Side 1/3
www.dahuasecurity.com
DH-PFS3106-4ET-60
4-Port PoE Switch (Unmanaged)
· Eight-Pin assignment PoE power supply
· Intelligent PoE
· Hi-PoE 60 W (Orange Port)
· PoE watchdog
· 250 m long distance PoE transmission
· Wide operating temperature: –30 to +65 (–22 °F to +149 °F)°C °C
Hardened PoE Switch | DH-PFS3106-4ET-60
System Overview
The device supports access to four 100 Mbps PoE Ethernet ports, one
independent gigabit Ethernet port or one gigabit opcal port, providing
quasi-industrial quality assurance while meeng the requirements of
various access scenes.
Funcons
Rich Port Types
Four 10/100 Mbps Base-T PoE Ethernet ports; one 10/100/1000 Mbps
Base-T Ethernet ports; one 100/1000 Mbps Base-X opcal port.
Wide Operang Temperature
The device can work in environment temperature ranging from –30 °C
to +65 °C (–22 °F to +149 °F).
Dual Power Backup
The device supports dual power backup.
Intelligent PoE
The switch features intelligent PoE power consumpon management
to help keep the power and data owing, even when the switch
experiences a power fault. Intelligent PoE monitors the power
consumpon of the connected devices, and in the event of large power
uctuaons, the switch shuts down one port at a me rather than
shung down all ports. Unlike typical switches that shut down all ports
as once, this switch shuts down the highest number port rst, then the
next highest number unl the switch detects the power consumpon is
below the PoE budget.
As an access layer PoE switch, DH-PFS3106-4ET-60 supports
simultaneous access to maximum four cameras, and is applicable for
outdoor monitoring scenes such as scenic spots, road juncons, coal
mines and substaons.
Hi-PoE 60W
Besides IEEE802.3af and IEEE802.3at, orange port also supports max.
60W output.
PoE Watchdog
The switch employs an innovave PoE watchdog funcon that
automacally detects a network port failure and restarts network
communicaon on the port. This funconality avoids manual
maintenance and network restarts, saving me and reducing costs.
Long Distance PoE
Long-distance PoE transmission extends the maximum transmission
distance to 250 m (from 100 m), but reduces transmission speed to a
maximum of 10 Mbps (from 1000 Mbps).
Eight-PIN Assignment PoE Power Supply
The Eight-PIN Ethernet port supports power supply, to enhance
front-end and rear-end compability.
Reduce cable loss and promote loading capacity.
Scene
Applicable for outdoor monitoring scenes such as scenic spots, road
juncons, coal mines and substaons.
www.dahuasecurity.com
Technical Specificaon
Hardware
Ethernet Port 4
Opcal Port 1
Ethernet Port Speed 100 Mbps
Data Transmission Port
Port 1–4: 4 × RJ-45 10/100 Mbps (PoE)
Port 5: 1 × RJ-45 10/100/1000 Mbps (Uplink)
Port 6: 1 × SFP 100/1000 Mbps (Uplink)
Power Supply 53 VDC
Operaing Temperature –30 °C to +65 °C (–22 °F to +149 °F)
Operating Humidity 5%–95% (RH)
Storage Temperature –30 °C to +70 °C (–22 °F to +158 °F)
Storage Humidity 5%–95% (RH)
Power Consumption Idling: 2.5 W
Full load: 60 W
Performance
Capacity 6.80 Gbps
Packet Forwarding Rate 3.57 Mpps
Packet Buffer Memory 1 Mbit
MAC Table Size 8K
Communication Standard IEEE802.3; IEEE802.3u; IEEE802.3X; IEEE 802.3ab; IEEE
802.3z
PoE
PoE Standard IEEE802.3af; IEEE802.3at; Hi-PoE
PoE Power 60 W
Power Consumption
Management Yes
PoE Pin Assignment PoE/Hi-PoE: 1, 2, 4, 5 (V+), 3, 6, 7, 8 (V-)
Long Distance PoE 250 m long distance PoE transmission
General
Statics Protection Air discharge: 15 kV
Contact discharge: 8 kV
Thunder-proof Common mode: 4 kV
Dierenal mode: 2 kV
Net Weight 0.45 kg (0.99 lb)
Gross Weight 1.10 kg (2.43 lb)
Product Dimensions 150 mm × 100 mm × 30 mm (5.91" × 3.94" × 1.18") (L ×
W × H)
Packing Dimensions
Packing box: 270 mm × 240 mm × 75 mm (10.63" × 9.45"
× 2.95") (L × W × H)
Protecve box: 544 mm × 253 mm × 331 mm (21.42" ×
9.96" × 13.03") (L × W × H)
Dimensions (mm[inch])
100.0 [3.94]
30.0 [1.18]
110.4 [4.35]
150.0 [5.91]
152.9 [6.02]
Hardened PoE Switch | DH-PFS3106-4ET-60
Transmission Performance:
Switch power supply voltage 53 V.
CAT5E/CAT6. Max. DC resistance < 10Ω/100 m
Cable (m) Load Capacity (W) Bandwidth (Mbps)
IEEE802.3bt 90 W
100 71.3 100
150 62 10
200 51 10
250 40 10
Hi-PoE 60 W
100 53 100
150 50 10
200 47 10
250 37 10
IEEE802.3at 30 W
100 25.5 100
150 25.5 10
200 25.5 10
250 25.5 10
Note: Data from this table was collected by Dahua test lab and is for reference only .
If there is inconsistency between field application and the table, the field result shall
prevail.
