Side 1/12

PAGE 1 OF12

620 / 621 KITCHENAIRE

SPIRAL & SOLID PLATES STOVE

Cooking

Instruction manual

Part number: 069179

CONTENTS

Introduction

Unpacking

Installation

Electrical installation

Connecting the sprauge to

the stove

Anti-tilt mechanism

Safety advice

Control panel

6 Position selector knob

Using the oven

Solid plates

Spiral plates

Warming drawer

Maintenance

Cleaning the oven

Replacing the oven lamp

Removable oven door

Do and Don’t guide

Problem check

Owners responsibility

Branches

Warranty

Purchase details

PAGE 2 OF12

Introduction

Congratulations on the purchase of this quality product.

We trust that you will enjoy many years of trouble free use. Please read these instructions

carefully before using the stove. This manual will provide you with information on how to

operate and care for your product in order that you gain the maximum benefit from it.

Unpacking

 Please ensure that packaging material is disposed of in a responsible manner.

 Plastic bags should be cut up to prevent children playing with them and accidentally

suffocating.

 Remove all packing from the oven cavity and position the accessories.

 If the appliance is damaged in any way, do not use it. Report the damage to your dealer, who

will take the necessary corrective action.

Installation

 Levelling feet are provided to assist you in positioning your stove, so that it will stand firm

and level. To adjust the level, turn the relevant foot to either raise or lower the stove.

 Surfaces immediately adjacent to the oven should be able to withstand temperatures of up to

100°C without delaminating or discolouring.

Electrical installation

This appliance must be earthed and the manufacturer and the seller do not accept

responsibility for any damage due to incorrect installation or electrical connection.

This appliance should not be connected through an earth leakage system. Refer to S.A.N.S. 10142

Connection to the power supply

This appliance has a ‘Y’ type supply cord connection and must be installed by a licensed

electrician, who will ensure that the stove is correctly connected and safely earthed. The rated

current is printed on the serial number label attached to the stove upper back panel. The appliance

must be connected to the mains through an All pole isolating switch which has a minimum

clearance between the contacts of 3 mm in All poles. A means for disconnection must be provided

in the fixed wiring.

Connecting the sprague to the oven

1.) Purchase a standard plastic/metal saddle

type bracket, capable of going around the

20 mm diameter sprague and with a hole

pitch of 38 mm (Plastic) 45 mm (Metal),

from your local hardware and 2 off 4.2

mm x 12 mm self tapping screws.

2.) Feed the cables through the Sprague and

connect to the mains terminal block of the

appliance.

3.) Place the plastic/metal saddle around the

sprague and fasten via the 2 self tapping

screws onto the factory pre punched holes

adjacent to the mains terminal block of the

appliance.

WARNING!

ELECTRICAL

CONNECTION

MUST ONLY BE

DONE BY A

QUALIFIED

ELECTRICIAN!

Accessories supplied may vary depending on the model. Not all accessories in the

user manual may be included with your appliance. Accessories may be purchased

from Defy spares.
