dBTechnologies’ active line array series
DVA has set new standards in the sound
reinforcement industry since its market launch
in 2006.
Equipped with top-notch features and
engineered for maximum versatility, DVA
T and DVA M series brought the benefits
of line array technology to a much wider
range of users. Now Italian manufacturer
dBTechnologies upgrades the best of
technology that determined the success of
the whole DVA series in the new DVA K series,
composed by the 3-way active line array DVA
K5 and active subs DVA KS10 and double 18”
DVA KS20.
Featuring a Class-D 500
W RMS Digipro® G3
digital amplifier, DVA K5
is capable to reach up
to 129 dB SPL and aims
to inherit the success of the
earliest model of the series DVA T4. The new DVA line array module
comprises 2 x 1,4”compression drivers, a 6.5” neodymium midrange
and a 8” neodymium woofer. Thanks to FIR filters technology, a new
dual rotary encoder DSP user interface allows an extremely precise
system tuning. The module’s electronics and components are
housed in a sturdy polypropylene box, reinforced with an internal
anti-vibration metal structure that allows the cabinet to achieve an
excellent acoustic response. DVA K5 comes with a freshly designed
frontal grille and an integrated raincover.
The semi-horn loaded
subwoofer DVA KS10 is
equipped with a single
18” woofer driven by a
Class-D Digipro® G3 power
amp delivering 1800W Peak
and reaching 134 dB SPL. Maximum versatility is granted by a
stereo input/output balanced pre-amp. Crucially, KS10 can be both
used as a compact PA system (together with K5 on a speaker pole)
or groundstacked, but can also be flown thanks to the optionally
available flyware. A dedicated encoder allows to apply up to 4.5 ms
of delay, with 0.5 ms steps. A switch allows to invert the phase by
180° as well as changing the LPF from 90 Hz to 120 Hz.
Featuring a double 18”
woofer pairing in a bass
reflex housing, the DVA
KS20 is equipped with
2 x DIgipro® G3 power
amplifiers delivering 3600 W
Peak. The system’s internal design brings together the benefits of
bass reflex and horn-loaded system in a compact sturdy housing
covered with robust black laquer. The 56 Bit DSP manages limiters
and delays, for flawless system processing.
DVA KS20 is the perfect low-end complement for larger DVA
K5 systems and can also be used vertically for groundstacked
configurations thanks to the DRK-20/10 pick points on top.
dBTechnologies
dBTechnologies
dbtechnologies.com
DVA K5 groundstacked
with DVA KS20
DVA K5 flown
with DVA KS10
dBTechnologies
Frequency Response [-3 dB] 70 Hz - 19.000 Hz
Max SPL 129 dB
LF 1 x 8” Neodymium woofer - 2.5” v.c.
MF 1 x 6.5” Neodymium midrange - 2” v.c.
HF 2 x 1” Compression driver - 1.4” v.c.
Directivity [H x V] 100° x 15°, single unit
Frequency Response [-3 dB] 39 Hz - 120 Hz
Max SPL 134 dB
LF 18” Woofer - 4” v.c.
Directivity Omnidirectional
Frequency Response [-3 dB] 34 Hz - 120 Hz
Max SPL 138 dB
LF 2 x 18” Woofer - 4” v.c.
Directivity Omnidirectional
Speaker Type 3-Way Active Line Array Module
Speaker Type Active Semi-Horn loaded Flyable Subwoofer Speaker Type Active Bassreflex - horn Subwoofer
Input Section 1x XLR balanced
Output Section 1x XLR balanced
Power Socket 1x Powercon In + 1 x Powercon Out
Input Section 2x XLR balanced
Output Section 2x XLR balanced
Power Socket 1x Powercon In + 1 x Powercon Out
Input Section 2x XLR balanced
Output Section 2x XLR balanced
Power Socket 1x Powercon In + 1 x Powercon Out
Amplifier technology Digipro® G3 Class-D
RMS Power 500 W
Peak Power 1000 W
Cooling Convection
Amplifier technology Digipro® G3 Class-D
RMS Power 900 W
Peak Power 1800 W
Cooling Convection
Amplifier technology Digipro® G3 Class-D
RMS Power 1800 W
Peak Power 3600 W
Cooling Convection
Controller DSP 56 Bit
AD/DA converter 24 bit/48 kHz
Limiter Dual Active Limiter Multiband RMS, Peak,
Thermal
Processing (filters) FIR Linear phase
X-over frequency MF-HF
Slope MF-HF
1800 Hz
24 dB/Octave
X-over frequency LF-MF
Slope LF-MF
340 Hz
24 dB/Octave
Controller DSP 56 Bit
AD/DA converter 24 bit/48 kHz
Limiter Dual Active Limiter Multiband RMS, Peak,
Thermal
X-over frequency LF-HF
Slope LF-HF
90 - 120 Hz (selectable)
24 dB/Octave
Controller DSP 56 Bit
AD/DA converter 24 bit/48 kHz
Limiter Dual Active Limiter Multiband RMS, Peak,
Thermal
X-over frequency LF-HF
Slope LF-HF
90 - 120 Hz (selectable)
24 dB/Octave
Enclosure Polypropylene PP Metal reinforced
Rigging Points Integrated rigging hardware (1.5° splay res.)
Dimensions (W x H x D) 580 x 240 x 327 mm
(23.2 x 9.6 x 13.08 in)
Weight 14.2 kg (31.3 lbs.)
Enclosure Multiplex birch plywood
Pole Mount 1 x M20 on top
Rigging Points Integrated for SRK10 Flykit (optional)
2 x Pick points on top to fix DRK10/20 Flybars
Dimensions (W x H x D) 515 x 640 x 720 mm
(20.6 x 25.6 x 28.8 in)
Weight 48 kg (105.82 lbs.)
Enclosure Multiplex birch plywood
Pole Mount 1 x M20 on top
Rigging Points 2 x Pick points on side to fix DRK10/20 rigging
frames
Dimensions (W x H x D) 1100 x 580 x 720 mm
(44 x 23.2 x 28.8 in)
Weight 84 kg (185.19 lbs.)
Acoustical Data
Acoustical Data Acoustical Data
Technical Data
Technical Data Technical Data
Inputs
Inputs Inputs
Processor Processor Processor
Mechanics
Mechanics Mechanics
Amplifier Amplifier Amplifier
Series
Power Supply 500 W SMPS with Auto-range PSU
Controls 1 x Input Sensitivity Rotary Switch
1 x DSP Setup Rotary Encoder (LF Correction)
1 x DSP Setup Rotary Encoder (MF-HF Correct.)
Power Supply 1000 W SMPS with Auto-range PSU
Controls 1 x Input Sensitivity Rotary Switch
1 x DSP Setup Rotary Encoder (Delay 4.5 ms)
1 x Phase Inversion Switch (0° - 180°)
1 x X-Over Frequency Switch (90 Hz - 120 Hz)
1 x Outputs Mode Switch (Link - X-Over)
Power Supply 2000 W SMPS with Auto-range PSU
Controls 1 x Input Sensitivity Rotary Switch
1 x DSP Setup Rotary Encoder (Delay 4.5 ms)
1 x Phase Inversion Switch (0° - 180°)
1 x X-Over Frequency Switch (90 Hz - 120 Hz)
1 x Outputs Mode Switch (Link - X-Over)

Produkt Specifikationer

Mærke: DB Technologies
Kategori: Subwoofer
Model: DVA

Har du brug for hjælp?

Hvis du har brug for hjælp til DB Technologies DVA stil et spørgsmål nedenfor, og andre brugere vil svare dig
