Thank You

Thank you for choosing Deﬁnitive Technology AW Series

all-weather outdoor loudspeakers. Your AW loudspeaker is

a unique high performance product developed to allow you

to experience the joy of superb music reproduced anywhere,

whether indoors or outdoors, in both domestic and

commercial applications. It utilizes specially developed

materials and components, brought together to achieve a

level of sound quality previously unavailable in all-weather

loudspeakers.

Our engineers have spent many years in developing this

product. In order to ensure that you experience the ﬁnest

performance and durability possible, we encourage you

to take a moment to fully read this owner’s manual and

familiarize yourself with the proper installation and set-up

procedures for your AW Series speakers.

AW5500 & AW6500

All-Weather Loudspeakers

Owner’s Manual

Deﬁnitive Technology warrants to the original retail purchaser only that this Deﬁnitive

Technology Loudspeaker Product (the “Product”) will be free from defects in materials and

workmanship for a period of ﬁve (5) years from the date of the original purchase from a

Deﬁnitive Technology Franchised Dealer. However, this warranty will automatically

terminate prior to the expiration of ﬁve (5) years if the original retail purchaser sells or

otherwise transfers the Product to any other party or if the serial number is defaced or

removed. The original retail purchaser shall hereinafter be referred to as “you.” To obtain

the warranty protection for your DeﬁnitiveTechnology Product(s), you must ﬁll out the

Warranty Registration Card(s), within ten days of the date of purchase.

Defective Products must be shipped, together with proof of date of purchase, prepaid

insured to the Franchised Dealer from whom you purchased the Product, or to the nearest

Factory service center. Product(s) must be shipped in the original shipping container or its

equivalent; in any case the risk of loss or damage in transit is to be borne by you. If, upon

examination at the Factory or a Deﬁnitive Technology Franchised Dealer it is determined

that the unit was defective in materials or workmanship at any time during this Warranty

period, Deﬁnitive Technology or the Deﬁnitive Technology Franchised Dealer will, at its

option, repair or replace this product at no additional charge, except as set forth below. All

replaced parts and Product(s) become the property of Deﬁnitive Technology. Product(s)

replaced or repaired under this Warranty will be returned to you, within a reasonable time,

freight collect.

This Warranty does not include service or parts to repair damage caused by accident,

misuse, abuse, negligence, improper mounting, inadequate packing or shipping procedures,

voltage in excess of the rated maximum of the unit, normal wear and tear, cosmetic

appearance of cabinetry or components not directly attributable to defects in materials or

workmanship, or service, or repair or modiﬁcation of the Product which has not

been authorized by Deﬁnitive Technology.

Deﬁnitive Technology makes no Warranty with respect to its Products purchased from

dealers or outlets other than Deﬁnitive Technology Franchised Dealers.

This Warranty is in lieu of all other expressed Warranties. If this Product is defective in

material or workmanship as warranted above, your sole remedy shall be repair or

replacement as provided above. In no event will Deﬁnitive Technology be liable to you for

any incidental or consequential damages arising out of the use or inability to use the

Product, even if Deﬁnitive Technology or a Deﬁnitive Technology Franchised Dealer has

been advised of the possibility of such damages, or for any claim by any other party. Some

states do not allow the exclusion or limitation of consequential damages, so the above

limitation may not apply to you.

All implied warranties on the Product are limited to the duration of this expressed

Warranty. Some states do not allow limitation on how long an implied Warranty lasts, so

the above limitations may not apply to you. This Warranty gives you speciﬁ

c legal rights,

and you also may have other rights which vary from state to state.

Limited USA Warranty:

5-Years for Drivers and Cabinets

This product complies with the essential

requirements of the EMC directive 89/336/EEC.

EAAT012108

CAUTION! To reduce the risk of electric shock and ﬁre, do not remove the cover or back plate of this

device. There are no user serviceable parts inside. Please refer all servicing to licensed service technicians.

Avis: Risque de choc electricque, ne pas ouvrir.

CAUTION! The international symbol of a lightning bolt inside a triangle is intended to alert the user to

uninsulated “dangerous voltage” within the device’s enclosure. The international symbol of an exclamation

point inside a triangle is intended to alert the user to the presence of important operating, maintenance and

servicing information in the manual accompanying the device.

CAUTION! To prevent electrical shock, match wide blade of plug to wide slot, fully insert. Attention: Pour

eviter les chocs electriques, introduire la lame la plus large de la ﬁche dans la borne correspondante de la

prise et pousser jusqu'au fond.

CAUTION! To reduce the risk of electrical shock, do not expose this equipment to rain or moisture.

1. Read Instructions—All safety and operating instructions should be read before operating the device.

2. Retain Instructions—The safety and operating instructions should be retained for future reference.

3. Heed Warnings—All warnings on the device and in the operating instructions should be adhered to.

4. Follow Instructions—All operating and safety instructions should be followed.

5. Water & Moisture—The device should never be used in, on or near water for risk of fatal shock.

6. Carts & Stands—The device should only be used on carts or stands recommended by the manufacturer.

7. Wall & Ceiling Mounting—The device should be mounted on a wall or ceiling only as recommended

by the manufacturer.

8. Ventilation—The device should always be located in such a way that it maintains proper ventilation.

It should never be placed in a built-in installation or anywhere that may impede the ﬂow of air through

its heat sink.

9. Heat—Never locate the device near heat sources such as radiators, ﬂoor registers, stoves or other

heat-generating devices.

10. Power Supply—The device should only be connected to a power supply of the type described in the

operating instructions or as marked on the device.

11. Power Cord Protection—Power cables should be routed so they are not likely to be stepped on or

crushed by items placed on them or against them. Special attention should be paid to areas where the

plug enters a socket or fused strip and where the cord exits the device.

12. Cleaning—The device should be cleaned in accordance with manufacturer’s instructions.

13. Periods Of Non-Use—The device should be unplugged when not being used for extended periods.

14. Dangerous Entry—Care should be taken that no foreign objects or liquids fall or are spilled inside

the device.

15. Damage Requiring Service—The device should be serviced by licensed technicians when:

• The plug or power supply cord has been damaged.

• Objects have fallen or liquid has spilled inside the device.

• The device has been exposed to moisture.

• The device does not appear to be operating properly or exhibits a marked change in performance.

• The device has been dropped or the cabinet becomes damaged.

16. Service—The device should always be serviced by licensed technicians. Only replacement parts

speciﬁed by the manufacturer should be used. The use of unauthorized substitutions may result in ﬁ

re,

shock, or other hazards.

CAUTION

ISK OF ELECTRIC SHOCK

DO NOT OPEN

Safety Precautions

Your local Deﬁnitive Technology dealer will usually be able to service your

Deﬁnitive loudspeakers. If, however, you wish to return the speaker to Deﬁnitive,

please contact us ﬁrst, describing the problem and requesting authorization as well

as the location of the nearest factory service center.

Please note that the address

given in this booklet is the addr

ess of our of

ﬁce only. Under no circumstances

should loudspeakers be shipped to our ofﬁce or returned without contacting

us ﬁrst and obtaining return authorization.

Deﬁ

nitive Technology Ofﬁces

11433 Cronridge Drive,

Owings Mills, Maryland 21

117

Phone: (800) 228-7148 (US & Canada),

01 (410) 363-7148 (all other countries)

Service

It is our pleasure to offer assistance if you have any questions regarding your

AW Series speakers or their set-up. Please contact your nearest Deﬁnitive

Technology dealer or call us directly at (800) 228-7148 (US & Canada),

01 (410) 363-7148 (all other countries), or e-mail info@deﬁ

nitivetech.com.

Technical Assistance

AW5500

Dimensions: 12

" L x 7

" W x 8

" D

Driver Complement:

One 5

" BDSS cast-basket bass/midrange

driver

One 5" x 8" pressure-driven Low-Bass Radiator

One 1" Pure Aluminum dome tweeter

Inputs:

Gold-plated 5-way binding posts

Frequency Response: 45 Hz – 30 kHz

Nominal Impedance:

4 – 8 Ohms

Rec.

Assoc. Ampliﬁcation: 10 – 175 Watts/channel

Sensitivity:

91 dB

Weight:

8.33 lbs. (3.78 kG)

AW6500

Dimensions: 14

" L x 8

" W x 9

" D

Driver Complement:

One 6

" BDSS cast-basket bass/midrange

driver

One 5

" x 10" pressure-driven Low-Bass Radiator

One 1" Pure Aluminum dome tweeter

Inputs:

Gold-plated 5-way binding posts

Frequency Response: 40 Hz – 30 kHz

Nominal Impedance:

4 – 8 Ohms

Rec.

Assoc. Ampliﬁcation: 10 – 200 Watts/channel

Sensitivity:

92 dB

Weight:

10 lbs. (4.52 kG)

Speciﬁcations subject to change without notice.

Speciﬁcations

Visit us at www.deﬁnitivetech.com.

Produkt Specifikationer

Mærke:	Definitive Technology
Kategori:	Højttaler
Model:	AW6500
Bredde:	366.7 mm
Dybde:	235 mm
Højde:	225.4 mm
Vægt:	4479 g
Produktfarve:	Sort
Pakkedybde:	292.1 mm
Pakkebredde:	292.1 mm
Pakkehøjde:	444.5 mm
Udgangseffekt (RMS):	200 W
Equalizer:	Ingen
Husmateriale:	Polymer
Anbefalet brug:	Andet
Frekvensområde:	40 - 30000 Hz
Impedens:	8 ohm (Ω)
Forbindelsesteknologi:	Ledningsført
Højttaler, type:	3-vejs
Lyd-output kanaler:	1.0 kanaler
Højttaler, placering:	I væggen/i loftet
Strømkilde type:	Vekselstrøm
Antal drivere:	3
Diskanthøjttaler:	Ja
Antal drivere til diskant:	1
Sensitivitet:	92 dB
AC (strøm) indgang:	Ja
Diskant diameter:	1 "
Bashøjttaler:	Ja
Antal bashøjttalerdrev:	1
Woofer diameter:	139.7 mm
Mid-range driver diameter:	165.1 mm
Woofer diameter (britisk mål):	5.5 "
Mid-range driver diameter (britisk mål):	6.5 "
Egnet til udendørs brug:	Ja
Antal mellemtoneenheder:	1
Klemskrue:	Ja
