SAROS SB-200-P

Saros® Sound Bar 200, Powered

crestron.com | 800.237.2041

>High-quality, full-range amplified

stereo sound bar

>Delivers enhanced sound quality

and performance for use with any

flat panel display

>Mounts to a wall or sits on a shelf

>Balanced or unbalanced stereo

line-level audio input [1]

>Unbalanced stereo audio cable included

>Powers on and off automatically

>100 to 240 Volt AC powered

The Saros® SB-200-P is a stereo sound bar designed to provide

enhanced audio performance for a flat panel display. Its full-range, front-

firing speakers offer an improvement over the small, rear-facing speakers

typical of many display devices. The bracket included with the sound bar

allows for attachment to a wall surface, or the unit can be placed on a

shelf below or above the display.

Built-in amplification allows for direct connection to the line-level audio

output of the display device, or to the output of an audio preamp, switcher,

mixer, tv tuner, codec, or Crestron DM® receiver.[1] The amplifier powers on

automatically when an audio input signal is detected, and powers off if no

signal is detected for several minutes.

The SAROS SB-200-P sound bar is ideally suited for use with the

Crestron RL® 2 Group Collaboration System and other unified

communication and videoconferencing systems. It is equally well-suited

for use in any small to medium sized room or public space in a hotel,

restaurant, museum, medical center, airport, office building, or residence.

SPECIFICATIONS

Features & Performance

Woofers: (2) 3 inch (76 mm) polypropylene cone w/rubber surround

Passive Radiator: (2) 3 x 4-3/8 inch (76 x 112 mm) polypropylene cone

w/rubber surround

Tweeters: (2) 1 inch (25 mm) polyester dome

Amplifier Power: 20 Watts per channel, stereo

Frequency Response: 100 Hz to 20 kHz (±3 dB)

Output Sensitivity: 83 dB SPL @ 1 meter, both channels driven @ 1 Watt

Input Sensitivity: 0.75 Vrms per channel for full rated output

Go To Sleep Time: 20 minutes (±5 minutes) with no signal present

Wake Threshold: 5 mV (±2 mV) typical

Connections

BALANCED AUDIO INPUTS: (1) 5-pin 3.5 mm detachable terminal block;

Balanced stereo line-level audio input

[1];

Maximum Input Level: 0.85 Vrms;

Input Impedance: 10k Ohms

UNBALANCED AUDIO INPUTS: (2) RCA connectors, female;

Unbalanced stereo line-level audio input

[1];

Maximum Input Level: 0.85 Vrms;

Input Impedance: 10k Ohms;

NOTE: Right-angle plugs may be required for wall mount applications. A

59 inch (150 cm) right-angle RCA to straight RCA stereo cable is included.

100-240V~50/60Hz 50W: (1) IEC 60320 C8 main power inlet;

Mates with removable power cord, included

Controls & Indicators

100-240V~50/60Hz 50W: (1) Rocker switch, turns main power on or off

PWR: (1) Blue LED, indicates the main power switch is turned on

Power Requirements

Main Power: 50 Watts (500 mA maximum) @ 100-240 Volts AC, 50/60 Hz

Environmental

Temperature: 41° to 104° F (5° to 40° C)

Humidity: 10% to 90% RH (non-condensing)

SAROS SB-200-P Saros

Sound Bar 200, Powered

Crestron Electronics, Inc. 15 Volvo Drive | Rockleigh, NJ 07647

Tel: 800.237.2041 / 201.767.3400 | Fax: 201.767.1903

www.crestron.com

All brand names, product names and trademarks are the property of their respective owners.

Speciﬁcations subject to change without notice. Revised 07/05/17

Construction

Enclosure: Plastic housing with perforate metal grille, black

Mounting: Freestanding or wall mount (bracket included)

Dimensions

Height: 4.18 in (106 mm)

Width: 40.60 in (1031 mm)

Depth: 2.78 in (71 mm);

2.96 in (76 mm) with wall mount bracket

Weight

7.8 lb (3.6 kg)

MODELS & ACCESSORIES

Available Models

SAROS SB-200-P-B: Saros ® Sound Bar 200, Powered, Black

Notes:

1. The SAROS SB-200-P has a fixed input level. It must be connected to an audio source

equipped with adjustable audio output level.

This product may be purchased from an authorized Crestron dealer. To find a dealer, please

contact the Crestron sales representative for your area. A list of sales representatives is available

online at www.crestron.com/salesreps or by calling 800-237-2041.

The specific patents that cover Crestron products are listed online at: .patents.crestron.com

Certain Crestron products contain open source software. For specific information, please visit

www.crestron.com/opensource.

Crestron, the Crestron logo, DM, and Crestron RL are either trademarks or registered trademarks

of Crestron Electronics, Inc. in the United States and/or other countries. Other trademarks,

registered trademarks, and trade names may be used in this document to refer to either the

entities claiming the marks and names or their products. Crestron disclaims any proprietary

interest in the marks and names of others. Crestron is not responsible for errors in typography

or photography. Specifications are subject to change without notice.
