quickstart guide

USB-EXT-DM

www.crestron.com

Speciﬁcations subject to

change without notice.

QUICKSTART DOC. 7563D (2038832) 08.16

USB over Ethernet Extender with Routing

For regulatory compliance information, refer to Doc. 7564.

USB-EXT-DM

Introduction

The Crestron® USB-EXT-DM consists of the

USB-EXT-DM-LOCAL and the

USB-EXT-DM-REMOTE (sold separately).

The USB-EXT-DM enables USB signal routing

under the control of a Crestron control system

or DigitalMedia™ system. As part of a

DigitalMedia system, the USB-EXT-DM

provides seamless routing of all types of USB

signals alongside video and audio. Without a

control system or DigitalMedia system, the

USB-EXT-DM can be used to provide

point-to-point USB extension over a LAN or a

dedicated CAT5e (or higher) cable.

The USB-EXT-DM-LOCAL connects to virtually

any host device—such as a computer, media

server, or game system—and, typically, also

connects to an Ethernet switch. When

integrated with a DigitalMedia system, the

USB-EXT-DM-LOCAL can connect directly to a

DM-TX series transmitter (for example, the

DM-TX-201-C).

The USB-EXT-DM-REMOTE connects to USB

peripheral devices—such as keyboards, mice,

and game controllers. Up to four peripheral

devices can be connected. When integrated

with a DigitalMedia system, the

USB-EXT-DM-REMOTE can connect directly

to a DM-RMC series receiver (for example, the

DM-RMC-SCALER-C).

Attaching the Brackets

Attach the two supplied brackets to the

rear of the extender using the four

supplied Phillips head screws (two screws

for each bracket).

Mounting onto a Flat Surface

With the two brackets attached to the

extender, attach the brackets to a ﬂat

surface using the outer middle mounting

hole of each bracket and the appropriate

mounting screws (not supplied).

Mounting

Using the two supplied brackets, mount a

USB-EXT-DM extender onto any of the

following:

● Flat surface, such as a table or wall

● Rack rail

● DigitalMedia receiver (DM-RMC-200

series or DM-RMC-SCALER series only)

For mounting instructions, refer to the

sections that follow.

Mounting onto a Rack Rail

With the two brackets attached to the

extender, attach either the left or right

bracket to the rack rail using the top

and bottom mounting holes and the

appropriate mounting screws

(not supplied).

Mounting onto a DigitalMedia Receiver

A USB-EXT-DM extender can be mounted onto

DigitalMedia receivers such as the DM-RMC-200-C,

DM-RMC-200-S, DM-RMC-200-S2,

DM-RMC-SCALER-C, DM-RMC-SCALER-S, and

DM-RMC-SCALER-S2.

To mount an extender onto the appropriate

DigitalMedia receiver, do the following:

1. Remove the two Phillips head screws from the

front of the DigitalMedia receiver and retain the

screws for use in step 3 below.

2. With the brackets attached to the extender, align

the innermost hole of each bracket with the

corresponding hole on the front of the DigitalMedia

receiver.

3. Using the two screws removed in step 1, secure

the brackets of the extender to the front of the

DigitalMedia receiver.

Sample Application of USB Extension with DigitalMedia Integration Sample Application of Point-to-Point Conﬁguration over a LAN

NOTE: The USB-EXT-DM is engineered to deliver maximum compatibility with the widest possible range of devices.

Crestron does not guarantee that all USB devices or hosts are compatible with the USB-EXT-DM.

NOTE: The USB-EXT-DM supports high-speed (480 Mbps) USB devices; however, DM 8G+® Ethernet links support

speeds up to 100 Mbps only. If higher bandwidth is required, ensure that the USB-EXT-DM is communicating via a

gigabit Ethernet network.

Sample Application of Point-to-Point Conﬁguration over a CAT5e Cable

IM TU

O M

I IN DIH

UDU

I O O T

DHIM T

H I I N

H B

SU DUA I

O O TU

DH IM T

UO MDH I IN D

IH BSU DUA I

O O

DH IM

UO MDH

I IN DIH BSU

DUA I O O TU

DH IM TU

O M

DHI IN

B DIH UO OID

UA T

IM TUO M

DH I

IN SUB D

IH UO OID

UA T

DH IM TUO MDH I IN

SU B DIH UO OI

DUA T

DH IM TUO

DH I IN

SUB DI

H UO

OIDU

O IM

DUA IO

O TU

D AIDEM LATI GI

TUO IMDH

DUA IOO TU

DAID E

M LA

GID

UO IM

DUA IOO TU

D AIDE M

TIG

UO IM

A IO

OTU

D AIDEM LATI

H I

MD O TU

Y/bP P

MOC/C /rP

FIPS DU

A I

D C A

R-

V-

H IMD O

Y/bP PMOC/C/rP S IPF DU

A I

C AC

R-

V-

IMD O T

YY/bP PMOC/C/ rP

SIP

F DU

A IO

MD C AC

-DIV-

H IMD O T

C OPMO IS I ET N

4-DIV-

1 2 34

NI T

ON OD MER RO TRES OM EVO ELIHW SELUD SI REWOP NO NI TON OD ME

R RO

RES SELUDOM EVO EWOP ELI

HW SI R NO

S( ST

PTUO MD )1

OLS

B A

I E

2 -

B A

- G

G 4

B A 42

- G I

G B A 42 8 - G I E

G B

A 4

2G I E - 2

G B A

- G I

A 42 G I E

G B - 6

B A

8 -

G I

LS 1

- 1 2

I E G B

A 4

- 3 4

G I

E G B

- 5 2

I E G B

A 4

- 7 42

E G

I E - 1 G 4

2A B G

I E - 3 G B A 42 G

E - 5 G 42 A B G

I E - 7 42 A B G G

TEN LAT

OT REWOP

CDV42 1 W 0 2 SS

ALC

.7~V05

2-001

zH 0

6/0

O MD S(

STU

U)2 TOL

NA L

RTSE

SCINOR

LE JN ,

GIEL

KCO

NI 7 0

67 ASU

NOIT

RISK O F EL

ECTRIC SHOCK

DO N OOT PEN

AVIS U

SIR :

E CHOCDE

ELECTRIQ

UE NE P OAS UVRIR

D IMDH

D M H

M IMD

D IMD M H

D M

USB-EXT-DM-LOCAL

USB

CABLE

CAT5e

CABLE

COMPUTER DM-MD8X8

COMPUTER

DM-TX-201-C

ETHERNET

SWITCH

CONTROL SYSTEM

USB-EXT-DM-REMOTE

USB-EXT-DM-LOCAL

KEYBOARD

MOUSE

FLASH

DRIVE

DISPLAY

USB-EXT-DM

LOCAL

USB-EXT-DM

REMOTE

USB-EXT-DM

LOCAL

DM-RMC-SCALER-C

USB

CABLE USB

CABLE

USB

CABLE

CAT5e

CABLE CAT5e

CABLE

CAT5e

CABLE

CAT5e

CABLE

HDMI

CABLE

HDMI

CABLE

HDMI®

CABLE

DM 8G®

CABLE

DM 8G

CABLE

COMPUTER

USB-EXT-DM-LOCAL

USB-EXT-DM

LOCAL

USB-EXT-DM-REMOTE

MOUSE

FLASH

DRIVE

USB-EXT-DM

REMOTE

LAN

KEYBOARD

USB

CABLE

USB

CABLE

USB

CABLE

COMPUTER

USB

CABLE

USB-EXT-DM-LOCAL

USB-EXT-DM

LOCAL

USB-EXT-DM-REMOTE

FLASH

DRIVE

USB-EXT-DM

REMOTE

CAT5e

CABLE

Option 2:

Rack Mount

Holes

Phillips

Head

Screws (4)

Surface

Mount

Hole

Surface

Mount

Hole

Option 1:

Rack Mount

Holes

DigitalMedia Receiver

(DM-RMC-200-S Shown)

Mounting Holes in

Extender Brackets for

DigitalMedia Receiver

USB-EXT-DM Extender

Mounted onto

DigitalMedia Receiver

Remove Phillips

head screws.

quickstart guide

USB-EXT-DM

www.crestron.com

Speciﬁcations subject to

change without notice.

QUICKSTART DOC. 7563D (2038832) 08.16

USB over Ethernet Extender with Routing

For regulatory compliance information, refer to Doc. 7564.

USB-EXT-DM

Pairing the USB-EXT-DM4

Troubleshooting

Power LED on

the USB-EXT-

DM-LOCAL is oﬀ.

Power LED on

the USB-EXT-

DM-REMOTE

is oﬀ.

Link LED is oﬀ.

Link LED is

blinking fast.

Link LED is

blinking slowly.

Link LED on the

USB-EXT-DM-

LOCAL is on, but

the Host LED is

oﬀ.

TROUBLE POSSIBLE CAUSE CORRECTIVE ACTION

Device is not receiving power

from the USB port.

Device is not receiving power

from the supplied ac power

pack.

No connection exists between

the USB-EXT-DM-LOCAL and

the USB-EXT-DM-REMOTE.

CAT5e (or better) cable is

defective.

No connection exists between

the USB-EXT-DM-LOCAL and

the USB-EXT-DM-REMOTE.

Network switches exist on

diﬀerent subnets.

Network switch is blocking

traﬃc from the extenders.

The USB-EXT-DM-LOCAL

and USB-EXT-DM-REMOTE

are paired with each other but

have not yet established a

link.

One or more of the following

conditions exist:

● The host device is not

powered on.

● The USB-EXT-DM-LOCAL

is not connected to the

computer.

● The host device is not

recognizing the

USB-EXT-DM-LOCAL.

● The host device does not

support USB hubs.

Ensure that the host device is

connected to the USB-EXT-DM-LOCAL.

If the problem persists, connect the USB

cable to another USB port on the host

device.

Ensure that the power pack is properly

connected to the device. If the problem

persists, check the power pack

connection to the ac power source.

Verify CAT5e (or better) cable

connections between the extenders.

Replace the cable.

Verify that the extenders are connected

directly or are connected to active

network switches.

Ensure that network switches can

communicate with each other and are on

the same subnet.

Ensure that traﬃc is not blocked due to

MAC address or traﬃc patterns. If the

problem persists, contact the network

administrator.

If the Link LED does not display solid

green after a few minutes, contact the

network administrator to determine if any

traﬃc is being blocked between the

devices.

Do the following:

1. Disconnect all USB devices from the

USB-EXT-DM-REMOTE.

2. Disconnect the USB-EXT-DM-

LOCAL from the host device.

3. Disconnect the USB-EXT-DM-

REMOTE from the ac power adapter.

4. Reconnect the USB-EXT-DM-

LOCAL to the host device.

5. Reconnect the USB-EXT-DM-

REMOTE to the ac power pack.

Connections

NOTE: The Conﬁg jack on the USB-EXT-DM-LOCAL and

USB-EXT-DM-REMOTE is reserved for factory use only.

Connecting the USB-EXT-DM-LOCAL

Connect the extender

as follows:

● Using the supplied

USB 2.0 A to B cable,

connect the USB Type B

host port ( ) to the host device (USB 1.1 or 2.0 compatible).

● Using a CAT5e or better cable (not supplied), connect the Link port to

an Ethernet network, to the LAN port of a DigitalMedia transmitter

(for example, the DM-TX-201-C), or to the Link port of a

USB-EXT-DM-REMOTE. The maximum cable distance is 330 feet

(100 meters).

Connecting the USB-EXT-DM-REMOTE

Connect the extender

as follows:

● Using USB 2.0 cables

(not supplied), connect

the USB Type A device

ports to USB devices

(USB 1.1 or 2.0 compatible). Up to four USB devices can be connected.

● Using a CAT5e or better

cable (not supplied),

connect the Link port

to an Ethernet network,

to the LAN port of a

DigitalMedia receiver

(for example, the DM-RMC-200-C), or to the Link port of a

USB-EXT-DM-LOCAL. The maximum cable distance is 330 feet

(100 meters).

● Using the supplied ac power pack, connect the 24 Vdc power jack on

the extender to an ac power outlet.

NOTE: The extender receives power from the USB host port.

To pair a USB-EXT-DM-LOCAL with a USB-EXT-DM-REMOTE, do

the following:

1. Ensure that the units are directly connected to each other.

2. On the USB-EXT-DM-LOCAL, press and hold the button for less Pair

than 10 seconds. The Link LED on the bottom panel of the extender

starts blinking green, indicating that the unit is in Pairing

mode. (Pressing and holding the button a second Pair

time for less than 10 seconds cancels Pairing mode.)

3. Within 10 minutes of activating Pairing mode on the

USB-EXT-DM-LOCAL, press and hold the button on the Pair

USB-EXT-DM-REMOTE for less than 10 seconds. The Link LED on the

bottom panel of the extender starts blinking green, indicating that the

unit is in Pairing mode. (Pressing and holding the button a second Pair

time for less than 10 seconds cancels Pairing mode.)

4. Observe that the Link LEDs on both units may start blinking slowly

before turning solid green. Once the Link LEDs are solid green, a valid

link is established between both units.

If, for any reason, pairing must be removed from a unit, press and hold the

Pair button for more than 10 seconds.

NOTE: Pairing a USB-EXT-DM-LOCAL with a USB-EXT-DM-REMOTE

establishes a link between the two devices. Manual pairing is required

only when a USB-EXT-DM-LOCAL and a USB-EXT-DM-REMOTE are

directly connected to each other in a point-to-point conﬁguration. In a

point-to-point conﬁguration, USB switching is not performed. In a

conﬁguration in which USB switching is to be performed, SIMPL

programming automatically pairs the extenders.

NOTE: If more than 10 minutes pass and the units are not yet

paired, the units switch back to the regular mode of operation and

reestablish the previous links they had (if any).

Programming

Program the USB-EXT-DM extenders using the USB-EXT-DM Control

Module in the Crestron Studio® application or SIMPL Windows.

The speciﬁc patents that cover Crestron products are listed at patents.crestron.com. The product warranty can be found at www.crestron.com/warranty.

Certain Crestron products contain open source software. For speciﬁc information, please visit www.crestron.com/opensource.

Crestron, the Crestron logo, Crestron Studio, DigitalMedia, DM 8G, and DM 8G+ are either trademarks or registered trademarks of Crestron

Electronics, Inc. in the United States and/or other countries. Extreme USB is either a trademark or registered trademark of Icron Technologies

Corporation in the United States and/or other countries. HDMI is either a trademark or registered trademark of HDMI Licensing LLC in the United States

and/or other countries. Other trademarks, registered trademarks, and trade names may be used in this document to refer to either the entities claiming
