Side 1/20

User’s Manual

CPS7500PIE/CPS7500PRO

K01-0000188-01

CyberPower Systems, Inc.

Website: www.cpsww.com

CPS7500PIE/CPS7500PRO

SAFETY AND EMC INSTRUCTIONS

Safety and EMC instruction

This manual contains important safety instructions. Please read and follow all instructions carefully during

installation and operation of the unit. Read this manual thoroughly before attempting to unpack, install, or

operate your Emergency Power System (EPS).

CAUTION! To prevent the risk of fire or electric shock, install in a temperature and humidity

controlled indoor area free of conductive contaminants. (Please see specifications for acceptable

temperature and humidity range).

CAUTION! To reduce the risk of electric shock, do not remove the cover.

CAUTION! EPS must be connected to an AC power outlet with circuit breaker protection. Do not

plug into an outlet that is not grounded. If you need to de-energize this equipment, turn off and unplug the

unit.

CAUTION! To avoid electrical shock, turn off the unit and unplug it from the AC power source before

servicing EPS, replacing the external battery or installing equipment.

CAUTION! To reduce the risk of fire, only connect the EPS to a circuit with 70 amperes (CPS7500

Series) maximum branch circuit over-current protection in accordance with the CE requirement.

CPS7500PIE Series include CPS7500PIE, CPS7500PIE-FR, CPS7500PIE-UK and other versions.

CPS7500PRO Series include CPS7500PRO, CPS7500PRO-FR, CPS7500PRO-UK and other versions.

CAUTION! The building wiring socket outlet (shockproof socket outlet) must be easily accessible

and close to the EPS.

CAUTION! Please use only VDE-tested, CE-marked mains cable (e.g. the mains cable of your

equipment) to connect the EPS to the building wiring socket outlet (shockproof socket outlet).

CAUTION! Please use only VDE-tested, CE-marked power cables to connect the loads to the EPS.

CAUTION! When installing the equipment, ensure that the sum of the leakage current of the EPS

and the connected equipment does not exceed 3.5mA.

CAUTION! This is permanently connected equipment and only qualified maintenance personnel

may carry out installations.

CAUTION! Do not disconnect the mains cable on the EPS or the building wiring socket outlet

(shockproof socket outlet) during operations since this would remove the protective ground of the EPS

and of all connected loads.

CAUTION! THE EPS shall be connected to the emergency switching device.

Produkt Specifikationer

Mærke:	CyberPower
Kategori:	Ikke kategoriseret
Model:	CPS7500PIE
Bredde:	370 mm
Dybde:	355 mm
Højde:	440 mm
Vægt:	55000 g
Brugervejledning:	Ja
Produktfarve:	Gul
Batterispænding:	12 V
Batterikapacitet:	200 At
Skærmtype:	LCD
Batteriteknologi:	Blybatterier (VRLA)
Formfaktor:	Tower
Responstid:	10 ms
Pakketype:	Kasse
Udgangseffekt:	5250 W
Certificering:	CE
Webbaseret administration:	Ingen
LED-indikatorer:	Strøm
Antal understøttede batterier:	20
Indgangsfrekvens:	45/65 Hz
Lydalarmer:	Ja
Strømbeskyttelsesfunktioner:	Over voltage, Overcharge, Overheating, Overload, Reverse polarity
AC udgange, antal:	3 AC stikkontakt(er)
AC stikkontakt typer:	Terminal, Type F
Indgående driftsspænding (maks.):	300 V
Output strømkapacitet (VA):	7.5 kVA
Indgående driftsspænding (min.):	140 V
Udgangs driftsspænding (min.):	220 V
Udgangs driftsspænding (maks.):	220 V
UPS topologi:	Dobbeltkonvertering (online)
Regulering af udgangsfrekvens:	50/60 Hz
Beskyttelse ved overspænding:	Ja
Bølgeform:	Sine
Hørbare alarmtilstande:	Alarm when on battery, Fault, Low battery alarm, Overload alarm, Battery replacement
Automatisk batteritest:	Ja
Antal F type udgange:	2
Hot-swap batteri:	Ja
Automatisk genstart:	Ja
Automatisk spændingsregulering (AVR):	Ja
Uddgående frekvens:	50/60 Hz
Nødstrøm Off (EPO):	Ja
Antal udgående faser:	1
Opladningsstrøm:	45 A
Bypass:	Ja
Type af påkrævet input beskyttelse:	3-polet kredsløbafbryder
