user manual

Symbols explanation:

Product accordance with the EU directive 2002/96/EC. The symbol of the crossed out basket

placed on the product means that the marked product can not be disposed of with other

household waste. After use, the product must be return to collection point for used electical and

electronic equipment or to the seller. Appropriate segregation of rubbish for subsequent

processing, recovery or descrution contributes to avoiding negative effects on the environment

and health, and also allows the recovery of raw materials from which the product is made.

The CE standard description on the product is the manufacturer's declaration that the marked

product meets the requirements of the directive so-called The "New Approach" of the European

Union (EU). For security and certification (CE) reasons, the device can not be rebuild or change

in any way. In the reason of using the power supply for other purposes than those described,

the product may be demaged. The incorrect use may also cause hazard such as short-circuits,

burns, electric shocks, etc. Read the users manual carefully and keep it for later use. The product

could be share to third partie only with the user manual included.

BOX

Ecological Solutions

GREEN

ATX power supplies

The RoHS mark on the product is the manufacturer's declaration that the marked product meets

the requirements of the EU Restriction of Hazardous Substances (2002/95/EC) directive, which

aims to reduce the amount of hazardous substances penetrating into the environment from

electrical and electronic waste.

www.akyga.com

In case of replacement of an old unit:

ź Disconnect all power plugs from the computer

ź Remove the computer housing

ź Disconnect all power connectors of the old PSU

ź Unscrew 4 screws holding the old PSU on the back of the computer

Installation of new Power Supply:

ź Screw new power supply to the case using 4 screws

ź Connect power connectors of a new PSU to suitable devices inside of the computer

ź Please remember that power connectors are intended for assembly in one particular way,

if there are problems with connection of plug and connector then reverse it and try again.

ź Make sure that there are no loose screws left inside the computer

ź Put on and tighten the computer case

ź Connect the power cord plug to an electrical outlet

Power Supply Instalation guide

Safety Precautions

WARNING! Product heats up during operation. To reduce the risk of burns or overheating the power

supply, do not place it in restricted ventilation area. Also, do not allow the working power supply to touch

soft surface such as pillows, blankets or clothing. The power supplies meets the limits on the surface

temperatures available to the user, as defined in the International Standard for Safety of Information

Technology Equipment (IEC 60950).

page 1

Produkt Specifikationer

Mærke:	Akyga
Kategori:	Computer adapter
Model:	AK-S1-300
Vekselstrømsindgangsspænding:	230 - 240 V
Vekselstrømsindgangsfrekvens:	50 - 60 Hz
Bredde:	125 mm
Dybde:	63.5 mm
Højde:	100 mm
Vægt:	600 g
Produktfarve:	Sølv
Pakkevægt:	700 g
Pakkedybde:	63.5 mm
Pakkebredde:	125 mm
Pakkehøjde:	150 mm
Opbevaringstemperatur (T-T):	0 - 60 °C
Relativ luftfugtighed ved drift (H-H):	0 - 60 %
Relativ luftfugtighed ved opbevaring (H-H):	5 - 60 %
Driftstemperatur (T-T):	5 - 50 °C
Støjniveau:	30 dB
Certificering:	RoHS, REACH, CE
Bæredygtighedscertifikater:	RoHS
Formål:	PC
Oprindelsesland:	Polen
Indgangsstrøm:	5 A
Gennemsnitstid mellem fejl (MTBF):	100000 t
Total effekt:	300 W
Antal blæsere:	1 blæser(e)
Strømbeskyttelsesfunktioner:	Over current, Over power, Over voltage, Overheating, Short circuit
Effektivitet:	70 %
Maksimal strøm:	300 W
Strømkorrektionsfaktor (PFC):	Passiv
Kombineret effekt (+3,3 V):	90 W
Kombineret effekt (+12 V):	204 W
Kombineret effekt (+5 V):	90 W
Maks. udgangsstrøm (+3,3 V):	9 A
Maks. udgangsstrøm (+12 V):	17 A
Maks. udgangsstrøm (+5 V):	13 A
Maks. udgangsstrøm (-12V):	0.5 A
Maks. udgangsstrøm (+5 VSB):	2.5 A
Strømforsyningenhed (PSU) formfaktor:	SFX
Ventilator diameter:	80 mm
Kølingstype:	Aktiv
Motherboard, strømstik:	20+4 pin ATX
Antal SATA strømstik:	2
Perifere (Molex) strømstik (4-pin):	2
CPU P4 strømstik (4-pin):	1
Kabeltype:	Ikke modulær
ATX strømstrik (24 stikben):	Ja
Kombineret effekt (-12V):	16 W
Kombineret effekt (+5 VSB):	16 W
Blæser placering:	Top
Længde på strømkabel på bundkort:	350 mm
Strømkabellængde SATA:	350 mm
Strømkabellængde CPU:	400 mm
ATX strømstik (20+4 pin):	Ja
