DIGITUS® Plug&View IP

cameras

User Guide

Plug&View IP camera ׀

Manual ׀

EN-201310

1 Introduction:

The Plug&View IP camera series by DIGITUS offers P2P cloud services in order to avoid the

complicated network configuration for the camera installation. Everything you need is "Plug&View"

and a few installation steps.

2 Supplied with:

- 1 X IP camera

- 1 X AC adapter

- 1 X ethernet cable

- 1 X installation CD

- 1 X Mounting Accessories

- * DN-16038/DN-16039/DN-16040/DN-16043/DN-16044 also include a built in 2GB memory for

storage.

3 Installation procedure:

3.1 Connect

Please follow the instructions of the Quick Start Guide to connect your Plug&View camera and to

start using it from your user account. Then log in to your user account in http://plug-view.com. After a

successful login you will see an overview of the images of your registered cameras.

4 Description of the toolbar

The toolbar can be found to the right side above the image of each IP camera. Here

you can quickly see the operational readiness and make various settings.

4.1 LED display symbols

 Green light

When the green light is ON, your IP camera is online und sending. The video image is

successfully displayed on the screen.

 Yellow light

When the yellow light is ON, the IP camera is online, but not yet sending. No video image is

displayed on the screen.

 Red light

When the red light is ON, the IP camera is offline and nothing is displayed on the screen.

4.2 Full Screen

The 'Full Screen' button opens a new screen for better viewing of the video image, which is then

displayed across the entire screen.

Produkt Specifikationer

Mærke:	Digitus
Kategori:	Overvågningskamera
Model:	DN-16038
Type:	IP-sikkerhedskamera
Højde:	90 mm
Brugervejledning:	Ja
Produktfarve:	Hvid
Wi-Fi:	Ja
Formfaktor:	Kuppel
Ethernet LAN:	Ja
Wi-Fi-standarder:	Wi-Fi 4 (802.11n)
Understøttede videoformater:	H.264
Driftstemperatur (T-T):	0 - 40 °C
Maksimal opløsning:	1600 x 1200 pixel
Intern hukommelse:	2000 MB
Kabler inkluderet:	Vekselstrøm
Understøttede grafikopløsninger:	1280 x 720 (HD 720),1600 x 1200 (UXGA)
Forbindelsesteknologi:	Kabel & trådløs
Kabelteknologi:	10/100Base-T(X)
DC-in-stik:	Ja
Monteringstype:	Loft
Diameter:	115 mm
Understøttet placering:	Indendørs
Samlet antal megapixels:	2 MP
Optisk zoom:	- x
Strøm over Ethernet (PoE):	Ingen
Minimumsbelysning:	- Lux
Nattesyn:	Ja
LED type:	IR
Billedhastighed:	25 fps
DC udgangsspænding:	+12V
DC-udgangsstrøm:	1 A
Monteringssæt:	Ja
Brændviddeområde:	1.5 - 3.6 mm
Objektivets synsvinkel, vandret:	69 °
