Side 1/12
Definitive Technology
SR - 8080BPSR - 8040BPB
- 8080HD
C
SR-8080BP & SR-8040BP OWNER’S MANUAL
SR-8000 Bipolar Surround Speakers:
SR-8080BP, SR-8040BP
Thank you for choosing the Definitive Technology SR-8000 Bipolar Surround Speakers.
These compact, high-quality bipolar speakers ar
e intended primarily for use as a r
ear or
side speakers. In addition, they can also be used as front “effects” speakers in multi-
channel DSP systems. The lifelike soundfield and flexible placement make this speaker
an excellent addition to any room.
Our engineers have spent many years in developing this product. In order to ensure
that you experience the finest performance possible, we encourage you to take a
moment to fully read this owner’s manual and familiarize yourself with the proper
installation and setup procedures for your SR surround speakers.
SR-8040BP
SR-8080BP
www.DefinitiveTech.com
L R C SR SL
Receiver/Amplifier
Speaker Outputs
Definitive Technology
2
SR-8080BP & SR-8040BP
OWNER’S MANUAL
Connecting Your Loudspeakers
Figure 2 – Wiring and Polarity
RECE IV ER/
A
MPLI FI ER
Receiver/Amplifier
+
-
Strip 1/4" (6mm) wire.
Identify markings on wire and assign +/-.
Ensure that the speaker is always con-
nected to the receiver or amplifier + to +
and – to –.
1. Unscrew binding post and insert wire.
2. Tighten until wire is secure.
1
2
Figure 3 – Connecting Speaker to Amplifier
Positioning Your SR-8000 Surround Speakers
Figure 1 – Rear and Side Surround Placement
VER
Y IMPORTANT:
Do not use your receiver’s auto setup function!!! The bipolar
nature of this speaker will often confuse the receiver’s auto
setup.
Dolby Digital and DTS multi-channel systems have critical channel balance
and speaker setup procedures which must be followed if the system is to
perform properly. Consult your receiver’s or processor’s manual to learn how
to access your system setup menus. Set speaker setup to “small” and crossover
to 80Hz for the SR-8080BP and 100Hz for the SR-8040BP.
Troubleshooting
If you experience any difficulties with your SR Series loudspeakers, try the
suggestions below. If you still have problems, contact your Definitive
Technology Authorized Dealer for assistance.
1.
Audible distortion when the speakers are playing at loud levels is
caused by driving (tur
ning up) your receiver or amplifier louder than it or
the
speakers ar
e capable of playing. Most receivers and amplifiers put out
their full-rated power well befor
e the volume contr
ol is turned all the
way up, so the position of the volume control is a poor indicator of its
power limit. If your speakers distort when you play them loud, turn the
volume down!
2.
If you experience a
lack of bass, it is likely that one speaker is out of
phase with the other and needs to be rewired paying closer attention to
connect positive to positive and negative to negative on both channels.
Most speaker wire has some indicator (such as color-coding, ribbing or
writing) on one of the two conductors to help you maintain consistency
.
It is essential to connect both speakers to the amplifier in the same way
(in phase).
3. Make sure all your system interconnects are solidly in place.
4. Check that no foreign objects or liquid has entered the speaker cabinet.
For use as side surround speakers, position
the speakers approximately 6' (2 m) high
and directly beside or 1-2' (30-60 cm)
behind the listening area.
For use as rear surround speakers, position
the speakers approximately 6' (2 m) high
and 6' (2 m) apart directly behind the lis-
tening area.
Speaker Setup:
Small,
SR-8080BP Crossover at 80Hz
SR-8060BP Crossover at 100Hz
