ACT- 1302T Quick Start Guide

ENG-1

Introduction to Appearance and Keypad

1. Memory card slot

2. Reset

3. USB slot

4. Power button

5. MIC

6. Shutter button

7. Mode Switch

8. Lens

9. LCD Touch Screen

10. Working Indicator Light

11. Indicator Light for charging

12. Wrist strap eyelet

Usage

1. Charge built- in lithium battery

In power-oﬀ state, when the camera is connected with computer,

charging begins. At this time, the charger indicator lights and it turns oﬀ

when charged full. Generally, it costs 2-4 hours to charge full.

2. Use memory card

1. Follow the instructions carved by slot of the memory card, it is to insert

FT card into the card slot till entirely inserted.

2. To t ake the F T c ard out , after gently pr es sing the end of the memory

card inwards, the card will reject out.

Note: The camera is not equipped with a built-in memory, and thus a

memory card is required.

3. Power On/Oﬀ

3.1 Power-on: If to press and hold POWER key for 3 seconds, the

screen starts up and the camera enters startup state.

3.2 Power-oﬀ: In idle state of the camera, if to click POWER key, the

camera turns oﬀ.

Automatic power-oﬀ: When idle time set for the camera reaches, it

automatically turns off to save power. The default time of the

system automatic power-oﬀ is 5 minutes;

3.3Power-oﬀ due to low battery: In case of extremely low battery, the

icon “ ”appears on the LCD screen. Please timely

charge the battery. When the icon turns red and ﬂashes, the

camera will automatically power oﬀ.

4. Functional mode switchover

The camera is equipped with three modes: capture, video and replay

mode. After power-on, the modes can be switched over with MODE

switch.

5. Indicators

Operation indicator: When the camera works (e.g. recording

video, capturing or automatic screen turn-oﬀ),

the operation indicator lights.

Charger indicator: Constant lighting is to remind user that the

camera is being charged.

6. Video recording mode

(With maximum 29 minutes video recording and then stop. Must be

started manually on the camera again.)

When the mode switch is turned to video mode, press the shutter

button once or click the LCD center once to begin videoing under

previewing state; press the shutter button once again if you want to

stop videoing, and the camera will also stop videoing automatically

when you reach 29 minutes video records, the memory card is full or

the power is insufficient during videoing period:

1 00:12:18: Timer means that videoing can still last for 12

minutes and 18 seconds.

2 : mode icon

represents that the

camera is in videoing and

recording mode at

present.

3 : videoing size clicks this icon and you can choose

720P/VGA.

4 : means that the memory card is inserted at present.

5 : digital zoom icon, click it and enlarge it.

6 : digital zoom icon, click and minify it.

7 : visual shutter, click this icon for taking photos or

recording.

8 : battery icon represents the present power of the battery.

9 : represents digital zoom times.

10 con to switch to the playback mode. : click this i

7.Photo mode

Switch the mode switch into the photo mode, press the shutter

button or click the LCD center once under the previewing state to

take a photo:

1 Counter, indicating current number of photos taken 0/1234:

already /number of photos to be taken.

2 : mode icon, indicating that the camera is in photo taking

mode at current.

3 : video size, click this icon to select 1M/3M/5M.

4 : means that the memory is been inserted at present.

5 : digital zoom icon, click it

to enlarge.

6 : digital zoom icon, click it

to minify.

7 : visual shutter, click this icon for taking photos or videoing.

8 : battery icon, indicates the power of the battery at present.

9 : indicates digital zooming times.

10 : click this icon to switch to the playback mode.

USB Cable

Capture mode: Take pictures.

Video mode: Record video and

driving (5min, 3min and 1min).

Replay mode: Picture and video

file playback.

ACT-1302T Quick Start Guide

ENG-2

8. - Vehicle mounted mode

Turn the mode switch to vehicle-mounted mode, press the shutter

button or click the LCD center once under the preview state to begin

recording, save a segment for recording every 5 minutes, then start to

record the next segment of video. When the storage card is full, the

earliest segment of video will be deleted to release the corresponding

space for continuous recording, and so the cycle.

1 00:12:18 timer, indicating that the camera can still record for

12 minutes and 18 seconds.

2 : mode icon, representing that the camera is in

vehicle-mounted mode at present.

3 : video size, click this

icon to select 1M/3M/5M.

4 : represents that the

memory card is been

inserted at present.

5 : digital zoom icon, click it to enlarge.

6 : digital zoom icon, click it to minify.

7 : visual shutter, click it for taking photos and recording.

8 : battery icon, representing the current power of the

battery.

9 : indicates the digital zooming times.

10 mode. : click this icon to switch into the playback

Note: the screen will be oﬀ automatically during recording process in

order to save power; user can press the power button shortly to start

the screen and restore display.

9. Playback mode

9.1 After starting up and entering the previewing state, click the

playback icon ( ) at the lower right corner of the LCD to switch to

the playback mode:

Click

1 : represents that the current file is an AVI video file.

2 : represents that there

is one file in the current

folder/one file in total.

3 \DCIM\: current folder name (such as: I: 100MEDIA, I: is the

movable disk of the device).

4 : Means that clicking can select files frontwards.

5 : Means that clicking can select files backwards.

6 : Means that clicking can activate to confirm the deletion

of the current file picture.

7 : Means that clicking can play the current movie clips.

8 : Means that clicking can switch back the previous photo

mode (video mode).

9.2 Movie clips playing

Click to pause playing, click to play quickly, and click

to play slowly.

9.3 File deletion

Click YES to delete the current ﬁle immediately, or click NO to cancel

the deletion operation.

Warning

• Lithium battery inside!

• Do not try to open the product!

• Do not expose to heat, water, moisture, direct

sunlight!

CAUTION!

DENVER ELECTRONICS A/S

Electric and electronic equipment and included batteries contains

materials, components and substances that can be hazardous to your

health and the environment, if the waste material (discarded electric and

electronic equipment and batteries) is not handled correctly.

Electric and electronic equipment and batteries is marked with the

crossed out trash can symbol, seen below. This symbol signiﬁes that

electric and electronic equipment and batteries should not be disposed

of with other household waste, but should be disposed of separately.

As the end user it is important that you submit your used batteries to the

approriate and designated facility. In this manner you make sure that the

batteries are recycled in accordance with legislature and will not harm

the environment.

All cities have established collection points, where electric and electronic

equipment and batteries can either be submitted free of charge at

recycling stations and other collection sites, or be collected from the

households. Additional information is available at the technical

department of your city.

Imported by:

DENVER ELECTRONICS A/S

Stavneagervej 22

DK-8250 Egaa

Denmark

www.facebook.com/denverelectronics

Produkt Specifikationer

Mærke:	Denver
Kategori:	Videokamera
Model:	ACT-1302T MK2
Bredde:	66 mm
Dybde:	27 mm
Højde:	43 mm
Vægt:	- g
Produktfarve:	Sort
Batterikapacitet:	440 mAh
Indbygget skærm:	Ja
Vægt (inkl. batteri):	40 g
Skærm diagonal:	2 "
Berøringsskærm:	Ja
Kompatible hukommelseskort:	MicroSD (TransFlash)
Wi-Fi:	Ingen
Bluetooth:	Ingen
Batteriteknologi:	Lithium
HD-type:	HD-Ready
Understøttede videotilstande:	720p
Antal USB 2.0-porte:	1
Understøttede videoformater:	AVI
Vandtæt op til:	10 m
Beskyttelsesfunktioner:	Vandtæt
Kabler inkluderet:	Mini-USB
Pakketype:	Kasse
Understøttede billedformater:	JPG
Near Field Communication (NFC):	Ingen
Batterilevetid (maks.):	1.5 t
Lagermedie:	Hukommelseskort
Indbygget mikrofon:	Ja
Mikrofonindgang:	Ja
Sensortype:	CMOS
Maksimal billedopløsning:	2592 x 1944 pixel
Samlet antal megapixels:	- MP
Maksimal videoopløsning:	1280 x 720 pixel
Videoopløsninger:	1280 x 720 pixel
Maksimal størrelse på hukommelseskort:	32 GB
Maksimum billedhastighed:	30 fps
USB-stik type:	Mini-USB A
Optisk sensorstørrelse:	1/3 "
Synsfelt vinkel (FOV):	120 °
Flip-ud skærm:	Ingen
Fototilstand:	Ja
HD-Ready:	Ja
Undervandsbeholder:	Ja
Cykelbeslag:	Ja
Hjelmbeslag:	Ja
Stropbeslag:	Ja
