Side 1/12

Definitive Technology

CS-8060HD & CS-8080HD OWNER’S MANUAL

CS-8000HD Series Center Channels:

CS-8060HD, CS-8080HD

Thank you for choosing the Definitive Technology CS Series Center Loudspeaker.

The CS Series is a compact high-definition loudspeaker system designed for use in

audio/video systems of the highest quality. Because of its wide range, high-power

handling and articulate clarity, it is ideal for use as a center channel in a high-

performing home theater system.

Our engineers have spent many years in developing this product. In order to ensure

that you experience the finest performance possible, we encourage you to take a

moment to fully read this owner’s manual and familiarize yourself with the proper

installation and setup procedures for your CS speaker.

CS-8060HD

CS-8080HD

Definitive Technology

CS-8060HD & CS-8080HD

OWNER’S MANUAL

Power Supply

1. The fuse and power disconnect device are located on the back of the speaker.

2. The disconnect device is the power cord, detachable at either the speaker or

the wall.

3. The power cord must be disconnected from the speaker before servicing.

Figure 2 – Wiring and Polarity

Receiver/Amplifier

Strip 1/4" (6mm) wire. Identify markings on wire and assign +/-.

Ensure that the speaker is always connected to

the receiver or amplifier + to + and – to –.

1. Unscrew binding post and insert wire.

2. Tighten until wire is secure.

Unpacking Your Model

Please Inspect For Shipping Damage

Each loudspeaker leaves our plant in perfect condition. Any visible or concealed

damage most likely occurred in handling after it left our plant and should be

reported at once to your Definitive dealer or the delivery company that

delivered your loudspeaker. Please unpack your system carefully. Save all cartons

and packing materials in case you move or need to ship your system. Record the

serial number found on the back of the Center Channel in the Notes section of

this owner's manual.

Safety Precautions

CAUTION! To reduce the risk of electric shock and fire, do not remove the

cover or back plate of this device. There are no user serviceable parts inside.

Please refer all servicing to licensed service technicians. Avis: Risque de choc

electricque, ne pas ouvrir.

CAUTION! The international symbol of a lightning bolt inside a triangle is

intended to alert the user to uninsulated “dangerous voltage” within the

device’s enclosure. The international symbol of an exclamation point inside

a triangle is intended to aler the user to the presence of important operat-t

ing, maintenance and servicing information in the manual accompanying

the device.

CAUTION! To prevent electrical shock, match wide blade of plug to wide

slot, fully insert. Attention: Pour eviter les chocs electriques, introduire la

lame la plus large de la fiche dans la borne correspondante de la prise et

pousser jusqu'au fond.

CAUTION! To reduce the risk of electrical shock, do not expose this equip-

ment to rain or moisture.

1. Read Instructions—All safety and operating instructions should be read

before operating the device.

2. Retain Instructions—The safety and operating instructions should be

retained for future reference.

3. Heed Warnings—All warnings on the device and in the operating

instructions should be adhered to.

4. Follow Instructions—All operating and safety instructions should be

followed.

5. Water & Moisture—The device should never be used in, on or near

water for risk of fatal shock.

6. Carts & Stands—The device should only be used on carts or stands rec-

ommended by the manufacturer.

7. Wall & Ceiling Mounting—The device should be mounted on a wall or

ceiling only as recommended by the manufacturer.

8. Ventilation—The device should always be located in such a way that it

maintains proper ventilation.

It should never be placed in a built-in installation or anywhere that

may impede the flow of air through its heat sink.

9. Heat—Never locate the device near heat sources such as radiators, floor

registers, stoves or other heat-generating devices.

10. Power Supply—The device should only be connected to a power supply

of the type described in the operating instructions or as marked on the

device.

11. Power Cord Protection—Power cables should be routed so they are not

likely to be stepped on or crushed by items placed on them or against

them. Special attention should be paid to areas where the plug enters a

socket or fused strip and where the cord exits the device.

12. Cleaning—The device should be cleaned in accordance with manufac-

turer’s instructions.

13. Periods Of Non-Use—The device should be unplugged when not being

used for extended periods.

14. Dangerous Entry—Care should be taken that no foreign objects or

liquids fall or are spilled inside the device.

15. Damage Requiring Service—The device should be serviced by licensed

technicians when:

• The plug or power supply cord has been damaged.

• Objects have fallen on or liquid has spilled inside the device.

• The device has been exposed to moisture.

• The device does not appear to be operating properly or exhibits a

marked change in performance.

• The device has been dropped or the cabinet becomes damaged.

16. Service—The device should always be serviced by licensed technicians.

Only replacement parts specified by the manufacturer should be used.

The use of unauthorized substitutions may result in fire, shock, or other

hazards.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

Positioning Your Speakers

Your new CS Series speaker is designed to add clarity and focus to the vocal range

and extend the musical image of your home theater. To optimize its performance,

please follow these simple guidelines. Although the following recommendations

will usually yield the best results, whatever sounds best to you is correct.

Figure 1 – Positioning CS Series Center Channel

Connecting Your Speakers

above

below

To receive the full benefit of the bass radiators built into your CS Speaker leave at

least 1–2" (2.5–5 cm) of space between the top of the speaker and any surface.

A center channel

Speaker should

be placed as

close to the

center of your

television as

possible without

obstructing

your view.

1–2"

(2.5–5 cm)

↔
