FEATURES

1. Green Rocker Power Switch

2. Surge-Protected Indicator LED

Illuminated when the surge-protection feature is working

properly

3. Ground Indicator LED

Illuminated when the grounded feature is working properly

4. Energy-Saving Indicator LED

Illuminated only during the Power-Saving Measurement

Initialization

5. Small-Input Jack

6. Sensor Plug

7. Always-On Outlets

These outlets receive continuous power

8. Energy-Saving Outlets

See operation section above

9. IR Sensor

Detects IR signals from your remote

10. IR Sensor Button

Sets the energy saving timer

11. 2 Wide-Spaced Outlets

7-OUTLET TIER 2

ADVANCED POWER STRIP

HT705GR

USER MANUAL

YOUR ULTIMATE ALLY IN POWER

Cyber Power Systems (USA), Inc.

4241 12th Avenue East, Suite 400 | Shakopee, MN 55379

CyberPowerSystems.com

ALWAYS ON / CABLE, DVR ENERGY SAVING / TV

PROTECTED

GROUNDED

ENERGY SAVING

SPECIFICATIONS

Model Number:

Outlets:

Surge Protection:

Electrical Rating:

UL Clamping Voltage:

Maximum Peak Current:

3 AC Lines Protected:

Response Time:

Attenuation:

EMI/RFI Filtration:

HT705GR

2 Always-On Outlets

5 Energy-Saving Outlets

(5 Standard Outlets and

2 Transformer spaced outlets )

1,500 Joules

125 V / 15 A / 1875 W

UL 1449 4th

500 V (H-N, H-G, N-G)

60,000 A

H-N: 30,000 A,

H-G: 15,000 A,

N-G: 15,000 A

(The maximum surge possible on

household wiring is 6,000 volts)

Less than 1 nanosecond

Up to 43 dB

150 kHz to 100 MHz

IR Detection Range/Degree: 16.4 ft./60

i WARNING: This product can expose you to chemicals including bisphenol A (BPA)

and styrene (ABS), which is known to the State of California to cause reproductive

harm and cancer. For more information, go to www.P65Warnings.ca.gov.

CAUTION

TO REDUCE THE RISK OF ELECTRIC SHOCK: Use only in dry locations and only indoors.

DO NOT plug into another relocatable power tap.

DO NOT “daisy chain” surge protectors.

DO NOT use with any aquarium equipment.

DO NOT use if properly grounded outlets are not available.

DO NOT install this device if there is less than 10 meters (30 feet) of wire between the electrical outlet and electrical service panel.

DO NOT use for medical or life support equipment. This device features an internal protection that will disconnect the surge protective component at the end of its useful life,

but it will maintain unprotected power to the load.

FOR MORE INFORMATION

Visit CyberPowerSystems.com for more information regarding:

• Product information and certiﬁcations

• Product warranty

• Connected equipment guarantee

TECHNICAL SUPPORT

Visit: CyberPowerSystems.com/support

Toll-Free: 1-877-297-6937

All other trademarks are the property of their respective owners.

CONFORMANCE APPROVALS

This device complies with Part 15 of the FCC Rules.

Operation is subject to the following two conditions: (1) this

device may not cause harmful interference, and (2) this device must

accept any interference received, including interference that may

cause undesired operation.

This equipment has been tested and found to comply with the limits

for a Class B digital device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against

harmful interference in a residential installation. This equipment

generates, uses, and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause

harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interfer-

ence to radio or television reception, which can be determined by

turning the equipment o and on, the user is encouraged to try to

correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from

that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

WARNING: Changes or modiﬁcations not expressly approved by the

party responsible for compliance could void the user’s authority to

operate the equipment.

TROUBLESHOOTING

PROBLEM TO CHECK

The Always-On outlets are not

receiving the power

• Ensure the plug connections are

secure and the power switch is set to

the on/reset position.

The HT705GR does not power o the

connected equipment in standby mode.

• Ensure the equipment is plugged into

the Energy-Saving outlets, not into

the Always On outlets.

• The HT705GR has not detected the

connected equipment in standby.

Please press the IR sensor button for

more than 10 seconds and release to

enter into the setting mode. When

switching surge o/on again assure

all connected equipment are placed in

power-o or standby mode.

The IR Sensor is not operating. • Turn o the HT705GR power, re-plug

the IR Sensor cable, then turn on the

HT705GR

The IR Sensor ﬂashes frequently during

normal operation.

• It may be radio frequency interfer-

ence. Check for other devices that

may be causing interference in the

area.

• Move the IR Sensor to another loca-

tion that is within line of sight and

normal operation range of connected

equipment remote controls.

The surge protected LED of the

HT705GR is on, but my IR Sensor LED

does not work (when the IR Sensor is

plugged in and powered on).

• Ensure the IR Sensor cable is safely

and securely connected to the

HT705GR, and;

• Press the IR Sensor button, the

Energy-Saving outlet will turn on.

The HT705GR is not working / the

protected LED is not illuminated.

• Remove all the connected equipment

and power cord from the wall outlet.

Reset surge protector by pressing and

hold the IR Sensor button for more

than 10 seconds, then release.

• If the grounded indicator does not

light when you plug in the surge pro-

tector, move the surge protector to

a dierent grounded three-prong AC

outlet. If the surge protector proves

to be working properly, your outlets

may not be properly grounded and

need to be repaired by a professional

electrician.

The connected equipment turned o

after 1 hour.

• The default setting for the energy

saving time is 1 hour.

• If you want to change the energy

saving time, please check the quick

start guide section to change default

energy saving time from 1 or 2 hours.

YOUR ULTIMATE ALLY IN POWER

QUICK START GUIDE

1. Connections:

Turn power switch to OFF. Plug surge protector into wall.

Plug powered-down electronic devices in to appropriate

outlets. Connect infrared (IR) sensor to surge protector into

small input jack. Place glossy side of IR sensor in sightline of

remotes. Turn power switch to ON using green rocker switch.

LED indicators (Protected & Grounded) should illuminate.

2. Power-Saving Measurement Initialization:

The HT705GR performs a power-saving detection

measurement after the green rocker switch is turned ON.

The Energy-Saving outlets will be turned on for 10 seconds,

and the energy-saving LED indicator will illuminate at the

same time. After initialization is complete, the Energy-Saving

outlets and energy-saving LED indicator will turn OFF, and

the unit is available for use. To reset the measurement of your

power consumption, press and hold the IR sensor button for

more than 10 seconds, release, and this will trigger a new

energy-saving measurement of the connected equipment.

3. The Energy-Saving Timer:

The energy-saving timer monitors the time period of power

delivery to the Energy-Saving outlets. The timer has a default

setting of 1 hour. If the timer does not receive any IR signal

during this window, it will turn o Energy-Saving outlets.

4.4. Operation:

Turn TV ON. Power ON all connected equipment. When the IR

sensor receives IR signals, the Energy-Saving outlets will

power on. The IR sensor’s blue LED light will blink for 4.5

minutes after 1 hour after last click of remote to give user

a notice of shutdown. Click any button on a TV remote or the

volume button on a cable provider’s remote to restart

energy-saving timer at zero. Blue LED light will stop blinking.

5.5. Setting the Energy-Saving Timer:

If you want to change the energy-saving time window, hold

the IR sensor button down for 7 seconds; LED light will flash 3

times, release. Press IR sensor 1 time. LED light will flash 1

time, and timer will be 1 hour. Hold the IR sensor button down

for 7 seconds. LED light will flash 3 times, release. Press IR

sensor 2 times, pausing in between. LED light will flash 2

times, and timer will be 2 hours.

6.6. Timer Shut-Down:

When the timer expires, the IR sensor will continue to

flash for 5 minutes, then the Energy-Saving outlets will4.

power off.

K01-0000630-03

Produkt Specifikationer

Mærke:	CyberPower
Kategori:	Ikke kategoriseret
Model:	HT705GR
Tænd-/slukkontakt:	Ja
Produktfarve:	Sort
Responstid:	1 ms
Kabellængde:	2.4 m
Antal produkter inkluderet:	1 stk
Strømstik:	NEMA 5–15P
Nominel indgangsspænding:	125 V
AC udgange, antal:	7 AC stikkontakt(er)
AC stikkontakt typer:	NEMA 5-15R
Overspænding energivurdering:	1500 J
EMI/RFI støjfiltrering:	Ja
Spidsstrøm, normal tilstand:	60000 A
Nominel udgangsstrøm:	15 A
Spændingsblokering:	500 V
Spidsstrøm, almindelig modus:	15000 A
Udgange med sikkerhedslukkere:	Ja
