Multi-Rail Switch : Built in rail switch allows users to change
between multi and single rail power output settings.
16 AWG PCI-e Cables : The thicker 16 AWG PCI-e cables allow for
higher currents, thereby improving both efficiency and safety.
10 Year Warranty : This unit comes with a standard limited
manufacturing warranty of 10 years from the date of purchase.
PACKAGE INFORMATION
Cable Type
EAN
AU
4719512072028
BR
4719512072035
EU
4719512072004
IN
4719512071991
JP
4719512072066
KR
4719512072042
ST
4719512072011
TW
4719512072059
UK
4719512071984
US
4719512071977
WO
4719512072073
Nett Weight
3.628 kg / 7.998 lb
Gross Weight
4.25 kg / 9.37 lb
Package Dimensions
355 x 208 x 130mm (13.98 x 8.19 x 5.12")
Carton Dimensions
410 x 370 x 235mm (16.14 x 14.57 x 9.25")
Unit / Carton
3 pcs
Carton / Pallet
24 pcs
Product Name
V1300 Platinum
Item Code
MPZ-D001-AFBAPV
ATX Version
ATX 12V
PFC
Active PFC
Input Voltage
110-240V
Input Current
15 8A-
Input Frequency
50-60Hz
Dimensions (L x W x H)
201.2 x 150 x 86mm
Fan Size
135
Fan Bearing
TBB
Efficiency
92% @ Typical Load
80 PLUS Rating
80 PLUS Platinum
ErP 2014 Lot 3
Yes
Operating Temperature
0~50°C
MTBF
>100,000 hours
Protections
OVP / OPP / SCP / OCP / UVP / OTP
Regulatory
cTUVus, TUV, CE, CCC, FCC, EAC, RCM,
BSMI, KC
Connectors
ATX 24 Pin
1
EPS 4+4 Pin
1
EPS 8 Pin
1
SATA
16
Peripheral 4 Pin
8
FDD
1
PCI-e 6+2 Pin
12
AC INPUT
110-240V~ 15-8A 50-60Hz
DC OUTPUT
+3.3V
+5V
+12V1
+12V2
- 12V
+5Vstb
25A
25A
54A
54A
0.5A
3A
TOTAL POWER
130W
1296W
6W
15W
1300
FEATURES
Thermal Regulation Mode (TRM) keeps
the V Platinum quiet and stable by
maintaining a constant fan speed up to
60% of the maximum load.
The hardware based rail switch allows
you to alter the PSU from single to
multiple rails in order to tailor the unit’s
performance to your needs.
The thicker 16 AWG PCI-e cables allow
for higher currents, because they have
a higher heat tolerance, thereby
improving efficiency and safety.
