Copyright © 2017 Cyber Power Systems, Inc. All rights reserved.
FEATURES
1. ON/OFF Reset Switch Breaker
Control power to all outlets. The switch is also a 15A breaker.
When an overload occurs, it will automatically switch o. To
resume operation, ensure the overload condition is corrected
and reset the surge protector by switching the unit ON.
2. Six Standard Outlets
SPECIFICATIONS
• Model Number: B602RC1/B602RC3/MP1003SS/MP1073SS
• Outlets: 6 Standard Outlets
• Surge Protection: 500 Joules
• Electrical Rating: 125V/15A/1875W
• UL Clamping Voltage: UL 1449 3rd/800V (L-N)
• Maximum Peak Current: 15,000A
• Response Time: Less than 1 nanosecond
• Circuit Breaker: Resettable 15Amp
CAUTION
TO REDUCE THE RISK OF ELECTRIC SHOCK - Use only in dry
locations and only indoors. plug into another DO NOT
relocatable power tap. “daisy chain” surge protectors. DO NOT
DO NOT use with any aquarium equipment. use if DO NOT
properly grounded outlets are not available. install DO NOT
this device if there is not at least 10 meters (30 feet) or more of
wire between the electrical outlet and electrical service panel.
This device features an internal protection that will disconnect
the surge protective component at the end of its useful life, but
will maintain power to the load – now unprotected.
TROUBLESHOOTING
If the ON/OFF is switched o, the 15 AMP circuit breaker may
have tripped. Examine your connected equipment and remove
the device that is overloading the circuit. Then, turn the
ON/OFF switch back to RESET.
TECHNICAL SUPPORT
Please contact our Tech Support department with installation,
troubleshooting, or general product questions.
• Phone: 1-877-297-6937
• Email: tech@cpsww.com
• Hours of Operation:
Monday – Friday 7:00am – 6:00pm CST
USER’S MANUAL
6-Outlet Surge Protector
B602RC1/B602RC3
MP1003SS/MP1073SS
6-Outlet Surge Protector
B602RC1/B602RC3
MP1003SS/MP1073SS
1
2
LIMITED WARRANTY AND CONNECTED EQUIPMENT GUARANTEE
Read the following terms and conditions carefully before using
the CyberPower B602RC1/B602RC3/MP1003SS/MP1073SS
(the “CPS Product”). By using the CPS Product, you consent to
be bound by the terms and conditions of this Limited Warranty
and Connected Equipment Guarantee (together referred to as
this “Warranty”). IF YOU DO NOT AGREE TO THE TERMS AND
CONDITIONS OF THIS WARRANTY, YOU SHOULD RETURN
THE PRODUCT FOR A FULL REFUND PRIOR TO USING IT.
CONGRATULATIONS ON YOUR PURCHASE
Thank you for selecting CyberPower B602RC1/B602RC3/
MP1003SS/MP1073SS Surge Protector. The information
contained in this manual explains the features and operation
of the B602RC1/B602RC3/MP1003SS/MP1073SS. Please take
a few moments to read this manual.
