Side 1/2

LIGHTING THE WAY FOR SIXTY YEARS

ASSEMBLY INSTRUCTION MODEL #4456-GA-CL-SAQ

All electrical components must be

installed by a licensed electrician

in accordance with the National

Electric Code and the appropriate

local electrical codes.

WARNING:

Electrical Danger Turn Power Off

CUL

You will need 12-Candelabra Base Bulb

40 Watts Recommended 60 Watts Max

USE LED BULBS FOR EXTENDED USE

How to Install

WARNING: This product can expose you to Lead,

which is known to the State of California to cause cancer

and/or birth defects or reproductive harm. For more

information go to www.P65Warnings.ca.gov

Crystal Sets

DETAILED ILLUSTRATION

A 52Sets. (1)14mm + AS20-2"

B 4Sets. AS20-2.5"(No Jewel)

C 12Sets. (1)14mm + AS20-2.5"

D 4Sets. (2)14mm + AS20-2.5"

E. 24Sets. (1)14mm + AS20-2.5"

F 8Sets. (14)14mm

G 1Piece. (4)14mm + AS8-40mm Ball

GD E

AC F

The fixture is dry rated

24"

29"

(4(A) CRYSTALS)

1.Do a complete inventory of all parts and components

before you start installing.

2.Screw the top glass dish & Loop on the coupling.

4.After safety attaching fixture into outlet box, install

bobeches, bulbs (not included) and proceed to connecting

the power.

5.When you begin to dress the fixture,start with packet

labeled(A).

6.IMPORTANT: Apply crystal sets in alphabetical order.

3.Place the glass dish and small metal dish over the bottom

metal cover and secure with the finial.

Part Number

LIGHTING THE WAY FOR SIXTY YEARS

PART NUMBER MODEL #4456-GA-CL- SAQ

Outlet box Part Numbers

.. (1)-Mounting Plate

C (2)-Outlet Box Screws

.. (1)-Lock Washer

.. (1)-Hex Nut

.. (1)-Nipple

G (1)-Canopy; w5" x h1" (

.. XFB4454GACAN5IN)

.. (1)-Collar Ring

.. (1)-Collar Loop

.. (1)-Chain; 72", 4mm (XFB4454GACHA4MM)

.. (1)-Ground Wire

(1)-Frame

A (2)-Wire Connector

(1)-Middle Glass Dish Ø4", 11mm hole (XFB4455DIBOB4IN)

(2)-Metal Dish

(1)-Bottom Glass Dish; Ø4", 11mm hole, 4pin (XFB4454GABOB4IN)

(12)-Candle Sleeve; h3" ( )XFB4452GACDL3IN

(12)-Bobeche; Ø4", 24mm hole, 4pin (XFB4454GABOB4IN)

( )-Rosette

PART BAG : Includes Parts A, CⅠ

PART BAG : Includes Parts B, D, E, F, H, IⅡ

(2)-Finial ( )XFB4454CHFIN

(1)-Loop

(1)-Top Glass Dish Ø4", 13mm hole, 4pin(XFB4456DIBOB4IN)

(1)-Metal Dish

(2)-Metal Dish

(1)-Glass Column

(1)-Thread

(1)-Metal Sleeve
