Installation manual
Daikin room air conditioner English
Installation manual
Daikin room air conditioner
CTXM15R2V1B
CTXM15R5V1B
FTXM20R2V1B
FTXM20R5V1B
FTXM25R2V1B
FTXM25R5V1B
FTXM35R2V1B
FTXM35R5V1B
FTXM42R2V1B
FTXM42R5V1B
FTXM50R2V1B
FTXM60R2V1B
FTXM71R2V1B
ATXM20R2V1B
ATXM20R5V1B
ATXM25R2V1B
ATXM25R5V1B
ATXM35R2V1B
ATXM35R5V1B
ATXM50R2V1B
Table of contents
Installation manual
2
CTXM15+FTXM20~42+ATXM20~35R2/5V1B +
FTXM50~71R2V1B + ATXM50R2V1B
Daikin room air conditioner
3P482320-11R – 2020.06
Table of contents
1 About the documentation 2
1.1 About this document.................................................................. 2
2 Specific installer safety instructions 2
3 About the box 3
3.1 Indoor unit ................................................................................. 3
3.1.1 To remove the accessories from the indoor unit......... 3
4 About the unit 3
4.1 About the wireless LAN ............................................................. 4
4.1.1 Precautions when using the wireless LAN.................. 4
4.1.2 Basic parameters ........................................................ 4
5 Unit installation 4
5.1 Preparing the installation site .................................................... 4
5.1.1 Installation site requirements of the indoor unit .......... 4
5.2 Opening the indoor unit ............................................................. 4
5.2.1 To remove the front panel........................................... 4
5.2.2 To open the service cover........................................... 4
5.2.3 To remove the front grille ............................................ 4
5.3 Mounting the indoor unit............................................................ 5
5.3.1 To install the mounting plate....................................... 5
5.3.2 To drill a wall hole ....................................................... 6
5.3.3 To remove the pipe port cover.................................... 6
5.4 Connecting the drain piping....................................................... 6
5.4.1 To connect the piping on right side, right-back, or
right-bottom ................................................................. 6
5.4.2 To connect the piping on left side, left-back, or left-
bottom ......................................................................... 7
5.4.3 To check for water leaks............................................. 7
6 Piping installation 7
6.1 Preparing refrigerant piping....................................................... 7
6.1.1 Refrigerant piping requirements.................................. 7
6.1.2 Refrigerant piping insulation ....................................... 7
6.2 Connecting the refrigerant piping .............................................. 8
6.2.1 To connect the refrigerant piping to the indoor unit .... 8
7 Electrical installation 8
7.1 Specifications of standard wiring components .......................... 8
7.2 To connect the electrical wiring to the indoor unit ..................... 8
8 Finishing the indoor unit installation 9
8.1 To insulate the drain piping, refrigerant piping and
interconnection cable ................................................................ 9
8.2 To pass the pipes through the wall hole.................................... 9
8.3 To fix the unit on the mounting plate ......................................... 9
8.4 To close the indoor unit ............................................................. 9
8.4.1 To re-install the front grille .......................................... 9
8.4.2 To close the service cover .......................................... 10
8.4.3 To re-install the front panel ......................................... 10
9 Commissioning 10
9.1 Checklist before commissioning................................................ 10
9.2 To perform a test run ................................................................. 10
9.2.1 To perform a test run using the user interface............ 10
10 Technical data 10
10.1 Wiring diagram .......................................................................... 10
10.1.1 Unified wiring diagram legend..................................... 10
1 About the documentation
1.1 About this document
INFORMATION
Make sure that the user has the printed documentation and
ask him/her to keep it for future reference.
Target audience
Authorised installers
INFORMATION
This appliance is intended to be used by expert or trained
users in shops, in light industry, and on farms, or for
commercial and household use by lay persons.
Documentation set
This document is part of a documentation set. The complete set
consists of:
▪General safety precautions:
▪ Safety instructions that you MUST read before installing
▪ Format: Paper (in the box of the indoor unit)
▪Indoor unit installation manual:
▪ Installation instructions
▪ Format: Paper (in the box of the indoor unit)
▪Installer reference guide:
▪ Preparation of the installation, good practices, reference data,…
▪ Format: Digital files on http://www.daikineurope.com/support-
and-manuals/product-information/
Latest revisions of the supplied documentation may be available on
the regional Daikin website or via your dealer.
The original documentation is written in English. All other languages
are translations.
Technical engineering data
▪ A of the latest technical data is available on the regionalsubset
Daikin website (publicly accessible).
▪ The of latest technical data is available on the Daikinfull set
Business Portal (authentication required).
2 Specific installer safety
instructions
Always observe the following safety instructions and regulations.
Unit installation (see ["5Unit installation"44])
WARNING
The appliance shall be stored in a room without
continuously operating ignition sources (example: open
flames, an operating gas appliance or an operating electric
heater).
WARNING
Do NOT place objects below the indoor and/or outdoor unit
that may get wet. Otherwise condensation on the main unit
or refrigerant pipes, air filter dirt or drain blockage may
cause dripping, and objects under the unit may get dirty or
damaged.
