Unpacking Your Disappearing In-Wall Speakers

Please Inspect For Shipping Damage

Each loudspeaker leaves our plant in perfect condition. Any visible or concealed

damage most likely occurred in handling after it left our plant and should be reported

at once to your Definitive dealer or the delivery company that delivered your loud-

speaker. Please unpack your system carefully. Save all cartons and packing materials

in case you move or need to ship your system. Record the serial number found on

the back of the speakers and on the carton in this manual and save it for future

reference should your speaker need service. For your best protection, register your DI

Series products on-line at http://www.definitivetech.com/Registration/.

Definitive Technology

DI LCR

OWNER’S MANUAL

Thank You

Thank you for choosing Definitive Technology Disappearing In-Wall Loudspeakers.

The DI Series products offer extraordinary sound quality from speakers that are

barely visible when installed in a wall or ceiling. Our engineers spent many

years developing this product. In order to ensure that you experience the finest

performance possible, we encourage you to take a moment to fully read this

owner’s manual and familiarize yourself with the proper installation and set-up

procedures for your DI Series speaker.

5.5LCR

15-5/16" (38.9cm)

7-3/8" (18.7cm)

14-3/8" (36.4cm)

6-7/16" (16.4cm)

3-5/8" (9.3cm)

3-1/8" (7.27cm)

2@5-1/4" (13.3cm)

1@1"(25mm)

8 lbs (3.6Kg)

28Hz - 30kHz

89dB

4-8 Ohms

10 -250 WPC

Grille Length

Grille Width

Cutout Width

Cutout Length

Total Depth *

Mounting Depth In-Wall **

Woofer

Tweeter

Product Weight

Frequency Response

Sensitivity

Impedance

Recommended Amp Power

* From back of mounting flange to deepest part of product

** Total depth when product installed in 1/2" (12.7 mm) thick material

Specifications

6.5LCR

17-1/8" (43.5cm)

8-5/16" (21.0cm)

16-3/16" (41.0cm)

7-5/16" (18.6cm)

3-5/8" (9.3cm)

3-1/8" (7.27cm)

2@6-1/2" (16.5cm)

1@1"(25mm)

8.5 lbs (3.9Kg)

26Hz - 30kHz

90dB

4-8 Ohms

10 - 275 WPC

6.5

LCR

5.5LCR

Painting DI LCR Speakers

Your DI Series speakers may be painted to match the color of the wall

or ceiling in which they are installed. Failure to follow the following

painting instructions may result in seriously degraded sound quality.

It is your responsibility to make sure your painting contractor sees and

follows these instructions.

1. DO NOT PAINT THE GRILLE WITH A BRUSH OR ROLLER —

they will clog the fine mesh of the grille and cloth scrim and result

in poor sound quality.

Remove the grille from the speaker and place it on a drop cloth,

newspaper or plastic sheet.

3. The grille MUST be spray painted with one of the following:

• Spray paint that closely matches the desired finish/color

• A custom spray bomb color matched to your paint finish

• Indoor latex paint using a spray gun (paint must be diluted

to the paint manufacturer’s specifications)

4. Do not remove the backing cloth (scrim).

5. Paint should be applied in a series of thin coats sprayed at

approximately 60 degrees from the grille surface, allowing each

coat to fully cure before applying additional coats.

6. To ensure that the paint distribution is evenly applied, each coat

should be applied from at least 4 different directions to the grille.

(N, S, E & W) This will ensure an even coverage on the grille.

7. Once the grille has been painted and the paint has fully cured, you

may use a brush or small roller to touch-up the outer edge of the

grille frame — being VERY careful not to get any additional paint

on the grille mesh surface.

Placement Options

Definitive Technology DI Series Loudspeakers give you nearly endless

placement options. But remember that placement choice for your in-wall

speakers bears careful consideration, as installation requires that you cut a

hole in your wall or ceiling. It is best to keep the speakers at least 2 feet

(60 cm) from side walls [Figure 1]. When using DI Series models in home

theater applications follow the guidelines illustrated in Figures 2 and 3.

Orient the left and right speakers so that the tweeters are on the outside

edge as shown in Figure 2. Definitive DI Series In-Wall Loudspeakers have

aimable tweeters that allow you to focus their sound toward or away from

your listening area depending on the application (see page 6).

Definitive Technology

– 12 inches

(2.5 – 31cm)

1 – 3 inches

(

25 – 75mm)

Figure 3

Figure 2

Figure 1
