OPERATION MANUAL
EKHBRD011ADV17
EKHBRD014ADV17
EKHBRD016ADV17
EKHBRD011ADY17
EKHBRD014ADY17
EKHBRD016ADY17
Indoor unit for air to water heat pump system
and options
Operation manual
1
EKHBRD011~016ADV17+Y17
Indoor unit for air to water heat pump system and options
4P402192-1B – 2017.09
CONTENTS Page
Introduction ..................................................................................... 1
General information .................................................................... 1
Scope of this manual .................................................................. 1
Quick start-up of the unit ............................................................... 2
Space heating operation .................................................................... 2
Domestic water heating operation...................................................... 2
Operation of the unit....................................................................... 2
Remote controller buttons and icons .......................................... 3
Setting the clock.......................................................................... 4
Space heating operation ( ) ...................................................... 5
Room temperature control.................................................................. 5
Leaving water temperature control ..................................................... 5
Domestic water heating operation ( )....................................... 7
Automatic storage............................................................................... 7
Manual storage................................................................................... 8
Reheat................................................................................................ 9
Disinfection operation ......................................................................... 9
Emergency operation.................................................................. 9
Other operation modes ............................................................... 9
Start up operation ( ) ................................................................. 9
Defrost operation ( ) .................................................................. 9
Quiet mode operation ( )................................................................. 9
Simultaneous demand of space heating and
domestic water heating............................................................. 10
Temperature read-out mode ..................................................... 10
Schedule timer operation.......................................................... 10
Space heating .................................................................................. 10
Domestic water heating.................................................................... 12
Quiet mode....................................................................................... 12
Programming and consulting the schedule timer...................... 12
Programming space heating............................................................. 13
Programming quiet mode or domestic water heating....................... 14
Consulting programmed actions....................................................... 14
Tips and tricks .................................................................................. 15
Operating the remote alarm option ........................................... 15
Operating the optional remote controller .................................. 15
Field settings............................................................................. 16
Procedure......................................................................................... 16
Field settings table............................................................................ 17
Maintenance .................................................................................. 19
Maintenance activities ...................................................................... 19
Important information regarding the refrigerant used....................... 19
Troubleshooting ............................................................................ 19
Disposal requirements ................................................................. 19
The English text is the original instruction. Other languages are
translations of the original instructions.
This appliance is not intended for use by persons, including children,
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person
responsible for their safety.
Children should be supervised to ensure that they do not play with
the appliance.
INTRODUCTION
General information
Thank you for purchasing this unit.
The unit is the indoor part of the air to water ERSQ or ERRQ heat
pump. The unit is designed for floor standing indoor installation and
used for heating applications. The unit can be combined with space
heating radiators (field supply) and with an EKHTS* domestic hot
water tank (option).
A remote controller with room thermostat functionality is standard
supplied with this unit to control your installation.
Refer to the installation manual for the list of options.
Scope of this manual
This manual describes how to start up and switch off the unit, set
parameters and configure the schedule timer by means of the
controller, maintain the unit and solve operational problems.
EKHBRD011ADV17 EKHBRD011ADY17
EKHBRD014ADV17 EKHBRD014ADY17
EKHBRD016ADV17 EKHBRD016ADY17
Indoor unit for air to water heat pump system
and options Operation manual
CAREFULLY READ THIS OPERATION MANUAL
BEFORE USING THE UNIT. IT WILL TELL YOU HOW TO
USE THE UNIT PROPERLY AND HELP YOU IF ANY
TROUBLE OCCURS. AFTER READING THE MANUAL,
FILE IT AWAY FOR FUTURE REFERENCE.
■This unit contains electrical and hot parts.
■Before operating the unit, make sure the installation
has been carried out correctly by a professional
dealer.
If you feel unsure about operation, contact your dealer
for advice and information.
NOTE An EKHBRD indoor unit can only be connected to an
ERSQ or ERRQ outdoor unit.
Refer to the installation manual of the indoor unit for
installation procedures.
