ASSEMBLY INSTRUCTION MODEL #ROS-A1015-CH-CL-MWP

LIGHTING THE WAY FOR SIXTY YEARS

All electrical components must be

installed by a licensed electrician

in accordance with the National

Electric Code and the appropriate

local electrical codes.

WARNING:

Electrical Danger Turn Power Off

CUL

You will need 15-Candelabra Base Bulb

40 Watts Recommended 60 Watts Max

USE LED BULBS FOR EXTENDED USE

How to Install

Crystal Sets

WARNING: This product can expose you to Lead,

which is known to the State of California to cause cancer

and/or birth defects or reproductive harm. For more

information go to www.P65Warnings.ca.gov

DETAILED ILLUSTRATION

G. 84Sets. (1)22mm Square

A. 27Sets. (2)22mm Square

B. 54Sets. (6)12mm+(4)14mm+(1)16mm+(2)18mm

+(1)50mm Baguette+(4)20mm+(1)22mm

+(1)24mm+(2)26mm+(2)28mm

C. 84Sets (2)22mm+(2)20mm+(1)50mm Baguette

+(3)16mm+(2)14mm+(2)12mm

D. 39Sets.

(1)22mm+(1)50mm Baguette+(2)14mm+(1)12mm

1. Attach the top rod kit onto the coupler on the top of wiring box.

2. Attach the bottom rod kit onto the coupler on the bottom of wiring box.

3. Attach the bottom threaded pipe onto the coupler on the bottom metal rin

Do not install the glass dish before the crystal strands "D" are dressed.

4. After safety attaching fixture into outlet box, install bulbs (not included)

and proceed to connecting the power.

5. Dress the crystal sets on the frame. Please hang the crystal strand "B"

before crystal " A".

6. Place the glass dish and small metal dish over the threaded pipe,

secure it with ball finial.

7. Hang the bottom crystal ball "E" on the finial.

The fixture is dry rated

27Sets. (1)22mm Square

1Piece AS8-50mm

DA B C

PART NUMBER MODEL #ROS-A1015-CH-CL-MWP

LIGHTING THE WAY FOR SIXTY YEARS

OUTLET BOX

Part Number

Part Numbers

.. (1)-Mounting bar

C (2)-Outlet Box Screws

.. (1)-Lock Washer

.. (1)-Hex Nut

F (1)-Nipple

G (1)-Canopy; w5" x h1.25" ( )

.. XFB1006CHCAN5IN

.. (1)-Collar Ring

.. (1)-Collar Loop

.. (1)-Chain; 72", 5mm (XFB1006CHCHA5MM)

(1)-Top Band Ring

(1)-Top Stem; 21.3", 16MM thickness (XFB1015CHTOPSTEM21.3IN)

.. (2)-Wire Connector

(1)-Band Ring

(1)-Bottom Stem; 6.5", 12MM thickness (XFB1015CHBOSTEM6.5IN)

(1)-Bottom Metal Ring

(1)-Bottom Threaded Stem; 3.5", 10MM thickness (XFB1015CHBOSTEM3.5IN)

(1)-Glass Dish; Ø5", 11mm hole (XFB1015DIBOB5IN)

.. (1)-Small Metal Dish

(1)-Finial ( )XFB1015CHFIN

(1)-Ground Wire

(1)-Metal Plate

PART BAG : Includes Parts A, CⅠ

PART BAG : Includes Parts B, D, E, F, H, IⅡ

PART BAG : Includes Parts L, MⅢ

PART BAG : Includes Parts O, PⅣ

PART BAG : Includes Parts Q, U, S, TⅤ
