User Manual

Complete Equalization & Loudspeaker Management System

480P

Power

Supply

480P Rear Panel

IEC Power Cord Receptacle

The 480P comes with a IEC power supply cord and a selectable power supply.

Voltage Selector Switch

The 480P allows you to select either 115V with 500mA 250V SLOW BLOW fuse or 230V with 250mA 250V Type “T” fuse. WARNING: Fuse

must be changed to correspond with the desired power setting.

RS485 Link to 480R (DB-9 connector type)

This connector is used to connect to the 480R. Cable lengths - 300 feet max. 500 feet with dbx proprietary cable.480R to 480P

RS485 Link to Network Master (DB-9 connector type)

This connector is used to connect the 480R to the network master. Connect to the CONTROLLER IN on the Network master 480P to Network

cable length- Up to 4000 feet.

RS485 Link to 480R (RJ-45 connector type)

This connector is used to connect to the 480R, and is wired in parallel with the DB-9 connector. Cable lengths - 300 feet max. 500480R to 480P

feet with dbx proprietary cable.

RS485 Link to Network Master (RJ-45 connector type)

This connector is used to connect the 480R to the network master. Connect to the CONTROLLER IN on the Network master and is and is wired

in parallel with the DB-9 connector. cable length- Up to 4000 feet.480P to Network

RS232 PC Connection

This input is used to connect a PC to the 480R for 480R software updates.

RS485/ PC Select Button

This recessed button is used to select the link to master controller connector or the PC

480P Front Panel

Power Switch

Turns the 480P and 480R on and off.

Specifications ( 480P Power Supply)

Inputs

Connectors: RS 232 and RS 485 Network Communication

Connectors

Power Requirements

30 Watts Selectable

100-120V - 50/60Hz

or 220-240V-

50/60Hz

Dimensions

Dimensions:

Height: 1.75” X Width- 19” X Depth 7.90”

Weight: 8 lbs.

Shipping Weight: 9.5 lbs.

18-0294-A

WARNING FOR YOUR PROTECTION

PLEASE READ THE FOLLOWING:

KEEP THESE INSTRUCTIONS

HEED ALL WARNINGS

FOLLOW ALL INSTRUCTIONS

CLEAN ONLY WITH A DAMP CLOTH.

DO NOT BLOCK ANY OF THE VENTILATION

OPENINGS. INSTALL IN ACCORDANCE WITH

THE MANUFACTURERS INSTRUCTIONS.

DO NOT INSTALL NEAR ANY HEAT SOURCES

SUCH AS RADIATORS, HEAT REGISTERS,

STOVES; OR OTHER APPARATUS (INCLUDING

AMPLIFIERS) THAT PRODUCE HEAT.

ONLY USE ATTACHMENTS/ACCESSORIES SPEC-

IFIED BY THE MANUFACTURER.

UNPLUG THIS APPARATUS DURING LIGHTNING

STORMS OR WHEN UNUSED FOR LONG PERI-

ODS OF TIME.

WATER AND MOISTURE: Appliance should not be used

near water (e.g. near a bathtub, washbowl, kitchen sink,

laundry tub, in a wet basement, or near a swimming

pool, etc). Care should be taken so that objects do not

fall and liquids are not spilled into the enclosure through

openings.

POWER SOURCES: The appliance should be connected

to a power supply only of the type described in the oper-

ating instructions or as marked on the appliance.

GROUNDING OR POLARIZATION: Precautions should

be taken so that the grounding or polarization means of

an appliance is not defeated.

POWER CORD PROTECTION: Power supply cords

should be routed so that they are not likely to be walked

on or pinched by items placed upon or against them,

paying particular attention to cords at plugs, conven-

ience receptacles, and the point where they exit from the

appliance.

SERVICING: To reduce the risk of fire or electric shock,

the user should not attempt to service the appliance

beyond that described in the operating instructions. All

other servicing should be referred to qualified service

personnel.

FOR UNITS EQUIPPED WITH EXTERNALLY ACCESSI-

BLE FUSE RECEPTACLE: Replace fuse with same type

and rating only.

MULTIPLE-INPUT VOLTAGE: This equipment may

require the use of a different line cord, attachment plug,

or both, depending on the available power source at

installation. Connect this equipment only to the power

source indicated on the equipment rear panel. To reduce

the risk of fire or electric shock, refer servicing to quali-

fied service personnel or equivalent.

SAFETY INSTRUCTIONS

NOTICE FOR CUSTOMERS IF YOUR UNIT IS EQUIPPED

WITH A POWER CORD.

WARNING: THIS APPLIANCE MUST BE EARTHED.

CAUTION: EQUIPMENT IS NOT DISCONNECTED FROM

MAINS WHEN SWITCH IS IN THE OFF POSITION

The cores in the mains lead are coloured in accordance with

the following code:

GREEN and YELLOW - Earth BLUE - Neutral

BROWN - Live

As colours of the cores in the mains lead of this appliance

may not correspond with the coloured markings identifying

the terminals in your plug, proceed as follows:

• The core which is coloured green and yellow must

be connected to the terminal in the plug marked

with the letter E, or with the earth symbol, or

coloured green, or green and yellow.

• The core which is coloured blue must be con-

nected to the terminal marked N or coloured

black.

• The core which is coloured brown must be con-

nected to the terminal marked L or coloured red.

This equipment may require the use of a different line cord,

attachment plug, or both, depending on the available power

source at installation. If the attachment plug needs to be

changed, refer servicing to qualified service personnel who

should refer to the table below. The green/yellow wire shall

be connected directly to the units chassis.

WARNING: If the ground is defeated, certain fault conditions in the unit

or in the system to which it is connected can result in full line voltage

between chassis and earth ground. Severe injury or death can then

result if the chassis and earth ground are touched simultaneously.

LIVE

NEUTRAL

EARTH GND

CONDUCTOR

BROWN

BLUE

GREEN/YEL

BLACK

Normal Alt

WIRE COLOR

WHITE

GREEN

The symbols shown above are internationally accepted symbols

that warn of potential hazards with electrical products. The light-

ning flash with arrowpoint in an equilateral triangle means that

there are dangerous voltages present within the unit. The excla-

mation point in an equilateral triangle indicates that it is neces-

sary for the user to refer to the owner’s manual.

These symbols warn that there are no user serviceable parts

inside the unit. Do not open the unit. Do not attempt to service

the unit yourself. Refer all servicing to qualified personnel.

Opening the chassis for any reason will void the manufacturer’s

warranty. Do not get the unit wet. If liquid is spilled on the unit,

shut it off immediately and take it to a dealer for service.

Disconnect the unit during storms to prevent damage.

C A UT I O N

A T T E NT I O N:

R I S Q U E D E C H O C E L E C T R I Q U E - N E P A S O U V R I R

W A R N I N G:

T O R E D U C E T H E R I S K O F F I R E O R E L E C T R I C ฀

S H O C K D O N O T E X P O S E T H I S E Q U I P M E N T T O R A I N O R M O I S T U R E

R I S K O F E L E C T R I C S H O C K ฀

D O N O T O P E N

IMPORTANT SAFETY INSTRUCTIONS

U.K. MAINS PLUG WARNING

A molded mains plug that has been cut off from the cord

is unsafe. Discard the mains plug at a suitable disposal

facility. NEVER UNDER ANY CIRCUMSTANCES SHOULD

YOU INSERT A DAMAGED OR CUT MAINS PLUG INTO A

13 AMP POWER SOCKET. Do not use the mains plug

without the fuse cover in place. Replacement fuse covers

can be obtained from your local retailer. Replacement

fuses are 13 amps and MUST be ASTA approved to

BS1362.

LITHIUM BATTERY

WARNING

CAUTION!

This product may contain a lithium battery.There is

danger of explosion if the battery is incorrectly

replaced. Replace only with a Sony or equivalent bat-

tery. Make sure the battery is installed with the cor-

rect polarity. Discard used batteries according to man-

ufacturer’s instructions.

ADVARSEL!

Lithiumbatteri - Eksplosjonsfare.Ved utskifting benyttes

kun batteri som anbefalt av apparatfabrikanten. Brukt

batteri returneres apparatleverandøren.

ADVARSEL!

Lithiumbatteri - Eksplosionsfare ved fejlagtig håndter-

ing. Udskiftning må kun ske med batteri av samme

fabrikat og type. Levér det brugte batteri tilbage til

leverandøren.

VAROITUS!

Paristo voi räjähtää, jos se on virheellisesti asennettu.

Vaihda paristo ainoastaan laitevalmistajan suosittele-

maan tyyppin. Hävitä käytetty paristo valmistajan ohjei-

den mukaisesti.

VARNING!

Explosionsfara vid felaktigt batteribyte.Använd samma

batterityp eller en ekvivalent typ som rekommenderas

av apparattillverkaren. Kassera använt batteri enligt

fabrikantens instruktion.

IMPORTANT SAFETY INSTRUCTIONS

ELECTROMAGNETIC

COMPATIBILITY

This unit conforms to the Product Specifications noted on

the Declaration of Conformity. Operation is subject to

the following two conditions:

• this device may not cause harmful interference,

and

• this device must accept any interference received,

including interference that may cause undesired

operation.

Operation of this unit within significant electromagnetic

fields should be avoided.

• use only shielded interconnecting cables.

DECLARATION OF

CONFORMITY

Manufacturer’s Name: dbx Professional

Products

Manufacturer’s Address:

8760 S. Sandy Parkway

Sandy, Utah 84070, USA

declares that the product:

Product name: dbx DriveRack™ 480P

Product option: None

conforms to the following Product Specifications:

Safety: EN 60065 (1993)

IEC 60065 (1998)

CAN/CSA E60065-99

EMC: EN 55013 (1990)

EN 55020 (1991)

Supplementary Information:

The product herewith complies with

the requirements of the Low Voltage

Directive 73/23/EEC and the EMC

Directive 89/336/EEC as amended by

Directive 93/68/EEC.

dbx Professional Products

Vice-President of Engineering

8760 S. Sandy Parkway

Sandy, Utah 84070, USA

March 15th, 2000

European Contact: Your Local dbx Sales and

Service Office or

Harman Music Group

8760 South Sandy Parkway

Sandy, Utah

84070 USA

PH: (801) 568-7533

FX: (801) 568-7583
